Appendix A - American Healthy Homes Survey II (AHHS II)

Field Sampling Protocols, Resident Questionnaire and Informed Consent

The AHHS II is a follow-up to the American Healthy Homes Survey (AHHS) conducted 2005-2006, and the National Survey of Lead and Allergens in Housing (NSLAH) conducted 1998-1999. Sponsored by the US Department of Housing and Urban Development (HUD) and the Environmental Protection Agency (EPA), it is aimed at monitoring changes in the level of health hazards in homes over time and in refining understanding of certain patterns identified in the AHHS and NSLAH. The design of the AHHS II is intended to maximize comparability of these surveys where appropriate (e.g., environmental sampling methodologies), while reflecting significant scientific and technological advances and evolution of the specific housing conditions of greatest interest to HUD.

The objectives, design, field operations and reporting requirements of the AHHS II are very similar to those to AHHS. Key differences are:

Allergen sampling will not be conducted.
Household dust and soil sampling for arsenic is not part of the design.
Evaluation of the potential for unintentional injuries, such as from falls, fires, burns, electrical faults, carbon monoxide, etc., has been added.
Air sampling for formaldehyde will be conducted.
Sampling for lead in household water and lead service lines will be included.

Survey objectives will be addressed by collecting a wide range of data including demographic data and various environmental data, from a nationally representative sample of approximately 600 housing units (dwelling units) across the United States (data on 1,131 units were collected in AHHS).

The dwelling units (DUs) have been randomly selected from 58 Primary Sampling Units (PSUs). For AHHS II, PSUs are counties or groups of contiguous counties with a minimum population of 15,000 in the 2000 Census and an end-to-end distance generally not exceeding 100 miles. Within each PSU between 4 and 12 smaller geographical areas called segments have been selected. Most PSUs consist of 5 segments.

At the start of the study, a total of 16-20 DUs in each PSU will be released for recruitment. Interviewers will attempt to recruit all released DUs. Each DU recruited will be scheduled by the Interviewer to be tested. A two-person team will do testing of each recruited DU: the Interviewer who recruited the DU and a licensed lead risk assessor referred to in this study as a Technician. Testing will include a resident questionnaire and collection of a wide variety of measurements. A summary of the environmental sampling is provided in Table INTRO-1. A summary of the analytical methods used to analyze the collected samples is presented in Table INTRO-2.

Table INTRO-1. Summary of Environmental Sampling
ID^a	Information Captured or Target Analyte	Data Collection Method or Sampling Media	Tests or Samples per DU	Special Handling Requirements	Maximum Media Count	Notes
Collected by Interviewer
I2	Lead in water (1st draw)	Bulk 1-liter	1	acidified at lab and wait >16 hrs before analysis	600	wide mouth LDPE bottle
I6	Mold by PCR	Vacuum dust (resident vacuum bag)	0-1	none	600
I8	Mold (by PCR)	Vacuum dust	1	none	600
I9	Mold (by PCR)	Dust wipe (Swiffer™)	1	frozen after collection	116	2 per PSU (58 PSUs)
I10	Lead in water (flushed draw)	Bulk 1-liter	1	acidified at lab and wait >16 hrs before analysis	658	wide mouth LDPE bottle; Count includes 2 spiked QC/PSU
Collected by Technician
T1	Formaldehyde in air	Absorption tube	1 plus 1 blank/PSU	frozen before and after collection	716	Count includes 1 spiked QC/PSU
T2	Lead based paint	XRF	>40 readings plus QC	not applicable	not applicable	Testing of water supply line for Pb included here, if it can be accessed.
T3	Lead in dust	Dust wipe	9 plus 1 blank	none	6600	Count includes 10% QC
T4	Pesticides	Dust wipe	2 plus 1 blank/PSU	frozen after collection	1258
T5	Lead in soil	Soil	0 to 6	dried at room temperature and sieved to <2 mm, sub-sampled, then sent to EPA	2640	Count assumes mean of 4 samples/DU and, for lead in soil, includes 10% QC.
T5	Bioavailable lead	Soil	0 to 6	sieved to <250 µm	2400
^aIdentifies the protocol containing detailed instructions for the tests or sample collection.

Table INTRO-2. Summary of Analytical Methods
ID^a	Information Captured or Target Analyte	Sample Preparation	Analytical Method	Detection Limits
Collected by Interviewer
I2	Lead in water (1st draw)	Acidified at lab to pH<2 with 1:1 nitric acid and wait >24 hrs before analysis	SM^b 3113B (GFAA) or ICP/MS	Pb: 3 µg/L
I6	Mold by PCR	sieved to 300 µm and extracted in neutral buffer and shaken in the bead beater to release the DNA. The mold DNA is purified using the DNA-EZ extraction kit.	MSQPCR developed by EPA (US Patent No.6,387,652).	not defined
I8	Mold (by PCR)
I9	Mold (by PCR)
I10	Lead in water (flushed draw)	acidified at lab to pH<2 with 1:1 nitric acid and wait >24 hrs before analysis	SM^b 3113B (GFAA) or ICP/MS	Pb: 3 µg/L
Collected by Technician
T1	Formaldehyde in air	none	modified NIOSH 2016 (HPLC- UV detection)	0.12 ppb for 3-hour sample at 1.5LPM
T2	Lead based paint by XRF	none	Direct field measurement using field portable XRF	Meets HUD EPA PCS requirements
T3	Lead in dust	EPA 3050B-M	EPA 6010C (ICP)	Pb: 20 mg/kg (RL)
T4	Pesticides	Extracted in dichloromethane and concentrated using solid-phase extraction cartridge^b	GCMS^b	variable depending on pesticide
T5	Lead in soil	EPA 3050B-M	EPA 6010C (ICP)	Pb: 20 mg/kg (RL)
T5	Bioavailable lead	EPA Method 9200.2-86: Buffered leach (pH 1.5) mimicking stomach acid conditions	EPA Method 3051A	not defined
^aIdentifies the protocol containing detailed instructions for the tests or sample collection. ^bStout, D.M., et.al.; American Healthy Homes Survey A National Study of Residential Pesticides Measured from Floor Wipes; Environ. Sci. Technol., 2009, 43, 4293-4300

LIST OF GENERAL (OFFICE) STUDY PROTOCOLS

Item Page

G2- DU RELEASE TO INTERVIEWERS 1

Advance Letter - Longitudinal 4

Advance Letter - New 5

Advance Letter – Longitudinal – Hand Delivered 6

Advance Letter – New – Hand Delivered 7

No Contact Letter - Longitudinal 8

No Contact Letter - New 9

Refusal Letter - Longitudinal 10

Refusal Letter - New 11

PSU Summary Sheet 12

G6- SUMMARY OF TESTING IN EACH DU 13

Table G6-1. Planned Division of Labor for Testing Efforts in Each DU 13

G7-TELEPHONE VERIFICATION OF DATA COLLECTION 14

Telephone Verification Log 15

G8 - ISSUANCE OF PARTICIPANT REPORTS 16

Respondent Report - Lead and/or Safety Hazards Exist 17

Respondent Report - No Lead and/or Safety Hazards Exist 20

LIST OF INTERVIEWER PROTOCOLS

Item Page

I0/T0 - GENERAL PROCEDURES FOR MINIMIZING CONTAMINATION 21

I2- RECRUITMENT SCREENING 23

Cover Sheet for Recruiting Questionnaire Form Set 27

Appointment Control Log and In-Person Contact Record 28

Recruitment Questionnaire 29

Appointment Reminder Card 34

Scheduling Calendar 35

Figure I2-1 - Bottle label for the first draw sample 36

FAQs 37

I3- INTRODUCTION AND INFORMED CONSENT 43

Cover Sheet for Resident Questionnaire Set 46

Introduction - part of Resident Questionnaire 47

Informed Consent 48

I4- ROOM INVENTORY 53

Room Inventory part of Resident Questionnaire 56

Random Number Table for Random Selections 57

I5- RESIDENT QUESTIONNAIRE 58

Remaining portions of Resident Questionnaire 59

Break-off Report 80

I6- INTERIOR WALKTHROUGH OBSERVATIONS 82

Household Walkthrough Observations forms 84

Vacuum Cleaner Bag Collection 88

AHHS II Field Chain-of-Custody for Vacuum Bag Sample 89

LIST OF INTERVIEWER PROTOCOLS - continued

Item Page

I7- ROOM OBSERVATION and BUILDING MOISTURE MEASUREMENTS 90

Room Observation Form - KIT 94

Room Observation Form - CLA 95

Room Observation Form - BR 96

Room Observation Form - Other Room 97

Room Observation Form - Basement 98

Building Materials - Moisture Testing Log 99

I8- FUNGI VACUUM DUST SAMPLING 100

Vacuum Sample Fungi Log 103

Random Number Table for Random Selections 104

I9- DUST WIPE SWIFFER™ SAMPLE 105

Dust wipe SWIFFER™ Sample Log 106

Chain-of-Custody for Vacuum Dust & Dust Wipe Swiffer™ Samples 107

I10- FLUSHED DRINKING WATER SAMPLE 108

Drinking Water Sample Log 110

Chain-of-Custody for Drinking Water Samples 111

I11- EXTERIOR WALKTHROUGH OBSERVATIONS 112

Exterior Conditions Log 113

LIST OF FIELD TECHNICIAN PROTOCOLS

Item Page

T1- FORMALDEHYDE IN AIR SAMPLING 114

Cover Sheet for Technician Form Set 119

Formaldehyde Sample Log 120

Chain-of-Custody for Formaldehyde Samples 121

T2- LEAD-BASED PAINT TESTING (using XRF) 122

Table T2-1. Data Collection Programming on the Heuresis model Pb200i 125

LBP Testing Codes and Checklist Instructions 126

LBP Testing Checklist for Miscellaneous Tests 127

LBP Testing Checklist for KIT 128

LBP Testing Checklist for CLA 129

LBP Testing Checklist for BR 130

LBP Testing Checklist for Other Room 131

LBP Testing Checklist for Exterior 132

Random Number Table for Random Selections 133

T3- LEAD DUST WIPE SAMPLING 134

Figure T3-1: Schematic of a side-to-side overlapping "S" wiping pattern 137

Figure T3-2: Schematic of a side-to-side overlapping "Z" wiping pattern 137

Lead Wipe Sample Log - KIT 138

Lead Wipe Sample Log - CLA 139

Lead Wipe Sample Log - BR 140

Lead Wipe Sample Log - Other Room 141

Lead Wipe Sample Log - Entry 142

AHHS Field Chain-of-Custody for Lead in Wipes 143

LIST OF FIELD TECHNICIAN PROTOCOLS - continued

Item Page

T4- PESTICIDE WIPE SAMPLING 144

Figure T4-1: Schematic of a side-to-side overlapping "S" wiping pattern 147

Figure T4-2: Schematic of a side-to-side overlapping "Z" wiping pattern 147

Pesticide Wipe Sample Log 148

Chain-of-Custody for Pesticide Samples 149

T5- LEAD SOIL SAMPLING 150

Random Number Table for Random Selections 155

Lead Soil Sample Log 156

Chain-of-Custody for Lead in Soil 157

G2- DU RELEASE TO INTERVIEWERS
Staff Involved:	Assigned QT Office Staff
Overview: The average number of DUs to be recruited and completed is 10.3 per PSU. Initially, for each PSU, a base draw of 4 dwelling units (DUs) in each segment (typically 16-20 DUs/PSU) will be released to the Interviewer for recruitment. These DUs are given a SAMP TYPE designation of M1, M2, M3, and M4. An additional draw of 2 DUs in each segment will be held in reserve. These DUs are given a SAMP TYPE designation of R1 and R2. The Interviewer will follow the full recruiting protocol for each DU released to him/her. At least four attempts will be made to contact a resident at each DU. Attempts will be made at different times of the day and on different days of the week. For example, if the first contact during the day on a weekday is unsuccessful, the second attempt might be made on a weekday evening, followed by a third attempt on the weekend, etc. The recruiting effort for a DU will be considered complete only if contact is made and a data collection visit is agreed to or refused, or if four unsuccessful attempts are made to contact a resident.
Data Recording on:		AHHS II Recruitment Tracking Spreadsheet

QuanTech headquarters staff will aid the recruiting in several ways:

1. AHHS II Recruitment Tracking Spreadsheet. An Excel workbook will be created and used at QuanTech headquarters (QT) to track all the recruiting and DU completion efforts as well as the general support efforts provided by staff at QT.

2. Advance Letters. QuanTech headquarters (QT) will mail an Advance Letter to each selected address about one week before the Interviewer arrives in the PSU. The Advance Letter explains the survey and the incentives for participation, and alerts the recipient to the pending visit from the Interviewer. Included with this letter is a token cash incentive of $1. These letters will be sent in Official HUD envelopes. The Interviewer will also hand a copy of the Advance Letter to the resident when contact is made. If nobody is home when the Interviewer first visits a DU, and the home is not obviously vacant, the copy of the Advance Letter will be hung in a clear plastic doorknob hanger bag on the main entry door of the DU. This copy will explain that the Interviewer stopped by and will return soon.

3. No Contact Letter. If four attempts to contact a resident at a selected DU are unsuccessful, and for DUs where access is impossible, e.g., some gated communities or apartment buildings with a doorman¹, a No Contact Letter will be sent by Priority Mail. These letters will also be sent in Official HUD envelopes. The No Contact Letter elaborates on the importance of the survey and the incentives for participation and provides a toll-free number to call to schedule a visit.

4. Refusal Letter. Finally, in the event of a refusal, a Refusal Letter will be sent by sent by Priority Mail to the potential respondent. The Refusal Letter will reiterate the reasons for participating and the incentives for doing so, and will provide a toll-free number for the potential respondent to call.

There are two versions of each letter: one for longitudinal addresses and one for new addresses. The wording differences are minor.

DU ID Number Assignments

The DU ID to be used by the Interviewer and Technician combines 3 data fields shown on the AHHS main and reserve sample DU addresses list, and has the following format:

XXX-YYY-ZZ

Where XXX is the PSU ID identifier from the AHHS Main and reserve sample DU addresses list identifier; a number from 101 to 999

YYY is the AHHS SEGID identifier; a number from 001 to 999

ZZ is the SAMP TYPE identifier from the AHHS Main and reserve sample DU addresses list identifier, M1, M2, M3, or M4 for main sample draw and R1 or R2 for reserve sample draw.

In AHHS II, a pesticide sample is to be collected in every DU, with an additional pesticide QC sample collected in the first DU visited in each PSU. A Swiffer™ dust wipe sample for mold is to be collected in the first two DUs visited in each PSU.

PSU Summary Sheet

The AHHS main and reserve sample DU addresses listing provided to the Interviewer in the Recruitment Kit (A) contains both the main draw DUs and the reserve draw DUs. A PSU Summary Sheet (see form at the end of this protocol) is added to this information to specify the DUs that are to be recruited.

Adjustments to Released DUs for Realized Recruitment Rate

QuanTech will attempt to complete data collection in all recruited DUs. However, it is expected that a small number of recruited DUs will not be completed (such as in the case of refusal to sign the informed consent, or a "mid-interview" refusal where the respondent decides to terminate the visit before data collection is complete). After approximately 20 PSUs have been completed, an evaluation of the response rate will be made. If the response rate for the first 20 PSUs is running low, QuanTech will release additional DUs from the reserve draws in the second 20 PSUs. The number of reserves released will be the number needed, based on the response rate for the first 20 PSUs, to bring the number of completed DUs in the first 40 PSUs up to the desired total of approximately 400 with high probability. Conversely, if the response rate is running high, a downward adjustment in the number of DUs released will be made. An additional response rate evaluation will be conducted after 40 PSUs are completed and adjustments made as needed.

Release Procedure

1. Verify DUs to be released. Discuss with the Project Director which DUs are to be released to the Interviewers. These entries are also to be made in a master spreadsheet containing all the DU listings.

2. Complete the PSU Summary Sheet. Complete the PSU Summary Sheet and put it in each folder containing the AHHS main and reserve sample DU addresses listings in the Recruiting Supplies Kit (A).

3. Mail out Advance Letter. One week before the start of recruiting at a given PSU, mail the Advance Letter containing the token $1 incentive to all released DUs. There are two categories of advance letters to be mailed: one for longitudinal addresses and one for new addressed. The master spreadsheet is configured to indicate which addresses belong to each category.

4. Update Tracking Records. Indicate, in the master spreadsheet containing the DU listings, the date the initial contact letters were sent and store this copy in the project records by PSU. Update the electronic version of the spreadsheet as time permits.

OMB No. xxxx-xxxx

expires: mm/dd/2018

U.S. DEPARTMENT OF HOUSING AND URBAN DEVELOPMENT

WASHINGTON, DC 20410-3000

OFFICE OF LEAD HAZARD CONTROL

AND HEALTHY HOMES

Control No. xxxxxxxxx

<date>

Dear Sir or Madam:

Ten years ago, this home was in the first American Healthy Homes Survey. You may not have lived here then. We selected it again as one of only 600 homes for the second American Healthy Homes Survey. Each home stands for thousands more. If you participate, you will get $160, a report on health and safety hazards in your home and, if you accept it, a report on lead paint hazards in your home. Reports like these can cost hundreds of dollars.

The purpose of the survey is to learn more about things in the home that can affect your health and safety. We will test for:

Lead in paint, dust and soil, that can harm young children.
Lead in your water. We will ask you to collect a water sample for this test, first thing in the morning.
Pesticides that may also be harmful to people.
Formaldehyde, found in carpets, furniture or particle board, that can cause health problems.
Mold in your home, whether you can see it or not, that can cause allergies or asthma.
Safety hazards such as carbon monoxide; smoke detectors that don’t work; electrical hazards; water that is too hot for children or the elderly; and, things that can cause trips and falls.

The survey will give you valuable information to protect your health and safety. It will also help the Government to understand how common these health and safety problems are in the country. Even if your home does not have any of these hazards, you are still giving valuable information to the study.

The Department of Housing and Urban Development (HUD) and the Environmental Protection Agency (EPA) are funding this survey. It is being conducted by QuanTech, a contractor. In a few days, an interviewer from QuanTech will contact you. She or he will show you official ID and ask you some short, easy questions about you and your home. These questions will help see if your home can participate in the survey. For example, vacation homes are excluded from the study. If your home is eligible, we hope you will participate so that our results will be complete. Answering the questions is completely voluntary, and you may choose not to answer any question. Your answers will be kept confidential.

We have enclosed a small token of appreciation as a way of saying thanks for your help.

If you have any questions or if you want to speak to a study representative at any time, please call Dr. David Cox, QuanTech, at 1-800-229-5220. We thank you in advance for your cooperation.

Sincerely,

Warren Friedman

Senior Advisor to the Director

This survey is a Federal program authorized under the Residential Lead-Based Paint Hazard Reduction Act and the National Environmental Policy Act. We will use the information collected in your home for scientific research and reports only. Your answers will be combined with others, so that no one can identify which answers are yours. No one outside the study will have access to your information.

No. xxxx-xxxx

expires: mm/dd/2018

U.S. DEPARTMENT OF HOUSING AND URBAN DEVELOPMENT

WASHINGTON, DC 20410-3000

OFFICE OF LEAD HAZARD CONTROL

AND HEALTHY HOMES

Control No. xxxxxxxxx

<date>

Dear Sir or Madam:

Your home is one of 600 selected to take part in an important national survey, the second American Healthy Homes Survey. Each home stands for thousands more. If you participate, you will get $160, a report on health and safety hazards in your home and, if you accept it, a report on lead paint hazards in your home. Reports like these can cost hundreds of dollars.

The purpose of the survey is to learn more about things in the home that can affect your health and safety. We will test for:

Lead in paint, dust and soil, that can harm young children.
Lead in your water. We will ask you to collect a water sample for this test, first thing in the morning.
Pesticides that may also be harmful to people.
Formaldehyde, found in carpets, furniture or particle board, that can cause health problems.
Mold in your home, whether you can see it or not, that can cause allergies or asthma.
Safety hazards such as carbon monoxide; smoke detectors that don’t work; electrical hazards; water that is too hot for children or the elderly; and, things that can cause trips and falls.

The Department of Housing and Urban Development (HUD) and the Environmental Protection Agency (EPA) are funding this survey. It is being conducted by QuanTech, a contractor. In a few days, an interviewer from QuanTech will contact you. She or he will show you official ID and ask you some short, easy questions about you and your home. These questions will help see if your home can participate in the survey. For example, vacation homes are excluded from this survey. If your home is eligible, we hope you will participate so that our results will be as complete as possible. Answering the questions is completely voluntary, and you may choose not to answer any question. Your answers will be kept confidential.

We have enclosed a small token of appreciation as a way of saying thanks for your help.

If you have any questions or if you want to speak to a study representative at any time, please call Dr. David Cox, QuanTech, at 1-800-229-5220. We thank you in advance for your cooperation.

Sincerely,

Warren Friedman

Senior Advisor to the Director

OMB No. xxxx-xxxx

expires: mm/dd/2018

U.S. DEPARTMENT OF HOUSING AND URBAN DEVELOPMENT

WASHINGTON, DC 20410-3000

OFFICE OF LEAD HAZARD CONTROL

AND HEALTHY HOMES

Control No. xxxxxxxxx

<date>

Dear Sir or Madam:

The purpose of the survey is to learn more about things in the home that can affect your health and safety. We will test for:

Lead in paint, dust and soil, that can harm young children.
Lead in your water. We will ask you to collect a water sample for this test, first thing in the morning.
Pesticides that may also be harmful to people.
Formaldehyde, found in carpets, furniture or particle board, that can cause health problems.
Mold in your home, whether you can see it or not, that can cause allergies or asthma.
Safety hazards such as carbon monoxide; smoke detectors that don’t work; electrical hazards; water that is too hot for children or the elderly; and, things that can cause trips and falls.

The Department of Housing and Urban Development (HUD) and the Environmental Protection Agency (EPA) are funding this survey. It is being conducted by QuanTech, a contractor. An interviewer from QuanTech has delivered this letter to your home. If you were not home to receive the letter in person, the Interviewer will stop by again shortly. She or he will show you official ID and ask you some short, easy questions about you and your home. These questions will help see if your home can participate in the survey. For example, vacation homes are excluded from the study. If your home is eligible, we hope you will participate so that our results will be complete. Answering the questions is completely voluntary, and you may choose not to answer any question. Your answers will be kept confidential.

If you have any questions or if you want to speak to a study representative at any time, please call Dr. David Cox, QuanTech, at 1-800-229-5220. We thank you in advance for your cooperation.

Sincerely,

Warren Friedman

Senior Advisor to the Director

OMB No. xxxx-xxxx

expires: mm/dd/2018

U.S. DEPARTMENT OF HOUSING AND URBAN DEVELOPMENT

WASHINGTON, DC 20410-3000

OFFICE OF LEAD HAZARD CONTROL

AND HEALTHY HOMES

Control No. xxxxxxxxx

<date>

Dear Sir or Madam:

The purpose of the survey is to learn more about things in the home that can affect your health and safety. We will test for:

Lead in paint, dust and soil, that can harm young children.
Lead in your water. We will ask you to collect a water sample for this test, first thing in the morning.
Pesticides that may also be harmful to people.
Formaldehyde, found in carpets, furniture or particle board, that can cause health problems.
Mold in your home, whether you can see it or not, that can cause allergies or asthma.
Safety hazards such as carbon monoxide; smoke detectors that don’t work; electrical hazards; water that is too hot for children or the elderly; and, things that can cause trips and falls.

The Department of Housing and Urban Development (HUD) and the Environmental Protection Agency (EPA) are funding this survey. It is being conducted by QuanTech, a contractor. An interviewer from QuanTech has delivered this letter to your home. If you were not home to receive the letter in person, the Interviewer will stop by again shortly. She or he will show you official ID and ask you some short, easy questions about you and your home. These questions will help see if your home can participate in the survey. For example, vacation homes are excluded from this survey. If your home is eligible, we hope you will participate so that our results will be as complete as possible. Answering the questions is completely voluntary, and you may choose not to answer any question. Your answers will be kept confidential.

If you have any questions or if you want to speak to a study representative at any time, please call Dr. David Cox, QuanTech, at 1-800-229-5220. We thank you in advance for your cooperation.

Sincerely,

Warren Friedman

Senior Advisor to the Director

OMB No. xxxx-xxxx

expires: mm/dd/2018

U.S. DEPARTMENT OF HOUSING AND URBAN DEVELOPMENT

WASHINGTON, DC 20410-3000

OFFICE OF LEAD HAZARD CONTROL

AND HEALTHY HOMES

Control No. xxxxxxxxx

<date>

Dear Sir or Madam:

Recently, an Interviewer stopped by your home concerning the second American Healthy Homes Survey. Because you were not available, I want to tell you a little more about this public health survey, why we need your participation, and how it will benefit you.

The purpose of the survey is to learn more about how the home environment affects the health of families like yours. There is growing evidence that household exposure to substances such as lead (in paint, dust, soil and water), mold, pesticides and formaldehyde can make children and adults ill. The Department of Housing and Urban Development and the Environmental Protection Agency are jointly conducting a nationwide survey to bring us closer to understanding how our home environments affect our health.

To better understand these health issues, we need to look at all types of homes. Everyone who participates helps to increase what we know about how our home environments affect our health. Your home was in the first American Healthy Homes Survey (although you may not have lived there then), and we would like to visit it again to see how things have changed in the last 10 years.

By participating in this survey, you will receive a cash payment of $160 a report on health and safety hazards in your home and, if you choose, a report on lead paint hazards in your home (reports like these can cost hundreds of dollars).

We understand that your life is quite busy but we hope you will find the time to participate in this important study. We want to ask you a few questions about your household, collect some samples of air, water, dust and soil, and measure painted surfaces in your home. We will schedule your participation at your convenience.

All of your answers will be treated as confidential. We will use the information collected in your home for statistical research and reports only. Your answers will be combined with others, so that no one can identify which answers are yours.

If you have any questions about the study, or would like to arrange a specific time for an Interviewer to visit with you, please call Daemian Schreiber, on our survey contract team, at 1-800-229-5220. We thank you in advance for your cooperation with this important health study.

Sincerely,

Warren Friedman

Senior Advisor to the Director

OMB No. xxxx-xxxx

expires: mm/dd/2018

U.S. DEPARTMENT OF HOUSING AND URBAN DEVELOPMENT

WASHINGTON, DC 20410-3000

OFFICE OF LEAD HAZARD CONTROL

AND HEALTHY HOMES

Control No. xxxxxxxxx

<date>

Dear Sir or Madam:

To better understand these health issues, we need to look at all types of homes. We need your home. Everyone who participates helps to increase what we know about how our home environments affect our health.

Sincerely,

Warren Friedman

Senior Advisor to the Director

OMB No. xxxx-xxxx

expires: mm/dd/2018

U.S. DEPARTMENT OF HOUSING AND URBAN DEVELOPMENT

WASHINGTON, DC 20410-3000

OFFICE OF LEAD HAZARD CONTROL

AND HEALTHY HOMES

Control No. xxxxxxxxx

<date>

Dear Sir or Madam:

Recently, an Interviewer stopped by your home concerning the second American Healthy Homes Survey. I would like to tell you a little more about this public health survey, and urge you to participate. This is how it will benefit you.

You will receive a report on health and safety hazards in your home and, if you choose, a report on lead paint hazards in your home (reports like these can cost hundreds of dollars).
You will receive a cash payment of $160

We need to look at all types of homes. We need your home. Whether you have young children living with you or not, everyone who participates helps to increase what we know about how our home environments affect our health. Your home participated in the first American Healthy Homes Survey, although you may not have lived there then. We would like to visit again to see how things have changed in the last 10 years.

All of your answers will be treated as confidential. We will use the information we collect in your home for statistical research and reports only. Your answers will be combined with others, so that no one can identify which answers are yours.

If you have any questions about the study, please call Daemian Schreiber, on our survey contract team, at 1-800-229-5220. We thank you in advance for your cooperation with this important health study.

Sincerely,

Warren Friedman

Senior Advisor to the Director

OMB No. xxxx-xxxx

expires: mm/dd/2018

U.S. DEPARTMENT OF HOUSING AND URBAN DEVELOPMENT

WASHINGTON, DC 20410-3000

OFFICE OF LEAD HAZARD CONTROL

AND HEALTHY HOMES

Control No. xxxxxxxxx

<date>

Dear Sir or Madam:

You will receive a report on health and safety hazards in your home and, if you choose, a report on lead paint hazards in your home (reports like these can cost hundreds of dollars).
You will receive a cash payment of $160

Sincerely,

Warren Friedman

Senior Advisor to the Director

PSU SUMMARY SHEET

PSU ID

Dwelling units to recruit:
	X	If this box is checked Recruit all DUs with SAMP TYPE = M1, M2, M3, and M4

		If this box is checked, also recruit all DUs with SAMP TYPE = R1

		If this box is checked, also recruit all DUs with SAMP TYPE = R2

Advance Letters to Deliver by Hand
The following list of DU IDs have unacceptable mailing addresses. Deliver a hand-delivered Advance letter to these DUs if they can be located.
	New Advance Letters*		Longitudinal Advance Letters*




Other Instructions









Envelopes with: a green dot hold NEW* letters; a red dot hold longitudinal letters

G6-SUMMARY OF TESTING IN EACH DU

Staff Involved: Assigned Interviewer & Field Technician

A summary of the measurements to be conducted in each DU is provided in the Table below

Table G6-1. Estimated Division of Labor for Testing in Each DU
Onsite Time (Minutes)	Interviewer	Technician	Samples Collected
1-10	I3- Conduct Introduction and obtain Informed Consent	Participate in Introduction T2- LBP testing - Initiate minimum of 5 minute warm up of XRF.
11-15	I4- Conduct Room Inventory - Select rooms for testing - Pass copy to Technician. - Do quick walk-through with Technician to communicate agreement on the rooms to be tested. -Retrieve First Draw water sample from resident	T1- Set up and initiate collection of formaldehyde in air sample. T2 - LBP testing - test incoming drinking water service line.	Interviewer: 1 first draw water sample Technician: 1-2 formaldehyde samples - collection continues until end of interior onsite activities by the Interviewer
16-190	I5- Administer Resident Questionnaire I6- Conduct Interior Walkthrough observations, collect vacuum bag sample I7-Conduct Room Observation and Building Moisture measurements I8- Collect vacuum dust samples for fungi I9- Collect dust wipe Swiffer™ sample for fungi. I10- Collect flushed water sample	T2- Conduct LBP testing of interior rooms T3- Collect dust wipe samples for Pb T4- Collect wipe samples for pesticides T1 - Complete collection of formaldehyde in air samples when Interviewer has completed all their indoor activities.	Interviewer: 0-1 vacuum bag 1 vacuum dust 1 flushed draw water sample Technician: 10 lead dust wipe 2-3 pesticide wipe 0-6 lead soil 1 formaldehyde air
191-210	I11- Conduct Exterior Walkthrough observations – general building condition observations and exterior temperature/humidity measurements. Perform collected sample and data review - store and package samples –conduct closeout with resident	T5- Collect Soil Samples for Pb T2- Conduct LBP testing of exterior Perform collected sample and data review - store and package samples –conduct closeout with resident	Technician: 0-6 lead soil
	(offsite) Perform daily off site activities (sample and data handling)
	(offsite) Perform end-of-PSU activities (equipment, leftover supplies, data and sample shipments)
I# and T# numbers above refer to specific written protocols for conduct of the tasks.

G7 - TELEPHONE VERIFICATION OF DATA COLLECTION
Staff Involved:	Assigned QT Office Staff
Overview: A random sub-sample (10%) of the completed households will be contacted by telephone to verify the team’s activities and conduct, and to validate selected information from the data forms. Timely verification is needed to ensure that resident responses are not hampered by memory loss. Therefore, these calls will be made on a PSU basis within 2 weeks after completing testing in a PSU.
Data Recording on:		Telephone Verification Log

Procedure

1. For each PSU that is completed, place the list of the completed DUs ID numbers into an Excel spreadsheet (one per row).

2. Add a random number in an adjacent column next to each DU entry, sort the entire list by the random number, print the list, and label it Telephone Verification QC checklist.

3. Calculate the number of DUs to be checked (10%), round up to the nearest whole number, and highlight the number of DUs to be checked starting from the top of the printed list.

4. For each DU to be checked pull the file containing all the field records for that DU. If the DU selected does not have a resident telephone number, indicate this on the printed list and highlight the next available DU entry in the list as a replacement.

5. For each DU to be checked call the resident and verify the information shown on the Telephone Verification Log:

6. For each discrepancy found, involve the QA officer and conduct an investigation to determine the appropriate actions to be taken.

DU #	Date Recruited:		Date Sampled:
Resident name		Telephone No.
Caller Name		Time called:
Caller Name		Time called:
Caller Name		Time called:
Caller Name		Time called:

INTRODUCTION: Hello, my name is (INTERVIEWER NAME). I am with QuanTech, a company that is doing the American Healthy Homes Survey for the United States Department of Housing and Urban Development (HUD) and the United States Environmental Protection Agency (EPA). We are doing a follow up on a recent visit to your house by our field staff and would like to speak to (RESIDENT NAME) to ask a few questions about the survey.

IF THE RESIDENT is not available, try to find out a convenient time to return a call and record below:

______________________________________________________________________________

Q1. Do you remember to visit by our Interviewer and Technician?

YES 1

NO 2  (SKIP TO E1)

DON’T KNOW 8  (See Note below)

IF THE RESIDENT does not know, try prompting with the dates. IF the answer is still no, skip to E1

Q2. The house our staff visited was your primary residence. Is this correct?

YES 1

NO 2

Q3. Can you verify for us what year was your home/apartment visited by our staff was built?

YEAR OF CONSTRUCTION |___|___|___|___|

DON’T KNOW 8

Q4. Did you find the survey experience helpful or informative?

YES 1

NO 2

Summarize answers here: ____________________________________________

__________________________________________________________________________

Q5. Do you have any questions regarding the study?

YES 1

NO 2

Summarize questions & answers here: __________________________________

__________________________________________________________________________

---------------------------------------------------------------------------------------------------------------------------

E1. Thank you very much for your time and participation.

G8 - ISSUANCE OF PARTICIPANT REPORTS
Staff Involved:	Assigned QT Office Staff
Overview: Following the completion of data analysis, a participant report is created and mailed to the participant. There are two general types of reports: a Hazards-Found Report and a Hazards-Not-Found Report (see attached examples). Each of these general reports can contain either a Lead Hazards Report section or a Safety Hazards Report section or both (the examples contain both). Participants indicate on the Informed Consent form which of these (lead hazards and/or safety hazards) reports they which to receive and whether or not they opt out of receiving a lead hazards report. If lead hazards are found, the participant will automatically be sent at least the lead hazards portion of the Hazards-Found Report unless they specifically decline to receive the lead hazards report (see the Informed consent form). Assigned statistical staff will create a listing of relevant reporting data (by DU) with a summary of the Informed Consent responses specifying the reports to be sent. Using these listings, reports will be generated and mailed to the participants.
Data Recording on:		Informed consent tabulations from completed DUs

Examples of reports are provided on the following pages.

<DATE>

RE: American Healthy Homes Survey - Results of Lead Testing and Observation of Selected Safety Features

Dear <RESPONDENT NAME>,

Thank you for participating in the American Health Homes Survey, sponsored by the U.S. Department of Housing and Urban Development (HUD) and the U.S. Environmental Protection Agency (EPA). We conducted environmental sampling and a review of safety hazards in your home on <DATE>. You indicated at that time that you would like the results on lead.

Lead Testing Results

We tested several locations in your home for the presence of lead in paint, dust, and soil. We took measurements from these locations in randomly selected areas inside and outside of the home. Some of these tested locations had levels of lead at or above the EPA's standards for lead hazards in homes and childcare facilities. Table 1 gives the lead levels for the sampled surfaces that were found to have lead paint, dust or soil hazards. Please note that during this survey, not all rooms or all surfaces were tested.

Studies have shown that lead levels in paint chips (indicating deteriorated paint in poor condition), house dust or soil at or above the EPA’s standards are hazardous because they present an increased risk that children under six years of age could develop elevated blood lead levels (10 or more micrograms of lead per deciliter of blood). Children in this age range are more susceptible to lead poisoning than are older children or adults. This is because their bones and nervous systems are developing, and, for example, they may crawl and play on the floor or on bare soil where they may be exposed to lead dust, paint chips, or contaminated soil through normal behavior, such as putting their hands and other objects in their mouths. Also, pregnant women can transmit lead to the fetus. If this report shows the presence of deteriorated lead paint, or elevated lead levels in dust or soil, children under the age of 6 and pregnant women should see their health care provider. However, if the only lead found is in intact paint or at lower levels in dust or soil, this is not considered a hazard.

The tests we performed in your home were conducted for purposes of obtaining statistics for the nation, and do not constitute the kind of thorough assessment that you can obtain from an inspection for lead-based paint or from a lead risk assessment by a certified lead-based paint inspector or risk assessor. If you would like additional information about lead in your home, we recommend that you consider having a lead hazard inspection and/or a lead risk assessment performed. You can get a list of certified lead inspectors and risk assessors by contacting your state government

AMERICAN HEALTHY HOMES SURVEY – LEAD HAZARD RESULTS (EXAMPLE)
<Name>
<Address>
MEASUREMENTS AT OR ABOVE EPA STANDARDS
Lead at or above EPA Standard in Intact Paint (This is not considered a hazard under the EPA standard.)
Room Location	Surface Tested	Lead Level Found (milligrams of lead per square centimeter of surface)	EPA Standard for Lead-Based Paint (milligrams of lead per square centimeter of surface)
Bedroom	Wall	1.3	1.0
Kitchen	Window	2.4	1.0
Exterior North Wall	Siding	1.0	1.0
Lead at or above EPA Standard in Deteriorated Paint (This is considered a hazard under the EPA standard.)
Room Location	Surface Tested	Lead Level Found (milligrams per square centimeter of surface)	EPA Standard for Lead-Based Paint (milligrams per square centimeter of surface)
Bedroom	Wall	1.4	1.0
Kitchen	Trim	3.0	1.0
Exterior North Wall	Door	1.1	1.0
Common Living Area	Trim	2.6	1.0
Lead at or above EPA Standard in Interior Surface Dust (This is considered a hazard under the EPA standard.)
Room Location	Surface Tested	Lead Level Found (micrograms of lead per square foot of surface)	EPA Hazard Standard for Lead in Interior Surface Dust (micrograms of lead per square foot of surface)
Bedroom	Floor	63	40
Kitchen	Floor	127	40
Other Room	Window sill	255	250

Lead at or above EPA Standard in Bare Soil (This is considered a hazard under the EPA standard.)

Type of area

Location Info

Lead Level Found

(parts per million by weight)

EPA Hazard Standard for

Lead in Bare Soil in a Play Area

(parts per million by weight)

Foundation/dripline

West side of Dwelling Unit

644

400

HOME SAFETY AUDIT

Fire Extinguisher: A fire extinguisher was not located in the house.

The major causes of most fires are: cooking, heating equipment, and smoking. Fire extinguishers can guard against small fires or keep a small fire from developing into a big one. Because almost all fires are small at first, they might be contained if a fire extinguisher is handy, fully charged, and used properly. The Federal Citizens Information Center (FCIC) has stated that fire extinguishers should be installed on every level of the home, including the kitchen, basement, and garage.

Smoke Alarms: No smoke alarms were found in your home. [OR IF SMOKE ALARMS WERE PRESENT BUT NOT OPERATING PROPERLY: Several smoke alarms were found in your home, however, when tested for operability were found to be not working.]

Residential smoke alarms, when functional, can prevent 50% to 80% of deaths by providing early warning of fires, which often occur at night when people are sleeping. You should follow the manufacturer’s instructions for testing operability and battery replacement if applicable.

Fire Escapes: No observable second fire escape route (either via an additional door or an openable window) was observed from at least one room evaluated.

The U.S. Consumer Product Safety Commission (CPSC) suggests that a family fire escape plan should be practiced every six months. The plan should include at least two different escape routes from each room for each family member. Designate a safe place in front of the house or apartment building for family members to meet after escaping a fire.

Slips, Trips and Falls: Environmental risk factors may contribute to about half of all home falls. Common environmental fall hazards include tripping hazards, lack of stair railings or grab bars, slippery surfaces, unstable furniture, and poor lighting. Most fall injuries in older adults are caused by falls on the same level and from a standing height. Therefore, it makes sense to reduce home hazards and make living areas safer.

No window guards or stops were present on the windows of at least one second story or higher room.

The CPSC has stated that window guards can prevent children from falling out of windows. Guards should be installed in children’s bedrooms, parents’ bedroom, and other rooms where young children spend time. Guards must meet requirements for spacing and strength and those that allow for escape in case of emergencies must be difficult for very young children to open. Consumers can also purchase window stops, which can be added to the window frame to prevent the window from opening more than 4 inches. Some new windows come with window stops already installed.

Area rugs with skid resistant or anti-slip features were not noted in the rooms we examined during our visit.

Tripping hazards can be reduced by using non-slip rug and/or mats, including the bathtub and shower floor.

The stairways were not observed to have at least one hand rail.
Grab bars were not present in the bathroom tub of at least one bathroom.

Grab bars should be placed next to the toilet and in the tub or shower.

Emergency Numbers: No phone had poisoning or emergency numbers posted.

Posting an emergency number such as 911 and a poison control center number such as 1-800-222-1222 near all phones or in a location known to everyone who resides or spends a considerable amount of time in the house provides important information needed during an emergency.

Please call the survey team toll-free at 1-800-229-5220 if you have any questions regarding the findings above. If you are a hearing- or speech-impaired person, you may reach this phone number through TTY by calling the toll-free Federal Information Relay Service at (800) 877-8339.

Sincerely,

Dr. David C. Cox

Project Director

<DATE>

RE: American Healthy Homes Survey - Results of Lead Testing and Observation of Selected Safety Features

Dear <RESPONDENT NAME>,

Thank you for participating in the American Health Homes Survey, sponsored by the U.S. Department of Housing and Urban Development (HUD) and the U.S. Environmental Protection Agency (EPA). We conducted environmental sampling and an observation of safety features related to falls, burns and fire hazards in your home on <DATE>. You indicated at that time that you would like the results of lead sampling and observation of selected safety features. These are presented below as they were identified during our visit.

We tested several locations in your home for the presence of lead in paint, dust, and soil. We took measurements from these locations in randomly selected areas inside and outside of the home. The levels of lead in paint, dust, and soil tested were below levels considered to pose a hazard by the EPA standards for lead hazards in homes and childcare facilities. Please note that during this survey not all rooms or building materials were tested. The tests we performed in your home were conducted for purposes of obtaining statistics for the nation, and do not constitute the kind of thorough assessment that you can obtain from an inspection for lead-based paint or from a lead risk assessment by a certified lead-based paint inspector or risk assessor. If you would like additional information about lead in your home, we recommend that you consider having a lead hazard inspection and/or a lead risk assessment performed. You can get a list of certified lead inspectors and risk assessors by contacting your state government.

We made a number of observations regarding safety-related hazards and found no obvious safety hazards.

Please call the survey team toll-free at 1-800-229-5220 if you have any questions regarding the findings above. If you are a hearing- or speech-impaired person, you may reach these phone numbers through TTY by calling the toll-free Federal Information Relay Service at (800) 877-8339.

Sincerely,

Dr. David C. Cox

Project Director

I0/T0- GENERAL PROCEDURES FOR MINIMIZING CONTAMINATION
Staff Involved:	Assigned Interviewer and Field Technician
Overview: This protocol provides a general discussion on minimizing inadvertent contamination of the samples collected in the survey.

General Procedures

1. Keep equipment clean. Some of the environmental levels of interest in this survey are extremely low. Because of this, it is very easy to accidentally move measureable amounts of target analytes from one sample to the next and one location to the next. Keeping all tools and sampling supplies as clean as possible will go a long way in combating this problem. Cleaning cloths (wipes) and paper towels are provided as part of the equipment kits for use in helping you keep your equipment and re-useable items clean. Always be sure to clean sampling equipment (templates, etc.) before placing them in a carrying device like a bag, box or bucket prior to each use and keep your carrying device clean by thoroughly cleaning it daily.

2. Organize your equipment and sampling supplies. For each DU, be sure to organize your equipment and supplies so that they can be retrieved with a minimum of handling and without touching other surfaces.

3. Nitrile Glove use. Gloves are used throughout the field collection efforts to accomplish two equally important major objectives. One is to protect collected samples from inadvertent contamination. The other is to protect the user from being contaminated by the materials used to collect sample as well as the sample material itself.

For each field sampling protocol, be sure to think through the various steps to be done before pulling on gloves and only do so when it is prudent. The are some activities, like handling sample labels, that are difficult to do while wearing gloves and you should take care of these, if possible, before donning gloves. In addition, there will likely be other activities other than collecting samples, where you should be wearing gloves so that you avoid cross-contamination issues such as when cleaning sampling templates. Also, it is extremely difficult to pull on nitrile gloves with wet hands so be sure you hands are completely dry before doing so.

For most sample collections, but not all, there are two options with regard to glove use. One is to pull on new gloves to collect the sample. The other is to use existing gloves already being worn and clean them using a cleaning wipe between collections of like-type samples (for example, the same gloves can be used to collect all 6 targeted soil samples as long as you clean them between samples). Whenever gloves are cleaned rather than replaced, be sure to wipe off gloves twice using two cleaning wipes between each pair of samples collected, tossing the used cleaning wipes into the trash. Whenever a protocol is changed to collect a new type of sample, always pull on a new pair of gloves and toss any used gloves currently being worn into the trash. Please note that when collecting pesticide samples (T4), always don a new pair of gloves between the samples collected in a single DU (do not clean them between samples for this target analyte).

4. Clean reusable templates and measuring tools between uses. Always do this cleaning immediately after collecting a sample so that the tools will be dry when needed for the next sample. A paper towel can be used to help dry tools if required for any sample other than formaldehyde. Since paper towels are known to potentially contain a small amount of formaldehyde, they should not be used for cleaning any tools or materials used for this sample collection (T1).

5. Discard cleaning cloths after a single use. Never reuse a cleaning cloth.

6. Clean tools and sampling supplies whenever contamination is suspected.

7. Discard, without use, any cleaning cloth that has been uncovered for more than a few minutes, or that is otherwise suspected of being contaminated.

I2- RECRUITMENT SCREENING
Staff Involved:	Assigned Interviewer
Overview: For each PSU, the Interviewer is sent a Recruiting Supplies - Kit (A) containing an AHHS Main and reserve sample DU addresses listing. This listing contains information on what dwelling units have been drawn as a sample for potential recruitment in the study. However, not all the DUs in this list are targeted for recruitment. Information on which DUs are to be recruited is summarized in the PSU Summary Sheet. The Interviewer is instructed to contact, screen, and recruit all DUs that are released as directed by the PSU Summary Sheet. Four types of Advance Letters have been created to aid in recruiting: an Advance Letter, a Hand-Delivered Advance Letter, a Modified Advance Letter, and a Generic Advance Letter. A $1 token cash incentive is included in the official HUD envelope with the Advance Letter. Examples of the Advance Letter and Hand-Delivered Advance Letter are provided in protocol G2. QuanTech headquarters (QT) will mail the Advance Letter to each targeted dwelling unit address that has a valid mailing address about one week before the Interviewer arrives in the PSU. In cases where there is no proper mailing address, a Hand-Delivered Advance Letter will be dropped off when the Interviewer attempts to recruit the housing unit. DUs with no proper mailing address will be indicated on the PSU Summary Sheet. The Modified Advance Letter is used to indicate that an unsuccessful contact visit has been made to a unit. It is left on the doorknob in a clear hanger bag. The Generic Advance Letter is left flat and sealed in plastic as a reference to the other letters to show to the resident when contact is made. At least four attempts will be made to contact each of the DUs released to the Interviewer, until contact is established. Attempts will made at varying times of the day and on different days of the week. For example, if the first attempt during normal working hours is unsuccessful, the second attempt will be made in the evening. If weekday attempts fail, additional attempts will be made on the weekend. Generally, the first attempted contact will be made during the day, with subsequent contacts made in the evenings and weekends. If four attempts to contact a resident at a selected DU are unsuccessful, the Interviewer should make other attempts when in the area such as when testing other nearby DUs. If this fails to make a contact, the Interviewer will notify QT for further instructions. For DUs that are impossible to reach, e.g., some gated communities and apartment buildings with doormen, the Interviewer will contact QT and QT will send a No Contact Letter by Priority Mail (see letter at end of protocol G2). The No Contact Letter elaborates on the importance of the survey and the incentives for participation and provides a toll-free number to call to schedule a visit. In cases of “hard” refusal, QT will send a Refusal Letter, again by Priority Mail. The Refusal Letter also elaborates on the importance of the survey and the incentives for participation and provides a toll-free number to call to schedule a visit.
Data Recording on:		Interviewer Form Set pulled from Kit (B)
Equipment Needed from Kit (A)
1 cell phone and power cable. 1 checkbook for writing the $160 checks to residents (sent to first PSU for a given Interviewer) 18 Recruiting Questionnaire Form Sets. 1 clipboard 1-3 blue ink pens 1 roll Clear Packing Tape 1 copy of FAQs (bound) 18 copies of each of the various advance letters plus 18 plastic door knob hangers				1 Envelope/folder (nominally labeled "DU Listings") containing: 1 completed PSU Summary Sheet 1 sealed Hand-Delivered Advance Letter for each DU listed in the PSU Summary Sheet 1 AHHS Main and Reserve Sample DU addresses list (for the PSU) 18 Appointment Reminder Cards (loose) 2 Scheduling Calendar Forms (loose)
Items Needed from Drinking Water Shipper - Kit (E1)
1 1st-draw water sample bottle for each DU scheduled to be visited on the following day. [Interviewers may wish to place the entire Kit (E1) box containing the first-draw water sample bottles in their car so these bottles are readily available to them as needed.] These bottles all have a large sticker on them containing detailed instructions on how to collect the sample.
Glove Use Directives:			none (see protocol I0)

Procedure

1. Complete any needed travel planning using the Recruiting Supplies.

2. Pack Auto with Needed Supplies. Gather the items needed for recruiting, as shown at the beginning of this protocol, and securely store them in your automobile. It is generally recommended that you place the entire Recruiting Supplies - Kit (A) into your automobile for use in recruiting.

3. Conduct Recruiting and Safely Store Recruiting Questionnaire Form Set. At each DU, conduct the recruitment screening using the Recruiting Questionnaire Form Sets in the Recruiting Supplies - Kit (A). Forms are shown at end of this protocol. Use the Scheduling Calendar to keep track of the appointment dates for testing. Attempt to make contact and recruit the DU, keeping track of the effort using the Appointment Control Log and In-Person Contact Record. At least four attempts must be made to contact each of the DUs released to the Interviewer. Attempts will be made at varying times of the day and on different days of the week. Once contact is made, attempt to recruit the DU using the Recruiting Questionnaire Form Set. For DUs successfully recruited, record the contact information and telephone numbers on the cover page of the Recruiting Questionnaire Form Set. Include the following actions when recruiting:

4. Using the Recruiting Questionnaire Form Set.

4.1 Use a different form set for each DU released for recruiting. Place the needed form set in the clipboard on top of the Scheduling Calendar (4.3 below) for use at a given DU.

4.2 Complete the Cover Sheet. The DU ID to be used by the Interviewer and Technician combines 3 data fields shown on the AHHS main and reserve sample DU addresses list, and has the following format:

XXX-YYY-ZZ

Where XXX is the PSU ID identifier from the AHHS Main and reserve sample DU addresses list identifier; a number from 101 to 999

YYY is the AHHS SEGID identifier; a number from 001 to 999

ZZ is the SAMP TYPE identifier from the AHHS Main and reserve sample DU addresses list identifier, M1, M2, M3, or M4 for main sample draw and R1 or R2 for reserve sample draw.

4.2.1 Use the Appointment Control Log to keep track of the required 4 recruiting attempts at a DU.

4.2.2 Schedule testing after successful recruiting. Record on the Appointment Reminder Card the scheduled testing day recorded in the Recruiting Questionnaire Form Set (line S8). Hand it to the resident as a reminder of the testing appointment.

4.3 Use a Scheduling Calendar Form to track the DU testing schedule. These forms are provided loose as a tool to keep track of testing schedules for recruited DUs. It is recommended that the Calendar Form be kept in Recruiting Supplies Kit (A) on the clipboard so it will always be available at each location as this kit is to travel with the Interviewer at all times while recruiting and testing. Remember that no DUs can be tested until the Technician arrives at the PSU. If you do not know when the technician is to arrive at the PSU, contact QT for that information so you can do your recruiting and scheduling.

4.3 For each DU that is recruited, safely store the completed Recruiting Questionnaire Form Set in the Recruiting Supplies - Kit (A). This form set will be sent back to QT with samples and other data collected during the testing phase of the work. It is recommended that the Recruiting Supplies - Kit (A) be kept with you at all times during both recruiting and testing. When testing for the DU is conducted, the completed Recruiting Questionnaire Form Set is moved from the Recruiting Supplies - Kit (A) to the Sampling Supplies - Kit (B) box used for testing in that DU.

4.4 For each DU that refuses, complete the applicable entries in the refusal/breakoff section of the Recruiting Questionnaire, safely store the completed Recruiting Questionnaire Form Set and other collected data back in the Recruiting Supplies Kit (A), and contact QT with the results no later than the end of the day as described in step (6) below.

4.5 At the door activities:

4.5.1 For 1st visits to the DU

4.5.1.1 If the resident is there, introduce yourself, show them you ID badge and hand them the Hand Delivered Advance Letter provided in the Recruiting Supplies Kit (A) and ask them to open and read it. Then continue on with recruiting.

4.5.1.2 If the resident is not there, place the Hand Delivered Advance Letter on the doorknob of the primary entryway of the DU using the provided clear plastic doorknob hanger bag.

4.5.2 For 2nd visits to the DU

4.5.2.1 If the resident is there, introduce yourself, show them you ID badge and show them the plastic encased Modified Advance letter (if needed) and continue on with recruiting. Be sure to retrieve the plastic encased Modified Advance letter from the resident, as it will be needed at other DUs.

4.5.2.2 If the resident is not there, but the Hand Delivered Advance Letter has been picked up, place a Modified Advance Letter on the doorknob of the primary entryway of the DU using the provided clear plastic doorknob hanger bag.

4.5.3 For 3rd and later visits to the DU

4.5.3.1 If the resident is there, follow instructions in step 4.5.2.1.

4.5.3.2 If the resident is not there, come back at another time. Don’t leave another Modified Advance Letter on 3^rd and later visits.

4.5.4 For the LAST visit to the DU

4.5.4.1 If the resident is there, follow instructions in step 4.5.2.1.

4.5.4.2 If the resident is not there, try to get a proper mailing address for the unit (if not known already) and contact QT. QT will send out a No Contact Letter to the address.

4.6 Hard refusals. If the resident refuses to complete the recruitment screening, or refuses the sampling visit after the DU is determined eligible, and conversion efforts fail, contact QT. A Refusal Letter will be sent by Federal Express.

5. Communicate Project Status to QT. Periodically (every other day or so), QT will call the Interviewer to obtain status information. If the Interviewer has not heard from QT in more than 3 days, the Interviewer is asked to call QT and provide a brief verbal report on the recruiting efforts from the previous day, and any other study needs. Note that this call will need to be placed while viewing the information stored in the Recruiting Supplies Kit (A). Items to be communicated include the following:

5.1 DU Recruiting and Testing Info

5.1.1 Which released DUs have been recruited?

5.1.2 Which released DUs were: recruited? Found ineligible? Could not be contacted?, Refused-Why?, Completed-When?

5.1.3 What are the scheduled testing dates for the recruited DUs?

5.1.4 Who will the incentive check be made out to?

5.2 DU Data/Samples Shipped from Field

5.2.1 What FedEx shipments were sent yesterday (record tracking number)?

5.3 DU Data has been transmitted by email from Field

5.3.1 What files were sent since the last verbal report?

5.4 Travel Arrangements

5.4.1 What travel arrangements (airfare, lodging, auto) are needed for Interviewer?

5.4.2 What travel arrangements (airfare, lodging, auto) are needed for Technician?

5.5 Supplies and Other Needs

5.5.1 What additional supplies are needed and by when?

5.5.2 What are the other needs?

Cover Sheet for Recruiting Questionnaire Form Set

Dwelling Unit ID:
		PSUID - AHHS SEGID - SAMP TYPE
DU Address And Contact Telephone Numbers (if available)










Assigned Interviewer

	Check here if a neighbor was used to the obtain any contact information recorded in this form set and place the name and contact phone number for that neighbor below:

**Note all fields to be completed by Interviewer

Interviewer Name _______________________________							PSU ID_____________________
MINIMUM 4 IN-PERSON ATTEMPTS ON DIFFERENT DAYS AT DIFFERENT TIMES
RECORD ALL ATTEMPTS/VISITS INCLUDING THE DATA COLLECTION APPOINTMENT VISIT
RECORD OF CONTACTS
		Day of		Result
	Date	the Week	Time	Code		Comments (Appointment)
1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

11.

12.

13.

14.

15.

In-Person Result Codes					Telephone Result Codes
P1 = No one home					T1 = Ring, no answer
P2 = Vacant					T2 = Wrong number
P3 = Would not answer door					T3 = Language problem
P4 = No adult home					T4 = Callback needed
P5 = Language problem					T5 = Appointment scheduled
P6 = Refusal					T6 = Appointment rescheduled
P7 = Breakoff/Friendly/Revisit					T7 = Appointment confirmed/ call completed successfully
P8 = Breakoff					T8 = Refusal to allow inspection
P9 = Completed resident questionnaire & sample collection					T9 = Other (specify) ________________________________________
P10 = Not eligible
P11 = Other (specify) _________________________
P12 = Completed Recruitment

DU ID:___________________ Interviewer Name: ___________________ Date: ____ / ____ / ______

Time Begun: _____________ ( AM / PM ) Final Result Code: ________________________________

U.S. DEPARTMENT OF HOUSING AND URBAN DEVELOPMENT

AMERICAN HEALTHY HOMES SURVEY II

RECRUITING QUESTIONNAIRE

BOX A

INTERVIEWER: BEFORE ATTEMPTING TO CONTACT RESIDENT

1. VERIFY THAT THE DU ADDRESS IS THE SAME AS THAT SHOWN ON THE COVER SHEET FOR RECRUITING QUESTIONNAIRE SET

YES, ADDRESS SAME 1

NO, ADDRESS NOT SAME 2  (CALL QUANTECH OFFICE)

UNKNOWN, CAN’T TELL FROM OUTSIDE 8

2. VERIFY HOUSING UNIT STATUS:

BUSINESS 1  CODE RESULT P10 & SKIP TO R1

VACANT 2  CODE RESULT P10 & SKIP TO R1

ELDERLY HOUSING (NO CHILDREN

ALLOWED TO LIVE THERE) 3  CODE RESULT P10 & SKIP TO R1

INSTITUTIONAL GROUP HOUSING

(PRISON, HOSPITAL, ETC.) 4  CODE RESULT P10 & SKIP TO R1

OTHER GROUP HOUSING

(DORMITORY, CONVENT, ETC.) 5  CODE RESULT P10 & SKIP TO R1

NONE OF THE ABOVE 6  CONTINUE

3. RECORD TYPE OF DWELLING:

DETACHED SINGLE FAMILY HOUSE 1

DUPLEX/TRIPLEX 2

ROW HOUSE/TOWN HOUSE 3

LOW RISE APARTMENT (1-3 FLOORS) 4

HIGH RISE APARTMENT (>3 FLOORS) 5

MOBILE/MANUFACTURED HOME 6

OTHER 7

(SPECIFY: _________________________________________________________)

ATTEMPT TO CONTACT A RESIDENT WHO IS 18 YEARS OR OLDER. PROCEED WITH BOX B.

IF YOU WERE NEVER ABLE TO CONTACT ANY RESIDENT, GO TO BOX E.

IF THE RESIDENT HAS ANY COMMUNICATION PROBLEM (E.G., AUDITORY OR VISUAL DISABILITY, OR SPEAKS A LANGUAGE OTHER THAN ENGLISH), ASK TO SPEAK WITH ANOTHER ADULT IN THE HOUSEHOLD. IF NOT, ASK PERMISSION TO GET A NEIGHBOR OR NEARBY FRIEND OR RELATIVE TO ASSIST WITH THE QUESTIONNAIRE.

IF RESIDENT REQUESTS THAT YOU CALL THE OWNER OF THE DU, RECORD NAME, ADDRESS AND PHONE NUMBER OF OWNER, ON CONTACT RECORD AND CALL YOUR SUPERVISOR. DO NOT PROCEED WITH SCREENING AT THIS TIME.

INTRODUCTION: Hello, my name is (INTERVIEWER NAME). I am with QuanTech, a company that is doing housing research for the United States Department of Housing and Urban Development (HUD) and the United States Environmental Protection Agency (EPA). You may have received an official letter like this from HUD a week or so ago.

[SHOW ID CARD AND HAND COPY OF THE APPROPRIATE ADVANCE LETTER TO RESPONDENT]

As this letter says, we are conducting a national study of lead and other substances that can affect people’s health. Your home was randomly selected to represent thousands of homes like yours across the country. If your home is eligible, and you agree to participate, you will be paid $160 for your participation when we complete work in your home. We want to ask you some questions, test paint and water for lead, and do other environmental testing. We will not damage anything in your home.

We will use the information collected in your home for scientific research and reports only. Your answers will be combined with others, so that no one can identify which answers are yours. No one outside the study will have access to information you provide.

We would very much appreciate your help with this important study. My purpose today is to see if your home is eligible and to schedule an appointment.

(ANSWER ANY QUESTIONS THE RESPONDENT MAY HAVE CONCERNING THE STUDY.)

First, I would like to ask you a few personal questions to see if your home is eligible for the study. You don’t have to answer any question you don’t want to answer. Your information will only be used for the purposes of this study. Do I have your permission to ask some questions?

YES 1

NO 2  (CODE P6, SKIP TO R1, END)

S1. Is this your primary residence?

YES 1  (SKIP TO S3)

NO 2

S2. On average, how many weeks or months per year do you spend in this home?

TWO WEEKS OR LESS 1  (CODE P10, SKIP to R1, END)

MORE THAN 2 WEEKS TO ONE MONTH 2  (CODE P10, SKIP to R1, END)

MORE THAN 1 MONTH TO 3 MONTHS 3  (CODE P10, SKIP to R1, END)

MORE THAN THREE MONTHS 4

S3. Are children allowed to live here?

YES 1  (SKIP TO S5)

NO 2

DON’T KNOW 8  (SKIP TO S5)

S4. Could you please describe to me why children are not permitted to live here? [PROBE: Are there any rules/regulations prohibiting children to live here?]

DORMITORY 1

RETIREMENT COMMUNITY 2

OTHER 3

(SPECIFY: _______________________________________________________)

IF RULES OR REGULATIONS PROHIBIT CHILDREN FROM LIVING HERE, CODE RESULT AS P10,

SKIP TO R1 AND END. IF IT IS ONLY THE INFORMAL WISH OF THE OCCUPANT THAT CHILDREN

SHOULD NOT BE PERMITTED TO LIVE HERE, CONTINUE WITH S5.

S5. Do 9 or more people live here who are not related to the householder?

YES 1  (SKIP TO R1, END)

NO. 2

REFUSE 7  (SKIP TO R1, END)

S6. Do you share kitchen facilities with people who do not live with you?

YES 1  (SKIP TO R1, END)

NO 2

S7. Your home is eligible for the study! I would like to make an appointment for an associate and myself to visit you next week to do some environmental testing. We would need about 3 and one-half hours to do the testing. We will of course schedule our visit at a time that is convenient for you next week. We will give you $160 to compensate for any inconvenience and as a thank-you for your participation when our work is complete.

AGREES 1

REFUSES 2  (CODE P6, SKIP TO R1, END)

S8. What would be a good day and time for you next week?

_____________________ _____ / _____ / _____ at ____________ (AM/PM)

DAY OF WEEK DATE TIME

(USE YOUR APPOINTMENT CALENDAR. TRY TO SCHEDULE FOR NEXT WEEK. TELL THE RESPONDENT THAT YOU WORK WEEKENDS. IF THE PERSON WOULD LIKE YOU TO TAKE SAMPLES RIGHT AWAY, EXPLAIN THAT THE TECHNICIAN WILL ARRIVE NEXT WEEK AND YOU CANNOT PROCEED WITHOUT HIM/HER.)

S9. When we come back, should we ask for you or for someone else?

SELF 1

OTHER HOUSEHOLD MEMBER 2

OTHER 3

(SPECIFY _______________________________________________________)

S10. Could I please have your/that person’s name and telephone number, so that we can confirm our appointment?

NAME OF CONTACT PERSON: _________________________________________________________

FIRST LAST

TELEPHONE NUMBER: ( ) _______ - ____________ (H)

( ) _______ - ____________ (W)

( ) _______ - ____________ (Cell)

Check if no telephone: ________

S11. We will bring the $160 check with us. Who should we make it out to?

NAME OF PERSON: ___________________________________________________________________

FIRST LAST

To help us plan our visit next week, we need to ask you one quick question about your home.

S12. When was this house built? Was it built . . .

1990 TO PRESENT 1

BETWEEN 1978 AND 1989 2

BETWEEN 1960 AND 1977 3

BETWEEN 1946 AND 1959 4

BETWEEN 1940 AND 1945 5

1939 OR BEFORE 6

DON’T KNOW 8

INTERVIEWER SHOULD PROBE FOR DATE RANGE IF RESPONDENT IS UNCERTAIN

S13. Thank you very much for your time and participation. We are looking forward to collecting data in your home on (SEE S8)

There are two small things we would like you do to help us when we come back. Between now and then, please do not clean the floors in your home, and please do not change your vacuum cleaner bag. Also, we will need you to collect a sample of your drinking water first thing in the morning on [DAY OF APPOINTMENT]. This is very simple - just fill a special bottle from the cold water tap in your kitchen. We will drop off the bottle and instructions the day before our visit.

[Must obtain Verbal Consent for water collection, as this is a study-related procedure being conducted prior to obtaining written consent]: Do you agree to collect a sample of your drinking water first thing in the morning on [DAY OF APPOINTMENT]?

YES 1

NO 2

BOX D

COMPLETE THE APPOINTMENT REMINDER CARD (DATE, TIME, YOUR NAME AND TELEPHONE NUMBER.) ANSWER QUESTIONS ABOUT CLEANING FLOORS OR CHANGING THE VACUUM CLEANER BAG. GIVE CARD TO THE RESPONDENT. COMPLETE THE CONTACT RECORD - INCLUDE THE APPOINTMENT INFORMATION, THE NAME OF THE CURRENT RESPONDENT, AND THE NAME (IF DIFFERENT) OF THE PERSON WHO WILL ASSIST YOU DURING THE DATA COLLECTION VISIT.

COMPLETE BOX E ON LAST PAGE OF QUESTIONNAIRE.

R1. I am sorry, but your home is not eligible for this study. Thank you very much.

END INTERVIEW

BOX E

INTERVIEWER: COMPLETE THIS BOX FOR ALL HOUSING UNITS RELEASED FOR RECRUITMENT

(INCLUDING THOSE THAT YOU RECRUITED FOR THE STUDY.)

E1. DID YOU EVER SEE ANY ONE IN THE SAMPLED HOUSING UNIT?

YES 1

NO 2  (CIRCLE 8 IN E2, E3, E4)

E2. (OBSERVATION ONLY) MY IMPRESSION OF THE RESPONDENT’S FAMILY INCOME IS…?

APPARENTLY NOT IN POVERTY 1

APPARENTLY IN POVERTY 2

UNABLE TO DETERMINE 8

E3. (OBSERVATION ONLY) MY IMPRESSION OF THE RESPONDENT’S RACE IS:

WHITE 1

BLACK OR AFRICAN AMERICAN 2

ASIAN 3

NATIVE HAWAIIAN OR OTHER PACIFIC

ISLANDER 4

AMERICAN INDIAN OR ALASKAN NATIVE 5

OTHER 6

UNABLE TO DETERMINE 8

E4. (OBSERVATION ONLY) MY IMPRESSION OF THE RESPONDENT’S ETHNICITY IS:

HISPANIC OR LATINO 1

NOT-HISPANIC OR LATINO 2

UNABLE TO DETERMINE 8

TIME ENDED: ______________ (AM/PM)

APPOINTMENT REMINDER CARD

American Healthy Homes Survey II

The QuanTech Team (Interviewer and Technician) will visit your home and collect environmental samples on

_________________ _______________ __________ (AM/PM).

DAY OF WEEK DATE TIME

In addition, on the day before this date, the Interviewer will drop off a plastic bottle for you to collect a cold-water sample on the date shown above before anyone in your home uses any water. Instructions are on the bottle.

We would like you or another adult member of your household to

be available to answer our questions and assist us. If you have any

questions about the study please call:

1-800-229-5220

Interviewer Name: ______________________________________

Telephone Number: (_______) ____________________

If you are a hearing- or speech-impaired person, you may reach these phone numbers

through TTY by calling the toll-free

Federal Information Relay Service at (800) 877-8339.

Before the visit to your home by our research team, we ask that you

do not vacuum, clean, or wipe the floors

for at least two days prior to our appointment.

To thank you for your time, we will give you a check for $160 when

we have completed the data collection for your home.

We appreciate your cooperation.

Scheduling Calendar (for field use) for Month of _________________________
PSU ID: _____________ Interviewer Name: ______________________

	Day	Abrev	Recruiting Notes
W E E K 1






	Day	Abrev	DU ID scheduled in AM	DU ID scheduled in PM
W E E K 2






W E E K 3

Collection of Drinking Water Samples

Figure I2-1 directs the resident to collect this sample as shown below. The collection bottle with instructions for the resident will be dropped off at least 2 days prior to the visit by the 2-person field team and will be followed up, as needed, with a call to the resident to remind them to collect the water sample prior to the day when the visit is to take place. The resident will be asked to collect a small portion (100-150 ml) each time they use the kitchen faucet for drinking or cooking. In cases where the water collection by the resident was not completed, the Interviewer will collect a flushed draw sample and document such collection.

Figure I2-1 - Bottle label for the drinking water sample (shown as actual size). This instruction set for collection by resident is formatted to fit on an Avery 60522 waterproof label (excess length to be cut off before the label is placed on the bottle; 1 liter bottles are roughly 7.5" tall and 3.5" in diameter). A positioning tool will be used to place the bottom of the sticker slightly less than 1 inches up from the bottom of the bottle. This will ensure that each filling to each successive lowest fill line will result in collection of about 113 ml. Filling to the top most fill line will result in collection of about 900 ml.

AMERICAN HEALTHY HOMES SURVEY II - FAQs

NOTE: These FAQs are intended for the guidance of the Interviewers in

fielding questions and they are not given to the respondents.

1.0 SURVEY BACKGROUND

1.1 What is the survey about?

The purpose of the survey is to find out how much lead and other substances that can affect people’s health are in American homes. Exposure to certain levels of lead can be hazardous, specifically to our children. This nationwide survey is sponsored by the U.S. Department of Housing and Urban Development (HUD) and the U.S. Environmental Protection Agency. It is authorized by Public Laws 102-550 and 99-158.

1.2 What is the authority/sponsor for this study?

The U.S. Department of Housing and Urban Development has contracted QuanTech, Inc. to conduct this national study.

(If a respondent would like to speak with someone at HUD, he/she can call Dr. Warren Friedman at HUD at (202)402-7574, during business hours, Eastern Time, Monday through Friday. In addition, the respondent may call QuanTech toll free at 1-800-229-5220. Make an appointment or call to visit the respondent in two (2) days. Record the situation on the control log. Make certain that the respondent has your name, QuanTech’s name, and the name of the study.)

According to the Paperwork Reduction Act of 1995, no persons are required to respond to a collection of information unless it displays a valid OMB control number. The valid OMB control number for this information collection is ****. The time required to complete this visit is estimated to be about three and a half hours, including the time for answering your questions, asking you questions and collecting the environmental samples.

1.3 How will HUD use the information from this survey?

It will be used to assess levels of lead, mold, and other potential hazards found in the Nation’s housing and to identify the associated potential risks. It will also be used to develop guidelines for providing a hazard-free environment for our children and improving the Nation’s health.

1.4 Do I have to do this?

Do I have to answer your questions?

Your participation is entirely voluntary, but very important to the success of this survey. In order for the results to be valid, it is important that everyone who is selected agrees to participate.

1.5 What is QuanTech?

Who do you work for?

QuanTech is a research company in Maryland that has conducted statistical studies for the U.S. Government since 1989. HUD chose QuanTech to help them conduct this survey. All the Survey Interviewers and Technicians are hired and professionally trained by QuanTech.

1.6 How will I recognize the Interviewer and Technician?

The Interviewer and Technician will be wearing a QuanTech identification badge that looks like this: (DISPLAY SAMPLE BADGE)

1.7 What if I have other questions?

If you have questions about the survey you may call the Project Director, Dr. David Cox, at QuanTech’s toll-free number (800)229-5220 between 9 am and 5 pm EST. After business hours and on weekends, please leave a message and Dr. Cox will return your call.

1.8 Are you selling a lead abatement service?

What are you selling?

Will you fix any problems you find?

QuanTech is only conducting a SURVEY of lead and other things that can affect people’s health and safety. We are not selling anything. We do not offer a lead abatement service or any other service to correct hazards we find. We also do not offer a referral service nor do we recommend any contractors to correct hazards we find. We do provide you with a copy of some current government information regarding the substances we are studying.

2.0 LEAD

2.1 Is this like the lead inspection I got when I bought my home?

Most likely this is not like the one you got when you bought this house. We will not only be looking for exposed lead paint, but we will be looking at lead in the dust in your house and in the soil outside. Moreover, the findings of this study will be used to determine the number of homes in America with lead based paint hazards.

2.2 What are the sources of lead in house dust?

Any painted or varnished surfaces including:

Walls

Windows

Ceilings

Doors

Floors

and

Soil

Some occupations and hobbies.

2.3 What happens if you find lead in my home?

If lead paint or hazardous levels of lead are found in your home, you will be notified so you can decide whether to take action. We can also advise you of options to further evaluate the possible health risk. However, most houses do not contain hazardous levels of lead.

2.4 Don’t we know all about lead and its effects on children?

Not really. Ten years ago, HUD did a comprehensive study of lead in American homes. That study told them how big the problem was. Since then HUD has operated many programs to raise awareness of the problem and to start to fix it. Therefore, one goal of this study is to see if the lead problem in homes has changed in the last 10 years.

Also, this survey looks at more than just lead. We don’t know how common many of the things we are testing for actually are in homes around the country. The information we gather will be used to develop guidelines for reducing hazards in our homes.

2.5 Are you going to test my water for lead?

Yes. We will ask you to collect a "first draw" from one of your faucets first thing in the morning. We will pick up the sample from you when we arrive. We will also collect a second water sample during our visit.

3.0 OTHER SUBSTANCES & TESTING

3.1 Why are you testing for pesticides?

There are limited national estimates on how much common pesticides are used in homes. If your home is selected for testing of pesticides, we will take wipe samples in the kitchen.

3.2 Why are you testing for formaldehyde?

Formaldehyde can irritate eyes, nose and throat and can aggravate asthma symptoms. Some studies have shown a possible link between formaldehyde and some cancers, such as leukemia. Formaldehyde is used in building materials, furniture and many household products, such as air fresheners. We will take a sample of the air in your home using a pump, and we will measure the amount of formaldehyde in it.

3.3 What safety hazards will you look for in my home?

We will check your home for:

Fire extinguishers

Smoke alarms and whether they work

Carbon monoxide detectors and whether they work

Fire escapes

Potential for slips, trips and falls

Damaged electrical wiring

High hot water temperature that may be. dangerous to children and the elderly

Posting of emergency phone numbers

4.0 SAMPLING

4.1 How was my household selected?

We would like to interview and collect environmental samples from every home in America, but it would be far too expensive. Instead, we randomly select household addresses to represent the total population. During the next few months, we will visit 58 communities to gather information from about 600 homes. Because your household represents many others throughout the country, your participation is very important. While your participation is voluntary, because we scientifically selected your household, we cannot substitute another household for yours if you do not participate.

4.2 Why don’t you go to another house?

All the houses we go to are scientifically selected to represent a certain type of housing in the United States. Because your home represents many others throughout the Nation, your participation is very important. We very much hope that you will participate. While your participation is voluntary, we will not be able to substitute another household for yours if you do not participate.

4.3 Are you going to my neighbor’s house too?

Answer YES or NO, depending on how the draw came out.

5.0 CONFIDENTIALITY

5.1 How do I know my answers will be kept confidential?

QuanTech is the only organization that will have access to information that ties your name and residence to data collected at your home as part of this study. Neither HUD nor EPA will receive ANY information that can tie your data to your name or residence. The survey results will be published in reports and scientific journals. All publications will use summary data, in other words averages and group totals.

6.0 PROTOCOL

6.1 How much time will it take?

Why is it going to take 3 and a half hours?

The initial visit will take about 5 minutes. If your house is eligible for the study, we will schedule a 3 and 1/2 hour visit at your convenience. During that time we will perform the following activities:

Answer all your questions,

Ask you some questions about your household,

Collect dust samples from selected rooms,

Collect a water sample and pick up one you collect for us,

Take a sample of the air in your home using a pump,

Look for common household safety devices in use (such as smoke detectors)

Check for safety hazards such as frayed electrical wiring and the danger of falls,

Measure things like temperature and humidity,

Measure painted surfaces without damaging the paint, and

Collect samples of soil.

6.2 Are you going to test every room in my house?

No. We will definitely test your kitchen, any play room (common living area) where children spend a lot of time, one bedroom, and a basement if you have one. We will also randomly select one other room, depending on the size of your home.

6.3 What will you be testing for and how will you test for them?

Our primary focus will be on lead in paint, dust and water in your house. We will also be testing for mold, formaldehyde and (in some homes) pesticides. We have a special monitor that can measure the amount of lead without damaging your walls. Finally, we will do a quick look around outside and collect some soil samples.

6.4 What kinds of questions will you be asking?

The questionnaire asks questions about the house or apartment, such as age, number of stories, type of heating and air conditioning, etc. There are also questions about the number of people in the household, the presence of allergies or asthma in any household members, and any hobbies or occupations that are related to lead or substances that cause allergies.

6.5 What does the environmental sampling involve?

What will you do in/to my home?

We will collect samples of house dust from small areas of your floors and windows. We will also collect small soil samples from outside if you have a yard. We will collect a sample of air using a pump. We will ask you to collect a water sample first thing in the morning and we will collect an additional sample during our visit. The Technician will measure lead in painted surfaces without damaging the paint.

6.6 Why can’t I clean my floors before your visit?

We will be collecting samples of dust from your floors. These samples will be sent to laboratories to be analyzed for lead, mold or pesticides. If you clean just before our visit there might not be enough dust for the laboratories.

6.7 Why do you want a used vacuum cleaner bag?

Some of the tests we are performing need large amounts of dust. These tests are looking at the presence of specific chemicals and molds throughout the home and so location is not important. However, other tests we are performing are meant to identify specific chemicals and mold in places where they are most likely to be located and so we are using dust wipes and vacuum sample collection for these tests.

6.8 Why are you wearing gloves to collect certain samples?

We are wearing gloves so as not to get oil or dirt from our hands on the sample itself. The samples we are taking are not harmful to us, but we could contaminate the sample.

6.9 Do I have to be here with you the entire time?

Why?

We’d be happy to schedule the appointment at a convenient time for you, but WE CAN’T BE IN YOUR HOME WITHOUT YOU. Our liability insurance doesn’t allow us to do that.

6.10 Will you damage any part of my home?

No part of your home will be damaged. We will collect dust samples using a wipe or vacuum technique that will not hurt surfaces. We will test paint using a detector that measures lead without damaging the painted surface. We will collect a few small samples of soil in your yard. We will take these samples in an area where the soil is bare, if possible. If not, we will remove the soil covering in about a two-inch diameter (circle) (e.g. grass or mulch).

6.11 What does the 3-and-a-half-hour time estimate include?

Explaining the survey, answering any questions you may have, interviewing you, taking samples and doing the safety check, collecting all our equipment, and checking we have everything before we leave.

6.12 If I have suggestions on how to improve this study, whom should I contact?

Director, Office of Lead Hazard Control and Healthy Homes, U.S. Department of Housing and Urban Development, 451 Seventh Street, S.W., Washington, D.C. 20410; and the Office of Information and Regulatory Affairs, Office of Management and Budget, Washington, D.C. 20503.

6.13 If I want to tell somebody that the time estimate was incorrect, whom should I contact?

7.0 RESULTS

7.1 How will the results be published?

The survey results will be published as group totals and as statistical summaries. Names and addresses will not be published, nor will any other published information identify you.

7.2 How will the survey results be used?

What will you do with this information?

We will write a report for the federal government describing the results of the survey, and we will publish articles in scientific journals about the survey. The report will contain only group totals. No information that would permit the identification of any individual or household will be released or published. The information will be used to assess levels of lead, mold, pesticides and formaldehyde, and other potential hazards found in the Nation’s housing, and to identify the associated risks. The information will be used to develop guidelines for providing a safer environment for our children and for improving the Nation’s health.

7.3 Can I get a copy of the results?

You will be able to get a free copy of the published report by writing to:

American Healthy Homes Survey II

c/o Office of Lead Hazard Control and Healthy Homes

U.S. Department of Housing and Urban Development

451 Seventh Street, S.W. (P3206)

Washington, D.C. 20410

The results of this study will be published after all the data is analyzed.

7.4 Who else will receive the survey results for my home?

The survey results will be provided to HUD in statistical form and as a summary of all homes that we tested. Your name, address, and any other identifying information will not be provided to any of the sponsoring agencies as part of this study.

8.0 REFUSAL REVERSAL

8.1 I just do not have time for your survey. I’m too busy now. Come back next week.

(Such statements are usually a "put-off" tactic and will be continued when you come back. Try to retain control of the situation by establishing an appointment.)

For example: "I’d be happy to come back at a time more convenient for you. How about 7:00 p.m. next Tuesday or Wednesday? …I’ll look forward to talking with you then."

8.2 You don’t want me in your survey; I don’t have any children.

We are studying all homes where children MIGHT live, not just those where children CURRENTLY live. Also, while more children than adults suffer from allergies or the effects of lead, adults can also get asthma, allergies, or lead poisoning.

8.3 You don’t want me in your survey; I don’t have any lead in my paint.

We are studying all types of homes in this study. We must survey both homes with lead hazards and homes without lead hazards to understand the extent of the lead problem in the United States. We need to understand the differences between homes with and without lead to figure out what must be done to reduce and eliminate the problem. In addition, we are studying other substances in homes that may cause health problems.

8.4 You don’t want me in your survey; I don’t have asthma or allergies.

We are studying all types of homes in this study. We must survey both homes with asthmatics and homes without them to understand the extent of the housing-related allergy problem in the United States. We need to understand the differences between homes with and without mold to figure out what must be done to reduce and eliminate the problem. In addition, we are studying hazards in homes due to lead and other substances.

8.5 I had a bad experience recently with someone taking a survey, so I don’t think I want to participate.

I regret that your experience in that survey was a bad one. However, this is an important national research effort authorized by the U.S. Department of Housing and Urban Development. We will make every effort to make your contact with us a pleasant one.

Thank You for Your Participation in This Important Survey

I3- INTRODUCTION AND INFORMED CONSENT
Staff Involved:	Assigned Interviewer and Technician
Overview: This protocol is the first task in a series of testing tasks conducted at each DU that is successfully recruited. These tasks (protocols I3 through I11 and T1 through T5) are performed at the scheduled time arranged with the resident during recruitment (protocol I2). Prior to traveling to the DU to conduct the testing tasks, all of the equipment and supplies needed to conduct the testing must be packed into the Interviewer (and/or Technician, if desired) vehicle(s) so that the needed materials will be available while onsite to complete the testing. After arriving onsite, the Interviewer and Technician prepare the needed materials and package them so that each task during the testing phase can be performed with minimal replicate trips to the transport vehicle(s). After the equipment and supplies are assembled, the Interviewer contacts the resident and an introduction of the 2 field team members is made to the resident using a standardized format followed by asking the respondent to read and sign the Informed Consent and Waiver before continuing with the inventory and interview (see forms at end of this protocol). If the resident is disabled (e.g., auditory or visual disability) or has difficulty communicating in English, the Interviewer will ask for permission to get a neighbor, nearby friend, or relative to assist and to assure that the resident understands and agrees to signing the form. The Interviewer will answer any questions the respondent has regarding the study and the activities to be conducted in their home using the FAQs as an aid (provided during recruiting in protocol I2). Once the Informed consent is signed, the Interviewer will retrieve the first draw water sample from the respondent. The introduction and informed consent (this I3 protocol), the room inventory (I4 protocol), and the resident questionnaire (I5 protocol) will all be carried out using a part of a standardized set of documentation referred to here as a Resident Questionnaire Form Set). This form set contains a cover page that identifies the unit ID number and address (recorded by the Interviewer) and all of the various data forms and support documents that will be needed to complete testing in the DU (Note: forms are shown in the applicable protocol sections but are grouped together in one bound document used by the Interviewer). To increase the efficiency and accuracy, data collection on the Resident Questionnaire itself (protocol I5), Interior Walkthrough (protocol I6), and Room Observations (protocol I7) are to be performed using a pre-programmed android. Therefore these forms are not present in the Resident Questionnaire Form Set provided in the DU Sampling Supplies - Kit (B). Backup Resident Questionnaire Form Sets containing these forms are provided in the Interviewer Equipment - Kit (W) in the remote case that the android failures to operate. The Interviewer should always carry one Backup Resident Questionnaire Form Set with them into each DU when testing for backup use.
Data Recording on:		Pre-programmed android phone, and Interviewer & Technician Form Sets (bound) pulled from Kit (B)
Items needed from Kit (A) - completed Recruiting Questionnaire for the DUs to be tested.
completed Recruiting Questionnaire for each DUs to be tested that day				All other items in the kit may be useful and should be readily available.
Equipment Needed from Kit (W), Kit (X), and Kit (Y)
All equipment electrical tape				Backup copy of Resident Questionnaire Form set
Items needed from Shipper Kit (C) Kit (D), Kit (E1), Kit (E2), and Kit (F)
enough subkits and blue ice packs to handle one day's sampling plus spares				Take one of the shippers to the field to temporarily hold collected samples that must be kept cold until they can be placed into the freezer.
Supply items from Kit (B)
All supplies will be used as various protocols are completed. If the first DU in the PSU use a Kit (B) with and "-WS" suffix ID				If the 2nd DU in the PSU, use a Kit (B) with and "-W" suffix ID
Glove Use Directives:			use new for each type of sample (see protocol I0)

Procedure

1. Coordinate travel plans with Technician to arrive at the DU for testing activities far enough in advance so that the equipment and supplies can be prepared before the scheduled appointment time. The Technician does not have any of the information as to the exact location of the recruited DUs or the schedule. The Interviewer needed to communicate this information frequently with the Technician to ensure the Interviewer and Technician is present at the recruited DU and ready to perform testing at the appointed time.

2. Pack equipment and supplies into vehicle(s). Ensure that all equipment and supplies are in vehicles going to DU as needed to meet the testing schedule. Most of this can be done the night before.

SECTIONS 2.1 THROUGH 2.9 RESERVED FOR MORE DETAIL AS NEEDED.

3. Travel to DU.

4. Prepare Equipment and Supplies for Onsite Use. Unpack the equipment and assemble or re-assemble the equipment to fit into the carriers (backpack, gear bag and bucket) designated for onsite use.

SECTIONS 4.1 THROUGH 4.9 RESERVED FOR MORE DETAIL AS NEEDED.

5. Complete cover pages of Recruiting Questionnaire Form Set and Technician Form Set. Be sure to record the correct DU ID number on the coversheet and other forms in the form sets. The DU ID number is comprised of 3 fields from the AHHS Main and Reserve Sample DU addresses list: PSUID-AHHS SEGID-SAMP TYPE.

6. Conduct resident introduction. Using the Introduction page of the Resident Questionnaire Data Set for the assigned DU, conduct an introduction using the standardized Introduction (see form at end of this protocol).

7. Hand the resident a copy of the Informed Consent.

8. Go over the Informed Consent. Read the Informed Consent to the Resident as they follow along in their copy or simply ask them to read it. Answer any questions that arise concerning what is going to be done. The FAQs provided in the Recruiting Supplies - Kit (A) is intended to provide answers to questions regarding the study. It should be kept at hand during the recruitment in case it is needed to help answer questions.

9. Interviewer, then resident signs 2 copies of the Informed Consent. Sign the both copies Informed Consent using a blue ink pen. Then, have the resident sign both copies and check off the boxes as to the reports desired using a blue ink pen.

10. Give loose copy of signed Informed Consent to resident.

11. Retrieve the first-draw water sample from the resident.

11.1 Place an ID label on the bottle (labels are in Kit (B) subkit I3). This label will have a "-01" suffix on it. Retain the remaining ID replicate "-01" labels in subkit I3 as they will be used later in protocol I10 and in the end-of-day activities.

11.2 Seal the bottle. If the bottle is full to the top, go to a sink and pour out a little until the level is even with the bend in the bottle that narrows to form the neck. If you pour out too much, don't worry about it and DO NOT ADD any water back to it. Screw the cap on tightly and wipe off the outside of the bottle so it is dry before sealing the cap. Seal the cap using electrical tape. Place the end of the tape (on the roll) over the edge where the cap meets to top of the bottle and hold it there with your thumb. Pull and stretch the tape as you wrap it around and over the cap edge. Make 2 full warps around the cap pulling hard at the end to stretch-break the tape. Push any trailing tape on the cap tightly against the cap to finish the seal. Place the bottle in your equipment pack for temporary storage.

12. Move on to the Room Inventory task (protocol I4).

Cover Sheet for Resident Questionnaire Form Set

Dwelling Unit ID:		Kit (B) Number:	place Kit (B) label here
	PSUID - AHHS SEGID - SAMP TYPE
DU Address and Contact Telephone Numbers (if available)









Interviewer Name

**Note all fields to be completed by Interviewer

DU ID#_______________ Interviewer Name: ____________________ Date: ____ / ____ / ______

Time Begun: _____________ ( AM / PM ) Final Result Code: ________________________________

AMERICAN HEALTHY HOMES SURVEY II

U.S. DEPARTMENT OF HOUSING AND URBAN DEVELOPMENT (HUD)

U.S. ENVIRONMENTAL PROTECTION AGENCY (EPA)

RESIDENT QUESTIONNAIRE/ROOM INVENTORY

INTRODUCTION: Hello. We have an appointment to do some environmental testing here today. Is (MR./MS. NAME OF CONTACT) here?

My name is (INTERVIEWER NAME). This is (NAME OF TECHNICIAN). We are with QuanTech. I spoke to (you/MR. /MS. NAME OF RESPONDENT, SEE CONTACT RECORD) last week and invited your household to participate in a research study for the United States Department of Housing and Urban Development. (SHOW ID BADGE, ASK TO GO INSIDE)

Box A

If the contact is not at home, attempt to conduct the survey with the person answering the door, if at least18 years old and a resident of the home.

Time: ________________ Date: ______________ day of week: ________________

If later the same day, plan to return then. If another day, re-arrange the appointment by telephone.

New appointment Date: ______________________ Time: ______________________

Complete the Record of Contact to document this/THESE activity(ies).

Before we can begin our work, I would like to ask you to please read and sign the informed consent form which explains the study in detail and gives us permission to collect dust, soil, and other environmental samples in this home. I will go over each item of the form with you so that you know exactly what we are going to do. You will be given a copy of the informed consent to keep.

Box B

Wait for the respondent to read each item on the consent form. Answer any questions they may have regarding the study and work you are doing. then sign both copies and ask the respondent to also sign and date both copies of the consent form. After checking the signature and date, provide respondent with one copy and proceed. DO NOT BEGIN ANY WORK UNTIL RESPONDENT GIVES PERMISSION and has signed the consent form.

Thank you, now I would like to begin with some questions about your house/apartment. First I need a list of the rooms in your home, so we can determine which ones to take samples in – we do not need to sample in every room. [COMPLETE ROOM INVENTORY]

Dwelling Unit ID: _________________________

INFORMED CONSENT TO PARTICIPATE IN THE

AMERICAN HEALTHY HOMES SURVEY II

Sponsor / Study Title:

HUD OHHLHC / “American Healthy Homes Survey (AHHS) II

This is a follow-up study to the American Healthy Homes Survey conducted in 2005-2006, funded by the U.S. Department of Housing and Urban Development (HUD), Office of Lead Hazard Control and Healthy Homes (OLHCHH).”

Protocol Number:

AHHS II

Principal Investigator:

David Cox, Ph.D.

Telephone:

(800) 229-5220 (24 Hours)

Address:

QuanTech

6110 Executive Blvd.

Suite 480

Rockville, MD 20852

This document tells you what you need to make an informed decision about the American Healthy Homes Survey II. This information is provided to you based on the Department of Health and Human Services regulation on "Protection of Human Subjects" (Title 45 CFR, part 46).

Purpose

The U.S. Department of Housing and Urban Development (HUD) and the U.S. Environmental Protection Agency (EPA) are surveying American homes. The survey is looking at causes of lead poisoning and things that affect health and safety. The survey is called the American Healthy Homes Survey II. QuanTech, under contract to HUD, is carrying out the survey. Approximately 20 homes will be included in this survey.

Financial Disclosure

Dr. David Cox, the study principal investigator, has direct ownership in QuanTech. Due to this potential conflict of interest, Dr. Cox will not be involved in the informed consent process or recruitment for this study. You can ask to speak with the study principal investigator if you have additional questions.

Procedure

The survey team is asking permission to visit your home for about 3 ½ hours. The team will:

Question you about your home’s construction and the heating and cooling systems; also questions about your family’s health, earnings, and ethnic background.
Collect samples of house dust from floors, windows, and a used vacuum bag.
Collect samples of soil outside your home.
Pick up a water sample you have collected, and collect a second sample.
Sample the air in your home using a small pump.
Look for common household safety devices (for example, smoke detectors), and things that affect safety (for example, frayed electrical wiring).
Measure lead in painted surfaces in your home without damaging the paint.
Take measurements of temperature, humidity, and moisture content in drywall/plaster.

The survey team will be using the dust, soil, water and air samples to test for:

Lead 2. Formaldehyde

Pesticides 4. Mold

New Information About the Study

You will be told about any new information found during the study that may affect whether you want to continue to take part.

Cost

There is no cost to you for taking part in this study.

Benefits

The results will help improve public health across the United States. In appreciation you will receive:

Reports on the findings of the air, water and dust tests and safety checks;
A pamphlet about lead in homes, for adults;
$160 when the team finishes the survey in your home.

We will tell you about any immediate hazards we notice, and send you a report on the results of our tests. However, HUD, EPA, and QuanTech cannot take any actions to correct hazards in your home. If the survey team finds lead paint or lead hazards in your home, you will be sent a report of the lead test results, unless you specifically decline to receive it. Please note that the presence of intact lead paint in a house is not considered a hazard. Lead must be accessible to young children or pregnant women to be a hazard.

Risks or Discomforts

The survey team will use a detector to measure lead in the paint in your home. The detector contains a small amount of radioactive material. This material is enclosed in a protective case inside the detector, and will not harm you. None of this material will remain in your home after they have left. The detector has been approved for use in homes in all fifty states.

If you accept the report on lead paint and/or lead hazards in your home, and you own the home, the law requires you to disclose the report to any buyers or renters. Exemptions include: (1) houses built 1978 or later; (2) dwellings with no bedrooms, such as lofts, efficiencies, and studios; (3) short-term leases of 100 days or less, as for vacation homes; and (4) housing designated for the elderly or the handicapped, where no children are allowed to live. Some localities may have additional reporting rules.

We will use the information we collect in your home only for scientific research and reports. Your answers will be combined with others, so that no one can identify your answers. No one outside the study will have access to your information. For example, your report on lead paint and/or lead hazards will not be given to HUD, EPA or State or local government agencies.

Alternatives to Being in The Study

You do not need to take part in this research study.

Subject Protections

Your participation is voluntary. There are no penalties or loss of benefits if you decide not to participate. You may decline to answer any questions you wish, and you may stop participating at any time. You do not have to accept any of the reports offered, including the lead hazards report.

Your part in the research may stop at any time for any reason, such as, the sponsor or the principal investigator decides to stop the study.

If you feel that you have not been adequately informed about the risks, benefits, procedures, or your rights, or if you feel under pressure to continue against your wishes, you can call QuanTech, Dr. David Cox, at (240) 397-2993. For any questions about this study, the results, or the information about your home, you can also call Dr. Cox at the toll-free number (800) 229-5220.

Confidentiality

To ensure that your information collected for this study will be kept private, your name will not be used whenever possible. A code will be used instead of your name. All of your study data will be kept in a secure location.

The sponsor, the sponsor’s representatives, the Food and Drug Administration (FDA), and Chesapeake IRB may have access to the study data.

Getting Answers to Your Questions or Concerns About the Study

You can ask questions about this consent form or the study (before you decide to start the study, at any time during the study, or after completion of the study). Questions may include:

Payment or compensation for being in the study, if any;
Your responsibilities as a study subject;
Eligibility to participate in the research;
The principal investigator’s or study site’s decision to exclude you from participation;
Results of tests and/or procedures;
Other questions, concerns, or complaints.

Contact the principal investigator or study staff listed on the first page of this form with any questions, concerns or complaints.

Getting Answers to Your Questions About Your Rights as A Research Subject

This study has been reviewed by an Institutional Review Board (IRB). This Committee reviewed this study to help ensure that your rights and welfare are protected and that this study is carried out in an ethical manner.

For questions about your rights as a research subject, contact:

By mail:

Study Subject Adviser

Chesapeake IRB

6940 Columbia Gateway Drive, Suite 110

Columbia, MD 21046

or call toll free: 877-992-4724
or by email: adviser@chesapeakeirb.com

Please reference the following number when contacting the Study Subject Adviser: Pro00019737.

Report Request

The following reports on the test results for your home can be mailed to you upon the completion of the study (currently estimated for Fall 2018). The reports are 3-6 pages long. Please check below to receive the reports.

Report Topic	Please send me a copy
Lead*	
Other test results and home safety	

*If your home has lead-based paint or a lead-based paint hazard, we will automatically send you a lead report unless you specifically decline to accept it. If any children under the age of 6 or pregnant women live in or regularly visit your home, we strongly encourage you to accept the lead report.

PLEASE INDICATE (BY CHECKING THE BOX) IF YOU DO NOT WANT THE LEAD REPORT, EVEN IF LEAD PAINT OR LEAD HAZARDS ARE FOUND IN YOUR HOME: 

For the Interviewer to complete:

I have fully informed the survey subject, , about the nature and purpose of the procedures described above, including their possible benefits and any risks involved. I have asked the subject if he or she has any questions about the procedures. I have answered those questions to the best of my ability. I will give the subject a signed and dated copy of this consent form.

Interviewer Signature Date

Printed Name of Interviewer

For the Subject to complete:

I have read the above information and have been informed about the nature and purpose of the procedures described above, including their possible benefits and their risks to my family or me from participating in this study. I understand that my participation is entirely voluntary. I agree to participate in this survey. I recognize that I am free to stop participating in this survey at any time without any effect on my rights.

Subject Signature Date

Printed Name of Research Subject

I4 - ROOM INVENTORY
Staff Involved:	Assigned Interviewer
Overview: Once consent is obtained (protocol I3), the Interviewer will complete the Room Inventory (see form at end of this protocol) to list all rooms in the home. This information will be used to select the rooms in which environmental sampling will be conducted. One room of each of 5 room types will be selected for sampling plus the basement, if one exists. The Room Inventory form groups the 4 types of rooms together using 4 sets of ID numbers, shown on the form in Column 1. They include Kitchens, KIT (Room ID’s 11 through 13), Common Living Areas, CLA (Room ID’s 21 through 24), Bedrooms, BR (Room ID’s 30 through 39), and other rooms, OTHER (Room ID’s 40 and higher). The Interviewer will discuss the rooms selected with the respondent; if one of the rooms is unavailable for some reason, a second room in the stratum will be selected, if possible. The Room Inventory will also ask which is the major used entrance and in which areas of the yard children play. Once rooms are selected, this information will be communicated to the Technician. The Room Inventory form has a carbonless duplicate back. The back of the Room inventory is for the Technician who will need this information for testing while the Interviewer administers the Resident Questionnaire. In addition, the Interviewer will query the respondent about the likely location of the drinking water service line coming into the home and record this for the Technician who will later examine it to determine whether it is a lead service feed line.
Data Recording on:		Interviewer Form Set pulled from Kit (B)
Equipment Needed from Kit (W)
1 blue ink pen 1 clipboard 1 black sharpie marker 1 flashlight with extra batteries					1 tape measure (25’)
Supplies Needed from Kit (B) - Subkit T3
Room Inventory (bound with duplicate tear-off back, which goes to Technician)				1 Refusal/Break-off Report (loose; if needed in case of a break-off)
Glove Use Directives:			optional (see protocol I0)

Procedure

1. Walk with resident and list all rooms in the DU on the Room Inventory form. Have the resident show you through each room of the house and record/list all rooms in the home on the Room Inventory (see form at the end of this protocol). Use a blue ink pen to record the findings. Use the following parameters.

1.1 Room column and room IDs. The numbers on the left are Room ID numbers. They will be used later on the various environmental testing forms. For each room found in the home, record the room on one of the rows of the form:

1.1.1 Kitchens (IDs 11-13). List each kitchen room on one of these rows. Note that in the case of an efficiency containing a kitchen as part of one common living area, the room is considered a common living area and is to be recorded on ID 24.

1.1.2 Common Living Areas (IDs 21-24). List each common living area room on one of these rows.

1.1.3 Child’s bedrooms (IDs 30 –34). List the age(s) in years of the children who sleep there.

1.1.4 Adult bedrooms (IDs 35-39). Fill in an identifier to help you distinguish between different bedrooms in the DU, to ensure that the Interviewer and Technician sample in the same rooms.

1.1.5 Bathrooms (IDs 45-48). Fill in an identifier to help you distinguish between different bathrooms in the DU.

1.1.6 Additional rooms not already listed (IDs 49-54). Enter these in rows 49-54.

1.1.7 Major entrance (ID 61) is the primary used entrance into the DU.

1.2 Exists column. For every listed room on the form, circle whether the listed room exists (yes) or not (no). It is generally recommended that you start by circling the 1's in the yes column for all the rooms you have found and listed. Then afterwards circle the 2's for those that do not exist.

1.3 Level column. Enter the level of the house where the room is located.

1.3.1 For DUs with basements, basement is level 0. A basement is a floor below ground level. All floors above a basement are labeled 1, 2, 3, etc to indicate the successive floors going up from ground level (level 1).

1.3.2 For DUs without basements, the ground floor is level 1. Floors above the ground floor are labeled 2, 3, 4, etc.

1.3.3 For DUs in high-rise buildings, the main entrance to the DU is level 1. Floors above level 1 inside the DU are labeled 2, 3, 4, etc.

1.4 Selection column. See step (2) below.

2. Randomly select primary testing rooms from like groups. After identifying and recording all the rooms, use the random selection procedure in step 3 to randomly select the 4 primary testing rooms from the groupings shown below:

2.1 Kitchen (KIT), IDs 11-13

2.2 Common Living Area (CLA), IDs 21-24

2.3 Bedroom (BR), IDs 30-39, where the children’s bedrooms are 30-34 and Adult bedrooms are 35-39

2.4 Other Room, IDs 40-54.

3. Random selection procedure for primary (testing) rooms. Place an ‘S’ in the applicable row under the selection column for the rooms selected using the following parameters:

3.1 If only one entry exists, select the one entry.

3.2 If more than one entry exists, select randomly among all rooms in the group using the Random Selection Procedure for Items shown at the end of this protocol.

3.3 When selecting the bedroom (BR), preference is for children’s bedrooms. If one or more child’s bedroom is listed within the 30-34 grouping, use steps 3.1 and 3.2 above to select a child’s bedroom as a primary room. Otherwise use the bedrooms listed within the 35-39 grouping as the group from which to randomly select as a primary room. Place an ‘S’ in the applicable row under the selection column for the rooms selected as primary rooms.

3.4 When selecting the other room, include adult bedrooms in the random selection if a child's bedroom was selected as the primary (BR) room. If one or more child’s bedroom is listed within the 30-34 grouping (and one of these is selected as a primary room), then expand the pick list for the other room to include this grouping (35-54 as opposed to 40-54).

4. Verify and complete room selections.

4.1 Verify that only four ‘S’ entries exist in the last column (far right) of the form.

4.2 If a Basement exists, is accessible and used for habitation, then place a ‘B’ in the applicable row under the selection column for the basement.

4.3 Place a ‘P’ next to the ‘S’ entry for the Kitchen to indicate that the pesticide sample is to be taken in the Kitchen (all DUs will be sampled for pesticides). Place a ‘PQ’ next to the ‘S’ entry for the Kitchen if a pesticide QC sample is also to collected in the DU (first DU sampled in each PSU).

4.4 Place a "W" next to the "S" entry for the CLA and the BR to indicate that these rooms are to be used for collection a composite dust wipe swiffer™ sample. The 1st DU tested AND the 2nd DU tested in a PSU are to get a dust wipe swiffer™ sample.

4.5 Place a "D" to indicate the selected room is where the technician should be able to get to the drinking water service line coming into the home.

5. Select a random wall to be tested as the exterior wall to receive additional LPB testing using the Random Selection Procedure for Items shown at the end of this protocol.

6. Visit and confirm access to selected rooms. Show the completed form to the Technician and briefly visit each selected room with the resident and Technician to ensure all agree on which rooms have been selected. Explain to the resident while visiting each room that the Technician will be making measurements in these rooms while we (Interviewer and resident) complete a questionnaire.

7. Pass copy of Room Inventory form to Technician. Remove the duplicate back-copy of the completed Room Inventory form and hand it to the Technician.

8. Move on to the Resident Questionnaire Task (protocol I5).

Random Selection Process for Items

1. Count the number of items (like room count or four walls)

2. Go to the Random Number Table

2.1 Select the first unused row of the table.

2.2 Look under the column that matches the count number to get the selection and remember the selected number.

2.3 Put a line through that row of the table to indicate that it has been used.

3. For rooms, starting at the top of the list of rooms from which you need to make a selection and count down the selected number down from the top (where the first listed room is one).

For example, if there are two child's bedrooms and the first row of the table is used, then the 2nd listed room is to be tested.

For walls, start at the main entrance door in the room, count the walls clockwise (left to right) until the selected number is reached and select that wall for testing.

For example, if the main entrance door in the room faces west and first row of the table is crossed-out (already used), then the 3rd wall or the east wall is to be tested.

Dwelling Unit ID#___________________

Room Inventory Form

List ALL rooms in the dwelling unit before making any selections!

ROOM	Exists?		Level	Selection S = 4 primary rooms P = Pesticide Room W = Swiffer room B = Basement D = water service line entry into DU	Comments WP = wallpaper on most walls
ROOM	Yes	No	Level		Comments WP = wallpaper on most walls
11. Kitchen	1	2
12. Kitchen	1	2
13. Kitchen/Living room	1	2
21. Living/Sitting room/Parlor	1	2
22. Den/Family/Rec/Florida/Great room	1	2
23. Den/Family/Rec/Florida/Great room	1	2
24. Efficiency (K/LR/BR or LR/BR)	1	2
30. Child’s Bedroom (age(s): )	1	2
31. Child’s Bedroom (age(s): )	1	2
32. Child’s Bedroom (age(s): )	1	2
33. Child’s Bedroom (age(s): )	1	2
34. Child’s Bedroom (age(s): )	1	2
35. Bedroom (identify: )	1	2
36. Bedroom (identify: )	1	2
37. Bedroom (identify: )	1	2
38. Bedroom (identify: )	1	2
39. Bedroom (identify: )	1	2
40. Dining room	1	2
41. Study/office	1	2
42. Sewing room	1	2
43. Guest Bedroom	1	2
44. Laundry Room	1	2
45. Bathroom (identify: )	1	2
46. Bathroom (identify: )	1	2
47. Bathroom (identify: )	1	2
48. Bathroom (identify: )	1	2
List any additional rooms:
49.	1	2
50.	1	2
51.	1	2
52.	1	2
53.	1	2
54.	1	2
61. Most Commonly Used Entrance (Identify closest room ID _______________)
Attached garage?	1	2

Note: A child’s bedroom is occupied by at least one person age 17 or younger.

Check: Verified Rooms by Level

Circle one random selected exterior wall to receive additional LBP testing:

(1) North (2) East (3) South (4) West

Random Number Table for Random Selections

Random Number Selections from a Group of 2 to 14 Items
Row	Number of Items to Pick From:
Row	2	3	4	5	6	7	8	9	10	11	12	13	14
1	2	2	3	1	3	4	5	3	7	11	5	3	5
2	2	3	3	4	2	5	8	5	10	1	3	7	2
3	2	1	3	1	4	2	8	3	2	5	7	3	2
4	2	3	3	1	3	1	6	8	6	9	3	13	2
5	1	1	3	5	4	2	6	2	5	3	4	2	2
6	1	3	2	3	4	7	6	2	6	3	12	4	14
7	2	3	2	2	5	6	6	1	1	8	9	8	8
8	2	2	1	4	2	4	5	5	4	6	6	10	13
9	2	2	3	1	5	3	6	6	7	2	8	7	1
10	1	3	1	1	3	2	2	7	5	6	10	4	13
11	2	1	3	1	5	7	3	6	10	6	3	2	13
12	1	2	3	2	5	4	2	4	8	3	10	11	9
13	1	2	2	2	4	3	2	6	3	8	4	4	6
14	2	1	3	3	3	2	3	7	5	10	5	4	7
15	2	2	1	4	4	7	3	7	2	9	7	5	11
16	2	3	1	3	3	6	6	9	8	11	5	2	11
17	2	3	3	2	4	3	4	2	9	3	3	12	12
18	1	2	2	2	4	4	2	4	7	2	5	9	12
19	1	1	1	3	5	3	3	4	2	4	8	7	8
20	1	3	3	2	2	2	2	3	5	7	11	12	12
21	2	1	4	4	5	1	3	2	2	3	4	7	4
22	2	1	3	4	3	5	3	5	5	10	1	11	2
23	2	1	3	3	1	5	3	3	5	5	4	7	3
24	1	3	2	3	5	4	7	3	8	4	8	5	6
25	1	3	2	2	6	2	5	5	3	2	1	10	2
26	2	3	3	4	5	5	5	8	6	3	6	3	12
27	2	3	3	2	2	6	2	1	6	2	5	8	12
28	1	3	3	4	6	3	7	1	3	3	2	8	11
29	2	2	4	4	3	7	3	2	8	10	6	10	8
30	1	1	2	5	5	2	3	2	3	4	4	8	11
31	2	3	1	4	4	4	5	7	6	3	6	2	3
32	1	3	3	4	5	5	4	3	9	6	3	9	12
33	1	2	3	3	2	4	6	8	4	3	4	11	13
34	2	1	1	3	3	3	7	4	8	2	4	11	1
35	1	1	3	2	6	6	6	3	8	4	6	1	7
36	1	1	3	5	3	4	5	6	10	2	9	1	11
37	1	2	2	3	3	7	7	4	3	2	3	6	12
38	1	2	3	5	4	7	6	1	1	8	6	8	13
39	1	1	1	3	3	6	5	3	7	8	12	6	1
40	2	2	1	1	2	4	7	9	5	9	5	11	12

I5- RESIDENT QUESTIONNAIRE
Staff Involved:	Assigned Interviewer
Overview: After the Room Inventory has been completed (protocol I4), the Interviewer will administer the remaining portions of the Resident Questionnaire using the tablet.
Data Recording on:		Remaining Portions of Questionnaire (on tablet)
Equipment Needed from Kit (W)
1 blue pen 1 clipboard 1 Samsung Galaxy tablet 1 backpack to hold tablet and other supplies 1 Backup Resident Questionnaire Form Set (needed only if tablet fails)					1 set Color Coded Cards: 1 Building Categories – Blue 1 Heating Sources – Tan 1 Work Activities – Green 1 Home Activities – Pink 1 Race and Education – Purple 1 Income A – Yellow 1 Income B – White
Supplies Needed from Kit (B) - Subkit I5
3 rows of 4 self-adhesive, pre-printed ID labels				1 Break-off Report (needed only in case of a mid-interview refusal)
Glove Use Directives:			optional (see protocol I0)

Procedure

1. Pick location to give questionnaire. Go to a convenient place in the DU (such as the Kitchen) to give the resident questionnaire using the tablet.

2. Move on to the Interior Walkthrough (protocol I6) after completing the interview.

1. HOUSE AND EXPOSURE

I have a few more questions about your house/apartment. (NAME OF TECHNICIAN) will be preparing our sampling equipment and forms in the mean time.

Q1. What year was your home/apartment built?

YEAR OF CONSTRUCTION |___|___|___|___|  (SKIP TO Q2b)

DON’T KNOW 8

PROMPT: Only if needed, Hand respondent card with building age categories - blue

Q2. Which category of years on this card do you think most closely matches when the building was built?

1990 TO PRESENT 1

BETWEEN 1978 AND 1989 2

BETWEEN 1960 AND 1977 3

BETWEEN 1946 AND 1959 4

BETWEEN 1940 AND 1945 5

1939 OR BEFORE 6

DON’T KNOW 8

Q2a. RECORD ANY COMMENTS RESPONDENT MAKES ABOUT BUILDING AGE.

___________________________________________________________________________

Q2b. Have there been any additions to this house since 1977 (that is, in 1978 or later)?

YES 1

NO 2

DON’T KNOW 8

Q3a. How long has anyone in the household lived in this home?

NUMBER |___|___|

YEARS 1

WEEKS 2

MONTHS 3

DON’T KNOW 8



(SKIP TO Q3c)

Q3b. How long have you lived in this home?

NUMBER |___|___|

YEARS 1

WEEKS 2

MONTHS 3

Q3c. Have you ever received a copy of a pamphlet called "Protect Your Family from Lead in Your Home"? (Show respondent a copy of the most current version of the pamphlet.)

YES 1

NO 2

DON’T KNOW 8

REFUSED 9

Q3d. Have you ever had this home tested for lead in paint, dust, or soil?

YES 1

NO 2

DON’T KNOW 8

REFUSED 9

Q4. [IF NEEDED, ASK] How many stories are in the house/building, including the basement? (IF SPLIT LEVEL, OR PARTIAL BASEMENT, COUNT THE GREATEST NUMBER OF STORIES ON TOP OF EACH OTHER.)

NUMBER OF STORIES |___|___|

DON’T KNOW 8

INTERVIEWER NOTE: IF SINGLE FAMILY HOME, SKIP TO Q7

Q5. [IF NEEDED, ASK] How many apartments/housing units are in this building?

NUMBER OF HOUSING UNITS |___|___|___|___| (SKIP TO Q7)

DON’T KNOW 8

Q6. [IF NEEDED, ASK] Would you say that there are 4 or fewer units, or 5 units or more, in the building?

4 OR FEWER UNITS 1

5 UNITS OR MORE 2

DON’T KNOW 8

BOX C

DO THIS AS YOU LEAVE THE RESPONDENT'S HOME

INTERVIEWER: if the respondent does not know how many units are in the building, verify by some other means (e.g. by looking at the mailboxes for the building). Record on the top of the Exterior Conditions Log as you leave the housing unit.

Q7. What is the main heating source in your home? You may refer to the tan card for your answer.

(CIRCLE ONE)

PROMPT: Only if needed, hand respondent card with heating sources - tan

GAS-HEATED FORCED AIR (VENTS) 01

ELECTRIC-HEATED FORCED AIR (VENTS)

(INCLUDES HEAT PUMPS) 02

OIL/KEROSENE-FIRED FURNACE 03

ELECTRIC BASEBOARD HEAT 04

RADIATORS (STEAM OR HOT WATER) 05

GAS STOVE/FIREPLACE/WALL FURNACE 06

WOOD BURNING STOVE/FIREPLACE 07

KEROSENE SPACE HEATER 08

RADIANT/CERAMIC HEATER 09

ELECTRIC SPACE HEATER 10

SOME OTHER SOURCE 11

(SPECIFY___________________________________________________________)

NO SOURCE OF HEAT 12  (SKIP TO Q9)

DON’T KNOW 98

Q8. Are there any other sources you use for heat? You may refer to the tan card for your answer(s).

(CIRCLE ALL THAT APPLY)

GAS-HEATED FORCED AIR (VENTS) 01

ELECTRIC-HEATED FORCED AIR (VENTS)

(INCLUDES HEAT PUMPS) 02

OIL/KEROSENE FIRED FURNACE 03

ELECTRIC BASEBOARD HEAT 04

RADIATORS (STEAM OR HOT WATER) 05

GAS STOVE/FIREPLACE/WALL FURNACE 06

WOOD BURNING STOVE/FIREPLACE 07

KEROSENE SPACE HEATER 08

RADIANT/CERAMIC HEATER 09

ELECTRIC SPACE HEATER 10

SOME OTHER SOURCE 11

(SPECIFY___________________________________________________________)

NO OTHER SOURCE OF HEAT 12

DON’T KNOW 98

Q9. What kinds of air-conditioning system(s) are in this home? Are there…

WINDOW UNITS 1

CENTRAL AIR CONDITIONING 2

EVAPORATIVE COOLER (SWAMP COOLER 3

NO AIR CONDITIONING 4  (SKIP TO Q11)

DON’T KNOW 8  (SKIP TO Q11)

Q10. How often have you used air conditioning in the past month? Would you say…

EVERYDAY, 1

20 TO 30 DAYS, 2

10 TO 19 DAYS, 3

1 TO 9 DAYS, OR 4

NOT AT ALL 5

DON’T KNOW 8

Q11. In the past month, approximately how many hours a day did you keep the windows or doors open in your home? Was it…

LESS THAN 1 HOUR PER DAY 1

1-3 HOURS PER DAY 2

4-12 HOURS PER DAY 3

MORE THAN 12 HOURS PER DAY, OR 4

NOT AT ALL 5

DON’T KNOW 8

Q12. Have there ever been water problems or dampness in your home from broken pipes, persistent leaks, heavy rain, or floods?

YES 1

NO 2  (SKIP TO Q14)

DON’T KNOW 8  (SKIP TO Q14)

Q12a. How recently have there been water problems or dampness in your home? Would you say:

RIGHT NOW 1  (SKIP TO Q13)

NOT NOW BUT IN THE LAST 3 MONTHS 2

3 to 12 MONTHS AGO 3

MORE THAN A YEAR AGO 4

DON’T KNOW 8

Q12b. When the water or dampness problem stopped or was fixed, were water damaged materials removed?

YES 1  (SKIP TO Q14)

NO 2  (SKIP TO Q14)

NO DAMAGED MATERIALS 3  (SKIP TO Q14)

DON’T KNOW 8  (SKIP TO Q14)

Q13 Can you describe the water problem or leak?

(SPECIFY__________________________________________)

Q14. Does your home frequently have a mildew odor or musty smell?

YES 1

NO 2

DON’T KNOW 8

Q15. Do you use a dehumidifier in your home?

YES 1

NO 2

DON’T KNOW 8

Q16. In the past six months, have you had any of the following pets living in your home? Please answer Yes or No for each type of pet. Did you have a…

YES NO DK

Q16a. CAT 1 2 8

Q16b. DOG 1 2 8

Q16c. HAMSTER 1 2 8

Q16d. GERBIL 1 2 8

Q16e. GUINEA PIG 1 2 8

Q16f. RABBIT 1 2 8

Q16g. BIRD 1 2 8

Q16h. ANY OTHER PETS 1 2 8

(SPECIFY___________________________________________)

IF Q16a – Q16h ARE ALL NO OR DK, THEN SKIP TO Q17

Q17. Of the pets you just mentioned, which are currently living in your home?

NONE 01

CAT 02

DOG 03

HAMSTER 04

GERBIL 05

GUINEA PIG 06

RABBIT 07

BIRD 08

OTHER 09

(SPECIFY__________________________________________)

DON’T KNOW 98

Q18. In the last 12 months, have you seen mice or evidence of mice, such as nests or droppings, in your home?

YES 1

NO 2 (SKIP TO Q20)

DON’T KNOW 8 (SKIP TO Q20)

Q19. About how often do see mice or evidence of mice in your home? Is it…

Every Day, 1

Once a week, 2

Once a month, 3

Once a year 4

Seldom 5

Never 6

DON’T KNOW 8

Q20. What is the source of water for your home?

City or county supplied (main) 01  (SKIP TO Q20b)

A well 02  (SKIP TO Q20b)

A collection tank 03

OTHER 09  (SKIP TO Q20b)

(SPECIFY__________________________________________)

DON’T KNOW 98  (SKIP TO Q20b)

Q20a. Where does the water that fills your collection tank come from?

Rain runoff 01

A spring 02

A river or lake 03

OTHER 09

(SPECIFY__________________________________________)

DON’T KNOW 98

Q20b. Where does your waste water go?

Central city or county sewer 01

Septic tank/system 02

OTHER 09

(SPECIFY__________________________________________)

DON’T KNOW 98

Q20c When you collected the drinking water sample for us (which I'll get from you later), where did you collect it?

Kitchen 01

Bathroom 02

OTHER 09

(SPECIFY__________________________________________)

DON’T KNOW 98

Q20d When you collected the drinking water sample for us, did you collect it before anyone in the home used any water today (e.g., showering, doing laundry, flushing the toilet, etc.)?

YES 1  (SKIP TO Q21)

NO 2

DON’T KNOW 8

Q20e Was the faucet where you collected the sample run at all today before you collected the sample?

YES 1

NO 2

DON’T KNOW 8

2. ACTIVITIES IN THE HOUSE

INTERVIEWER NOTE: TAG THE ROOM INVENTORY FORM WITH A CLIP SO THAT IT CAN BE EASILY REACHED AS IT WILL BE NEEDED TO OBTAIN ROOM CODES FOR ANSWERING MANY OF THE FOLLOWING QUESTIONS

Q21. Do you use air fresheners such as plug-ins, gels or solids, or sprays in the home?

YES 1

NO 2  (SKIP TO Q22)

DON’T KNOW 8  (SKIP TO Q22)

Q21a. Please tell me which room(s) you use air fresheners in, the type of air freshener, and how many are in each room.

Room Name	Room code from Room Inventory	21b. Plug-in How many are in… [ENTER NUMBER IN ROOM]	21c. Gel/Solid How many are in… [ENTER NUMBER IN ROOM]	21d. Spray in last month?
				Y 1 N 2 DK 8
				Y 1 N 2 DK 8
				Y 1 N 2 DK 8
				Y 1 N 2 DK 8
				Y 1 N 2 DK 8
				Y 1 N 2 DK 8

Q22 Do you use air cleaning appliances such as ionizers, ozone generators, or air filtration appliances in the home?

YES 1

NO 2  (SKIP TO Q23)

DON’T KNOW 8  (SKIP TO Q23)

Q22a. Please tell me which room(s) you use air cleaning appliances in and the type of air cleaning appliance in each room.

Room Name	Room code from Room Inventory	22b. ionizer [ENTER NUMBER IN ROOM]	22c.ozone generator [ENTER NUMBER IN ROOM]	22d. air filtration appliance [ENTER NUMBER IN ROOM]	22e. Other air cleaner [ENTER NUMBER IN ROOM]

Q23 (recent carpet installation) DELETED since not a source of formaldehyde.

Q24 In the last 6months, has any new furniture or cabinetry been purchased for the home?

YES 1

NO 2  (SKIP TO Q25)

DON’T KNOW 3  (SKIP TO Q25)

Q24a Where in the home is the new furniture or cabinetry?

Room Name Room Code from Room Inventory

__________________ ___________________________

Now I will ask some questions about pesticide application in this home.

Q25. In the last 12 months, have you had cockroaches in your home?

YES 1

NO 2

DON’T KNOW 8



(SKIP TO Q25c)

Q25a. When was the last time you saw cockroaches inside your home? Was it…

WITHIN THE LAST WEEK, 1

WITHIN THE LAST MONTH, 2

2 TO 4 MONTHS AGO 3

5 – 12 MONTHS AGO 4

DON’T KNOW 8



(SKIP TO Q25c)

Q25b. Approximately how many cockroaches do/did you see per day on average in your home?

LESS THAN 5 1

5 TO 50 2

MORE THAN 50 3

DON’T KNOW 8

Q25c. In the last 12 months, have you had bed bugs in your home?

YES 1

NO 2

DON’T KNOW 8



(SKIP TO Q26)

Q25d. When was the last time you saw bed bugs inside your home? Was it…

WITHIN THE LAST WEEK, 1

WITHIN THE LAST MONTH, 2

2 TO 4 MONTHS AGO 3

5 – 12 MONTHS AGO 4

DON’T KNOW 8

The following set of questions pertains to indoor pesticide applications.

Q26. Are pesticides or chemicals to kill bugs used inside your home?

prompt: show card for types of indoor pesticide products - Grey

YES 1

NO 2

REFUSED TO ANSWER 7

DON’T KNOW 8



(SKIP TO Q32)

Q27. Who usually applies the pesticides or chemicals to kill bugs inside your home?

(cIRCLE all that apply)

SELF (YOU) 1

FAMILY MEMBER 2

(SPECIFY______________________________________________________)

PROFESSIONAL PEST CONTROL APPLICATOR 3

BUILDING MAINTENANCE STAFF 4

OTHER 5

(SPECIFY______________________________________________________)

REFUSED TO ANSWER 7

DON’T KNOW 8

Now, the following questions are about pesticides or chemicals that have been used to kill bugs inside your home. These could have been used by you, a family member, a family friend, a professional pest control worker, and/or the building (or apartment) maintenance staff.

Q28. During the warm months in your area, did you or anyone else use any pesticides or chemicals to kill bugs inside your home?

YES 1

NO 2

REFUSED TO ANSWER 7

DON’T KNOW 8



(SKIP TO Q29)

Q28a. How often did you or anyone else use pesticides or chemicals to kill bugs inside your home during the warm months?

prompt: On average, how often was it used during the warm months in your area?

DAILY 01

EVERY TWO TO SIX DAYS 02

WEEKLY 03

ONCE EVERY 2 WEEKS (BIWEEKLY) 04

ONCE EVERY 3 WEEKS 05

MONTHLY 06

ONCE EVERY 2 MONTHS (BIMONTHLY) 07

ONCE EVERY 3 MONTHS 08

LESS THAN ONCE EVERY 3 MONTHS 09

REFUSED TO ANSWER 97

DON’T KNOW 98

Q28b. What kinds of bugs were being killed inside your home during the warm months?

(CIRCLE all that apply)

ANTS 01

COCKROACHES 02

CRICKETS 03

FLEAS/TICKS 04

FLIES 05

LICE 06

MOSQUITOES 07

TERMITES 08

WASPS/BEES 09

WATER BUGS 10

BED BUGS 11

REFUSED TO ANSWER 97

DON’T KNOW 98

Q28c. Where were pesticides used inside your home during the warm months?

(Circle all that apply)

prompt: read the list as needed

ATTIC 01

BASEMENT 02

BATHROOM – CHILD’S 03

BATHROOM - OTHER 04

BEDROOM – CHILD’S 05

BEDROOM – OTHER 06

CHILD’S PLAY ROOM 07

DINING ROOM 08

FAMILY ROOM 09

GAME ROOM 10

HALLWAY 11

INDOOR ENCLOSED PORCH/SUNROOM 12

KITCHEN 13

LAUNDRY ROOM/UTILITY ROOM 14

LIVING ROOM 15

OFFICE/STUDY/DEN 16

OTHER INDOOR AREA 17

(SPECIFY______________________________________________________)

REFUSE TO ANSWER 97

DON’T KNOW 98

Q28d. During the warm months, are pesticides or chemicals that kill bugs normally applied inside your home using any of the following?

(Check all that apply)

HAND RESPONDeNT PESTICIDE PRODUCTS CARD - Grey

AEROSOL CAN 01

SPRAYER 02

FOGGER 03

FOAM/GEL 04

GRANULES/DUST/POWDER/PELLETS 05

LOTION 06

SHAMPOO 07

BAIT STATION/TRAP 08

CANDLES/COIL 09

FLY STRIP 10

PET COLLAR/SPOT-ON 11

ANY OTHER 12

(SPECIFY______________________________________________________)

REFUSED TO ANSWER 97

DON’T KNOW 98

Q29. During the cold months in your area, did you or anyone else use any pesticides or chemicals to kill bugs inside your home?

YES 1

NO 2

REFUSED TO ANSWER 7

DON’T KNOW 8



(SKIP TO Q30)

Q29a. How often did you or anyone else use pesticides or chemicals to kill bugs inside your home during the cold months?

prompt: On average, how often were they used during the cold months?

DAILY 01

EVERY TWO TO SIX DAYS 02

WEEKLY 03

ONCE EVERY 2 WEEKS (BIWEEKLY) 04

ONCE EVERY 3 WEEKS 05

MONTHLY 06

ONCE EVERY 2 MONTHS (BIMONTHLY) 07

ONCE EVERY 3 MONTHS 08

LESS THAN ONCE EVERY 3 MONTHS 09

REFUSED TO ANSWER 97

DON’T KNOW 98

Q29b. What kinds of bugs were being killed inside your home during the cold months?

(Circle all that apply)

ANTS 01

COCKROACHES 02

CRICKETS 03

FLEAS/TICKS 04

FLIES 05

LICE 06

MOSQUITOES 07

TERMITES 08

WASPS/BEES 09

WATER BUGS 10

BED BUGS 11

REFUSED TO ANSWER 97

DON’T KNOW 98

Q29c. Where were pesticides used inside your home during the cold months?

(Check all that apply)

prompt: read the list as needed

ATTIC 01

BASEMENT 02

BATHROOM – CHILD’S 03

BATHROOM - OTHER 04

BEDROOM – CHILD’S 05

BEDROOM – OTHER 06

CHILD’S PLAY ROOM 07

DINING ROOM 08

FAMILY ROOM 09

GAME ROOM 10

HALLWAY 11

INDOOR ENCLOSED PORCH/SUNROOM 12

KITCHEN 13

LAUNDRY ROOM/UTILITY ROOM 14

LIVING ROOM 15

OFFICE/STUDY/DEN 16

OTHER INDOOR AREA 17

(SPECIFY______________________________________________________)

REFUSE TO ANSWER 97

DON’T KNOW 98

Q29d. During the cold months, are pesticides or chemicals that kill bugs normally applied inside your home by you or someone else using any of the following?

HAND RESPONDENT PESTICIDE PRODUCTS CARD - GREY

AEROSOL CAN 01

SPRAYER 02

FOGGER 03

FOAM/GEL 04

GRANULES/DUST/POWDER/PELLETS 05

LOTION 06

SHAMPOO 07

BAIT STATION/TRAP 08

CANDLES/COIL 09

FLY STRIP 10

PET COLLAR/SPOT-ON 11

ANY OTHER 12

(SPECIFY______________________________________________________)

REFUSED TO ANSWER 97

DON’T KNOW 98  (SKIP TO Q32)

Q30 DELETED – freqUENCY OF PESTICIDE APPLICATION

Q31 DELETED – FREQUNCY OF PESTICIDE APLLICATION

Q31a. During the most recent use of a pesticide or chemical to kill bugs in your home, where was it applied inside your home?

(Circle all that apply)

prompt: read the list as needed

ATTIC 01

BASEMENT 02

BATHROOM – CHILD’S 03

BATHROOM - OTHER 04

BEDROOM – CHILD’S 05

BEDROOM – OTHER 06

CHILD’S PLAY ROOM 07

DINING ROOM 08

FAMILY ROOM 09

GAME ROOM 10

HALLWAY 11

INDOOR ENCLOSED PORCH/SUNROOM 12

KITCHEN 13

LAUNDRY ROOM/UTILITY ROOM 14

LIVING ROOM 15

OFFICE/STUDY/DEN 16

OTHER INDOOR AREA 17

(SPECIFY______________________________________________________)

REFUSE TO ANSWER 97

DON’T KNOW 98

Q31b. During the most recent use, how was the pesticide or chemical applied inside your home?

HAND RESPONDENT PESTICIDE PRODUCTS CARD - GREY

AEROSOL CAN 01

SPRAYER 02

FOGGER 03

FOAM/GEL 04

GRANULES/DUST/POWDER/PELLETS 05

LOTION 06

SHAMPOO 07

BAIT STATION/TRAP 08

CANDLES/COIL 09

FLY STRIP 10

PET COLLAR/SPOT-ON 11

ANY OTHER 12

(SPECIFY)______________________________________________________

REFUSED TO ANSWER 97

DON’T KNOW 98

Q31c. Who used the pesticides or chemical inside your home in the most recent use?

SELF (YOU) 01

FAMILY MEMBER 02

PROFESSIONAL PEST CONTROL

APPLICATOR 03  (SKIP TO Q31e)

BUILDING MAINTENANCE STAFF 04  (SKIP TO Q31e)

OTHER 05  (SKIP TO Q31e)

REFUSED TO ANSWER 07  (SKIP TO Q32)

DON’T KNOW 08  (SKIP TO Q32)

Q32. During the past 30 days, was any pesticide or chemical used by you or anyone else to kill bugs outside your home?

YES 1

NO 2

REFUSED TO ANSWER 7

DON’T KNOW 8



(SKIP TO Q34)

Q33. During the past year, was any pesticide or chemical used by you or anyone else to kill bugs outside your home?

YES 1

NO 2

REFUSED TO ANSWER 7

DON’T KNOW 8

HAND RESPONDENT WORK ACTIVITIES CARD - GREEN

Q34. This card has a list of work activities. In the last six months [IF NEEDED AND IN HOUSE LESS THAN 6 MONTHS: Since you moved to this address], have you or has anyone in your household done any of these activities at work? [CIRCLE ALL THAT APPLY]

CONSTRUCTION/PAINT ACTIVITIES

01. BUILDING DEMOLITION

02. PAINT REMOVAL (INCLUDING SANDING OR SCRAPING)

03. PLUMBING

04. SANDBLASTING (INCLUDING OUTDOOR DECKING/PORCH FLOORING)

05. PRESSURE-TREATED WOOD CONSTRUCTION (DECKS, FENCES, PLAYSETS, FURNITURE, OTHER OUTDOOR STRUCTURES)

06. PRESSURE CLEANING/WASHING WOOD STRUCTURES (DECKS, FENCES, PLAYSETS, FURNITURE, OTHER OUTDOOR STRUCTURES)

INDUSTRY ACTIVITIES

07. BATTERY MANUFACTURING OR SALVAGE WORK

08. EXPLOSIVE OR AMMUNITION WORK

09. FOUNDRY WORK

10. GLASS WORK

11. LEAD SMELTER WORK

12. OIL REFINERY WORK

13. OTHER LEAD-RELATED INDUSTRY WORK

14. PESTICIDE/CHEMICAL-RELATED WORK

15. WOOD TREATMENT PLANT/MILLWORK PLANT

MISCELLANEOUS (LEAD)

16. CAR RADIATOR REPAIR

17. MAKING OR SPLICING CABLE

18. WORK AT A FIRING RANGE OR POLICE WORK

19. WELDING OR TORCH CUTTING

ANIMAL CARE

20. ANIMAL CARE WORKER/VETERINARIAN

21. EXTERMINATION OF PESTS

FARMING/LANDSCAPING

22 AGRICULTURAL/HORTICULTURAL/LANDSCAPE RELATED WORK

23 NONE (SKIP TO Q35)

98. DON’T KNOW (SKIP TO Q35)

Q34a. How often does anyone who does this work wear or bring his or her work clothes home?

NEVER 1  (SKIP TO Q35)

RARELY 2

OFTEN 3

ALWAYS 4

DON’T KNOW 8  (SKIP TO Q35)

Q34b. Do you usually wash or clean these work clothes here at home?

YES 1

NO 2

DON’T KNOW 8

HAND RESPONDENT HOME ACTIVITIES CARD - PINK

Q35. The card lists several activities that can be done at home. In the last six months [IF NEEDED, AND IN HOME LESS THAN 6 MONTHS: Since you moved to this address], have you or anyone in your household participated in any of these activities here at home?

[CIRCLE ALL THAT APPLY]

01. MAKE BULLETS OR FISHING SINKERS

02. PAINT CARS OR BICYCLES

03. RELOAD BULLETS, TARGET SHOOT, OR HUNT

04. REMOVE PAINT FROM ANY PART OF THE HOUSE

05. REMOVE PAINT FROM FURNITURE

06. SAND OR PAINT PARTS OF THE HOUSE

07. SOLDER ELECTRONIC PARTS

08. SOLDER PIPES OR METAL

09. USE ARTISTS’ PAINT (JEWELRY, PICTURES)

10. WORK WITH STAINED GLASS

11. WORK WITH POTTERY OR GLAZES

12. BUILD/SAND/SANDBLAST OR PAINT OUTDOOR WOODEN DECKING/WOODEN FLOORING OR WOODEN PATIO FURNITURE/PLAYSETS

13. PRESSURE CLEANING/WASHING WOOD STRUCTURES (DECKS, FENCES, PLAYSETS, FURNITURE, OTHER OUTDOOR STRUCTURES)

15. NONE

98. DON’T KNOW

Q36. Is this home used for childcare? By childcare I mean someone in the house is paid to take care of children.

YES 1

NO 2  (SKIP TO Q37)

DON’T KNOW 8  (SKIP TO Q37)

Q36a. Not including children who live here, how many children are cared for in this house for pay?

NUMBER OF CHILDREN |__| |__|

REFUSED 997

DON’T KNOW 998

Q36b. Is this a licensed home childcare?

YES 1

NO 2

DON’T KNOW 8

Q36c. Which rooms in this home are used for childcare?

Room Name Room Code from Room Inventory

__________________ ___________________________

Q37. Is there a garage attached to your home?

YES 1

NO 2  (SKIP TO 38)

DON’T KNOW 8  (SKIP TO 38)

Q37a. Do you ever start your car in the garage with the garage door closed?

YES 1

NO 2  (SKIP TO 35)

DON’T KNOW 8  (SKIP TO 35)

Q37b. How long do you usually let it run in the garage?

[INTERVIEWER NOTE: IF RESPONDENT GIVES RANGE OF TIME, RECORD LONGEST TIME.]

NUMBER OF MINUTES |__| |__|

DON’T KNOW 998

Q38. How many times in last two months have you had to reset a circuit breaker or replace a fuse?

NONE 1

ONCE 2

2 OR MORE TIMES 3

DON’T KNOW 8

3. People

Now I need to ask a few questions about the people who live in this home.

Q39. How many people live in this household?

NUMBER OF PEOPLE |__| |__|

REFUSED 997

DON’T KNOW 998

INTERVIEWER NOTE: NUMBER OF PEOPLE LISTED IN Q38 MUST MATCH NUMBER GIVEN IN Q37. IN Q38, RESPONDENT DOES NOT HAVE TO GIVE NAMES; RELATIONSHIPS (E.G. SON, DAUGHTER, ETC) ARE ACCEPTABLE.

Q40. For each person, please tell me his or her gender, and age. I will then need to record whether each person is Hispanic or Latino, his or her race, level of education and then finally some questions about allergies. Let’s begin with you.

INTERVIEWER NOTE: LIST ALL THE HOUSEHOLD MEMBERS, THEN ASK ALL QUESTIONS ACROSS A ROW FOR EACH PERSON BEFORE PROCEEDING TO THE NEXT PERSON

HAND RESPONDENT THE RACE AND EDUCATION CODES CARD – PURPLE

	Q40a.	Q40b.	Q40c.	Q40d.	Q40e.	Q40f.
	Person	Gender	Age	Do you/ (does next) consider self Hispanic or Latino?	Race Code(s)	Education Code(s)
1	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
2	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
3	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
4	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
5	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
6	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
7	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
8	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
9	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
10	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
11	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
12	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
13	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
14	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2
15	__________________	Male 1 Female 2		YES (H/L) 1 NO (H/L) 2

[CHECK: DOES THE NUMBER OF PEOPLE LISTED IN Q40 CORRESPOND WITH THE NUMBER GIVEN IN Q39?…YES____CONTINUE NO_____ {GO BACK AND CORRECT Q39 OR ADD PEOPLE TO Q40}]

Q41. Has a doctor ever diagnosed anyone in your household with allergies?

YES 1

NO 2

DON’T KNOW 8



(GO TO Q42)

Q41a. Did a doctor ever say that anyone in your household has…

YES NO DK

Q41a1. HAY FEVER (ALLERGIC RHINITIS) 1 2 8

Q41a2. SKIN ALLERGIES 1 2 8

Q41a3. FOOD ALLERGIES 1 2 8

Q42. Has a doctor ever diagnosed anyone in your household with asthma, including adults that had childhood asthma?

YES 1

NO 2

DON’T KNOW 8



(GO TO Q44)

Q43. Does anyone in your household currently take medication for asthma?

YES 1

NO 2

DON’T KNOW 8

Q43a. Has anyone in your household visited an emergency room or been hospitalized for asthma in the past year?

YES 1

NO 2

DON’T KNOW 8

Q44. Do any members of your household smoke cigarettes?

YES 1

NO 2

DON’T KNOW 8



(SKIP TO Q44b)

Q44a. How often are cigarettes smoked inside the house?

LESS THAN ONCE A DAY 1

1-3 TIMES A DAY 2

4-10 TIMES A DAY 3

MORE THAN 10 TIMES A DAY 4

DON’T SMOKE INSIDE THE HOUSE 5

DON’T KNOW 8

Q44b. Do any members of your household smoke cigars, pipes or other types of tobacco products?

YES 1

NO 2

DON’T KNOW 8



(SKIP TO Q45)

Q44c. How often are cigars, pipes or other types of tobacco products smoked inside the house?

LESS THAN ONCE A DAY 1

1-3 TIMES A DAY 2

4-10 TIMES A DAY 3

MORE THAN 10 TIMES A DAY 4

DO NOT SMOKE INSIDE THE HOUSE 5

DON’T KNOW 8

Q45. These next questions provide us with information that will help us when we analyzing the dust samples.

		1.	2.	3.	4.	5.
		KITCHEN	COMMON LIVING AREA	BEDROOM	OTHER ROOM	BASEMENT
	ENTER ROOM CODE FROM ROOM INVENTORY FORM	1___	2___	3___	_____	_____
Q45a	How long ago was the floor or carpet last cleaned? (not including shampooing or steam cleaning)	DAYS \|__\| \|__\| WEEKS \|__\| \|__\| DON’T KNOW 8	DAYS \|__\| \|__\| WEEKS \|__\| \|__\| DON’T KNOW 8	DAYS \|__\| \|__\| WEEKS \|__\| \|__\| DON’T KNOW 8	DAYS \|__\| \|__\| WEEKS \|__\| \|__\| DON’T KNOW 8	DAYS \|__\| \|__\| WEEKS \|__\| \|__\| DON’T KNOW 8
Q45b	How was the floor or carpet last cleaned? [CIRCLE MOST RECENT METHOD]	VACUUMED 1 MOPPED 2 SWEPT 3 OTHER 4 Specify:______________ DON’T KNOW 8	VACUUMED 1 MOPPED 2 SWEPT 3 OTHER 4 Specify:______________ DON’T KNOW 8	VACUUMED 1 MOPPED 2 SWEPT 3 OTHER 4 Specify:______________ DON’T KNOW 8	VACUUMED 1 MOPPED 2 SWEPT 3 OTHER 4 Specify:______________ DON’T KNOW 8	VACUUMED 1 MOPPED 2 SWEPT 3 OTHER 4 Specify:______________ DON’T KNOW 8
Q45c	When was the last time the carpet or rug was shampooed or steamed cleaned?	1-4 WEEKS 1 1-6 MONTHS 2 7-12 MONTHS 3 >1 YEAR 4 NEVER 5 NO CARPET/RUG 6 DON’T KNOW 8	1-4 WEEKS 1 1-6 MONTHS 2 7-12 MONTHS 3 >1 YEAR 4 NEVER 5 NO CARPET/RUG 6 DON’T KNOW 8	1-4 WEEKS 1 1-6 MONTHS 2 7-12 MONTHS 3 >1 YEAR 4 NEVER 5 NO CARPET/RUG 6 DON’T KNOW 8	1-4 WEEKS 1 1-6 MONTHS 2 7-12 MONTHS 3 >1 YEAR 4 NEVER 5 NO CARPET/RUG 6 DON’T KNOW 8	1-4 WEEKS 1 1-6 MONTHS 2 7-12 MONTHS 3 >1 YEAR 4 NEVER 5 NO CARPET/RUG 6 DON’T KNOW 8

Q46. Do you have a vacuum cleaner?

YES 1

NO 2  (SKIP TO Q47)

DON’T KNOW 8  (SKIP TO Q47)

Q46a. Is your main vacuum cleaner a bagless vacuum cleaner?

YES 1

NO 2

DON’T KNOW 8

IF 46a IS "YES," USE SECOND PHRASE FOR 46b AND 46c.

Q46b. How long since the vacuum bag was changed? / How long since you emptied the vacuum cleaner cup?

NUMBER |___|___|

WEEKS 1

MONTHS 2

YEARS 3

DON’T KNOW 8

Q46c. Has the vacuum cleaner bag only been used at this home? / Since you emptied the cup, has the vacuum cleaner only been used in this house?

YES 1  (GO TO BOX, BELOW)

NO 2  (SKIP TO Q47)

DON’T KNOW 8  (SKIP TO Q47)

INTERVIEWER NOTE: IF 46c IS "YES," AND RESPONDENT USES VACUUM CLEANER BAGS, READ:

When we end this interview, I am going to ask you to give me the bag from your vacuum cleaner.

IF 46c IS "YES," AND RESPONDENT TELLS YOU THEY HAVE A BAGLESS VACUUM CLEANER, READ:

When we end this interview, I will empty the contents of your container into a plastic bag.

These next few questions are general questions to help us categorize your home for the survey.

Q47. Do you own or rent this home?

OWN 1  (SKIP TO Q51)

RENT 2

REFUSED 7  (SKIP TO Q51)

DON’T KNOW 8

Q48. Is the housing authority your landlord or is your house/apartment privately owned?

HOUSING AUTHORITY ................1

PRIVATE LANDLORD 2  (SKIP TO Q50)

REFUSED. ........................................7

DON’T KNOW 8

Q49. Is your rent amount lower because you are in either a Federal, State or local government-housing program?

YES 1

NO 2

REFUSED 7

DON’T KNOW 8



(SKIP TO Q51)

Q50. Each year, as part of your rental agreement, is your household required to complete recertification by reporting income to determine the amount of rent you pay?

YES 1

NO 2

REFUSED 7

DON’T KNOW 8

Q51. I need to ask about your 2016 household income. This information will never be associated with your household. Was the total 2016 income for the household below or above $35,000?

BELOW $35,000 1  (INCOME CARD A-YELLOW)

$35,000 OR MORE 2  (INCOME CARD B-WHITE)

DON’T KNOW 8

HAND RESPONDENT CARD WITH INCOME CATEGORIES AS SPECIFIED IN Q50 ABOVE.

Q52. Which number on the card represents your total household income for 2016?

Up to $ 4,999 01

$ 5,000 to $ 9,999 02

$ 10,000 to $ 14,999 03

$ 15,000 to $ 19,999 04

$ 20,000 to $ 34,999 05

$ 35,000 to $ 49,999 06

$ 50,000 to $ 69,999 07

$ 70,000 to $ 89,999 08

$ 90,000 to $119,999 09

$120,000 or above 10

REFUSED 97

DON’T KNOW 98

END: We have now finished with all our survey questions. Thanks so much for answering these questions. Now, if you don’t mind I would like to perform a quick household walkthrough with you to survey household features, including those that may have an impact on safety. (Interviewer begins to stand) then after we do a quick walkthrough, I would like to collect your vacuum cleaner bag from your vacuum (ON INTERIOR WALK THROUGH FORM -> CONTINUE WITH WALK THROUGH FORM.)

TIME ENDED: ______________ (AM/PM)

Dwelling Unit ID___________________

RESPONDENT REFUSAL/BREAK-OFF REPORT

B1. What was the reason you were unable to proceed with testing the dwelling unit?

UNIT INELIGIBLE 1  (CONTINUE WITH B2)

RESPONDENT REFUSED TO

PARTICIPATE 2  (SKIP TO B3)

ADDRESS INCORRECT 3  (SKIP TO B8)

LANGUAGE PROBLEM 4  (SKIP TO B10)

NO ADULT IN HOUSEHOLD 5  (SKIP TO B10)

OTHER 6  (SKIP TO B3)

SPECIFY __________________________________________________________

B2. Explain in detail how you verified the unit was ineligible:

___________________________________________________________________________

______________________________________________________________  (SKIP TO B10)

B3. What were the reasons given for the refusal?

(Circle all that apply)

too BUSY 01

DOES NOT WANT TO KNOW ABOUT LEAD,

ALLERGENS OR OTHER ENVIRONMENTAL

CONTAMINANTS IN HOUSE 02

DID NOT UNDERSTAND LETTER

(TOO TECHNICAL) 03

wORRY ABOUT LEAD DISCLOSURE

RULE 04

SURVEY TOO LONG/TOO MUCH TIME

IN HOUSE 05

Negative reaction to

government surveys 06

INCENTIVE INSUFFICIENT 07

What would be persuasive?_____________________________________________

needs more information 08

What is needed?_____________________________________________________

needs request in writing 09

NEEDS US TO ASK OWNER 10

(OWNERS NAME AND PHONE__________________________________________)

other 11

(specify___________________________________________________________)

B4. Strength of refusal: (CIRCLE ONE)

MILD, NO HOSTILITY 1

FIRM, BUT NOT HOSTILE 2

HOSTILE 3

B5. What methods did you use to persuade respondent to participate:

___________________________________________________________________________

B6. Did you ask to speak to any other person in the household?

YES 1

NO 2  (SKIP TO B8)

B7. What happened with that other person?

__________________________________________________________________________

B8. Would you recommend contacting the household again?

YES 1  (SKIP TO B10)

NO 2

B9. Explain why you would not recommend contacting the household again.

___________________________________________________________________________

B10. Did you call the QuanTech office?

YES 1

NO 2  (CALL QUANTECH OFFICE)

B11. What was the result of your call to the home office?

___________________________________________________________________________

___________________________________________________________  (END)

I6- INTERIOR WALKTHROUGH OBSERVATIONS
Staff Involved:	Assigned Interviewer
Overview: After the Resident Questionnaire has been completed (protocol I5), the Interviewer is directed to perform data collection using the Interior Walkthrough Observations form programmed into the tablet (see form at end of this protocol). These efforts include cleanliness and clutter observations, safety observations, collection of the resident vacuum bag, and measurement of hot water temperature.
Data Recording on:		Resident Questionnaire Form Set (same one started in I3)
Equipment Needed from Kit (W)
1 backpack to hold tablet and other supplies 1 Samsung Galaxy tablet 1 Backup Resident Questionnaire (needed only if tablet fails) 1 blue pen 1 clipboard 1 thermometer (for hot water temp measurement)					1 flashlight with extra batteries (use for all protocols all DUs) 1 tape measure (25’) gloves cleaning wipes trash bag
Supplies Needed from Kit (B) - Subkit I6
1 row of 4 self-adhesive, pre-printed ID labels inside re-closable bag 2 13"x17.5" Polypropylene Bag (for vacuum cleaner bag)				2 8"x10" Polypropylene Bags (for "Bagless" vacuum cleaner cup contents)
Glove Use Directives:			Use new (see protocol I0)

Procedure

1. Conduct walk through using Tablet to record data. Using the Resident Questionnaire Form Set for the assigned DU that is programmed into the tablet (see equivalent forms at end of this protocol), perform data collection to capture interior household walk-through data. Be sure to visit and collect data on the entire house (if allowed) not just the rooms selected for later testing.

1.1 Complete recording of household cleanliness and clutter data.

1.2 Collect and store vacuum bag sample. Collect a vacuum bag if the respondent replied YES to Q46c (Has the vacuum cleaner bag only been used at this home? / Since you emptied the cup, has the vacuum cleaner only been used in this house?). When the time for the vacuum bag collection is reached, obtain and store this sample using the following parameters:

1.2.1 Locate vacuum. Ask the resident to show you the vacuum as prompted by the Resident Questionnaire Form Set

1.2.2 Don a pair of gloves. If possible, for personal protection, don a pair of lab gloves before handling the vacuum bag. If this is not possible, you can use a cleaning wipe to clean your hands after handling this sample.

1.2.3 Ask Resident to remove and hand you the vacuum bag or dust container. Ask the Resident to remove the bag or dust container from their vacuum cleaner to avoid causing any damage to their vacuum.

1.2.3.1 For vacuum bags, very slowly place bag in larger polypropylene (sample) bag and seal it. Take care to avoid spreading dust in the house. If possible, take the bag outside to gently squeeze air out so it will fit in the sample bag.

1.2.3.2 For bagless vacuums, very slowly pour the contents into the smaller polypropylene (sample) bag and seal it. Take care to avoid spreading dust in the house. If possible, take the vacuum outside to make this transfer into the sample bag.

1.2.4 Assign unique ID number to collected sample (3 places).

1.2.4.1 Place sample ID label on sample bag. Place a Sample ID label on the bag using the first row of 4 Sample ID labels provided with Sub-kit I6. Then place this labeled bag into another sample bag of similar size and seal it.

1.2.4.2 Place sample ID label on Chain of Custody form. Place a second replicate ID label (same ID number) on a chain of custody form and complete the appropriate entries on this form and temporarily store the collected sample with chain of custody form.

1.2.4.3 Record sample ID on the indicated place in the tablet (on the electronic version of the Household Walkthrough form) where data is recorded on the Vacuum Cleaner Bag Collection.

2. Move on to the Room Observation and Building Moisture Measurements (protocol I7).

Dwelling Unit ID#_______________

Emergency Phone Numbers

Are poisoning or emergency phone numbers posted near at least one phone?

Yes 1

No 2

If Yes, where located?

In Room?

On Phone?

Visible from Phone?

Distance from Phone?

Yes 1

No 2

Yes 1

No 2

Yes 1

No 2

______ FT

Fire Extinguishers

Is there a fire extinguisher in the house? Yes 1 No 2	If PRESENT
	ROOM	CODE	charge status	EXPIRED?	type(s)
			Charged 1 Not Charged 2 Can’t Tell 3	Yes 1 No 2	ABC 1 A 2 B 3 C 4
			Charged 1 Not Charged 2 Can’t Tell 3	Yes 1 No 2	ABC 1 A 2 B 3 C 4
			Charged 1 Not Charged 2 Can’t Tell 3	Yes 1 No 2	ABC 1 A 2 B 3 C 4
			Charged 1 Not Charged 2 Can’t Tell 3	Yes 1 No 2	ABC 1 A 2 B 3 C 4

Smoke Alarms

Smoke alarm(s) present in home?

Yes 1

No 2 (SKIP TO NEXT PAGE)

TYPE

Central System 1

Battery Operated 2

level(s) OF HOME

(circle all that apply)

- 0 - 1 - 2

- 3 - 4 - 5

nUMBER present

__________

Are smoke alarm(s) present where all household members sleep (in room or immediately outside room)?

Yes 1

No 2

IF NO, number of rooms not covered by smoke alarm?

__________

TEST ALARMS – ARE ALL OPERABLE?

Yes 1

No 2

Can’t Test 3

If no, How many are not operational?

__________

Stairway/Hallways

Stairways

Flooring Type

(circle all that apply)

If area rug OR MAT, skid resistant?

HAND RAILS PRESENT?

Yes 1

No 2

BOTH SIDES?

Yes 1

No 2

Mat (2’x3’ or less) 1

Area rug 2

Wall-to-wall carpet 3

Cement/brick 4

Wood Flooring 5

Vinyl Tile 6

Grouted Tile 7

Linoleum 8

Other 9

Yes 1

No 2

OPENING > 6”?

Yes 1

No 2

Halls

Mat (2’x3’ or less) 1

Area rug 2

Wall-to-wall carpet 3

Cement/brick 4

Wood Flooring 5

Vinyl Tile 6

Grouted Tile 7

Linoleum 8

Other 9

Yes 1

No 2

Window Guards and Stops

Are there rooms on a second story or higher above true ground level?

Yes 1

No 2

IF YES Are window guards or stops present on the windows in any of the rooms that are second story or higher above true ground level?

Yes 1

No 2

No access 3

Grab bars (bathrooms) – do not include towel racks

Room #

Type

grab bars present?

If yes, where located?

(circle all that apply)

Child safety locks?

(circle all that apply)

Half 1

Full 2

Yes 1

No 2

Wall inside tub 1

Wall outside tub 2

Near toilet 3

Other 4

Toliet 1

Cabinets 2

None 3

Half 1

Full 2

Yes 1

No 2

Wall inside tub 1

Wall outside tub 2

Near toilet 3

Other 4

Toliet 1

Cabinets 2

None 3

Half 1

Full 2

Yes 1

No 2

Wall inside tub 1

Wall outside tub 2

Near toilet 3

Other 4

Toliet 1

Cabinets 2

None 3

Half 1

Full 2

Yes 1

No 2

Wall inside tub 1

Wall outside tub 2

Near toilet 3

Other 4

Toliet 1

Cabinets 2

None 3

Air Cleaning Devices

Air cleaning device present? Yes 1 No 2 (Continue to Thank You)
ROOM CODE	TYPE	MAKE/MODEL	Does unit produce ozone?	Ozone rating (mg/hr)	# Hours use per week	How often is the filter changed?
	Built In 1 Portable 2		Yes 1 No 2 DK 8			Annually 1 Bi-annually 2 Quarterly 3 As needed 4 Don’t know 5
	Built In 1 Portable 2		Yes 1 No 2 DK 8			Annually 1 Bi-annually 2 Quarterly 3 As needed 4 Don’t know 5
	Built In 1 Portable 2		Yes 1 No 2 DK 8			Annually 1 Bi-annually 2 Quarterly 3 As needed 4 Don’t know 5
	Built In 1 Portable 2		Yes 1 No 2 DK 8			Annually 1 Bi-annually 2 Quarterly 3 As needed 4 Don’t know 5

Home Cleanliness (Circle one):	Household Clutter Code (Circle one):
Appears clean 1	Organized, nothing out of place 1
Some evidence of housecleaning 2	Average amount of clutter 2
No evidence of housecleaning 3	Lack of organization, nothing in place 3

Combustion Source Information	Present?
Combustion Source Information	Present?
Combustion furnace present?	Yes 1 No 2
Gas stove/ fireplace present?	Yes 1 No 2
Wood fireplace present?	Yes 1 No 2
Gas hot water heater present?	Yes 1 No 2
Gas dryer present?	Yes 1 No 2
Gas cook stove/oven present?	Yes 1 No 2
Portable fuel-fired heater present?	Yes 1 No 2
Other combustion source present? (SPECIFY:_______________________________________________)	Yes 1 No 2
CO monitor present in home?	Yes 1 No 2
Cook stove fan exhausts to outside?	Yes 1 No 2

Thank you very much. I will begin my environmental sample collection now. I will need your vacuum cleaner bag or the contents from your bag-less vacuum container.

INTERVIEWER NOTE: Look at the answer to question Q46c [Has the vacuum cleaner bag only been used at this home? / Since you emptied the cup, has the vacuum cleaner only been used in this house?]

Collect the vacuum cleaner bag sample if they answered YES to this question.

Skip collection of the vacuum bag sample If they answered NO or DONT KNOW to this question.

Vacuum Cleaner Bag Collection

Vacuum cleaner Present?

Yes 1

No 2

If yes, type of vacuum system used most:

Standard Vacuum (w/bag) 1

Bag-less Vacuum (no bag) 2

Central house collection system (duct reservoir) 3

If yes, Enter Make _____________ Model No. ____________

Field sample ID label here

Sample collected?

Yes 1

No 2

If no sample, reason:

No vacuum cleaner 1

Vacuum used at other house 2

Respondent refused 3

Unable to access bag/container 4

No replacement bag available 5

Other 6

SPECIFY: _______________________

AHHS Field Chain-of-Custody for Vacuum Bag Sample
DU ID:
Completed by:					on
	(name)					(date)
Sample ID		TYPE Bulk Dust in Vacuum Bag	Comments
Field sample ID label here		X
Relinquished by: Date / Time:				Relinquished by: Date / Time:
Received by: Date / Time: Condition Acceptable?  Yes  No				Received by: Date / Time: Condition Acceptable?  Yes  No

I7- ROOM OBSERVATION and BUILDING MOISTURE MEASUREMENTS
Staff Involved:	Assigned Interviewer
Overview: After the Interior Walkthrough Observations have been completed (protocol I6), the Interviewer is directed to perform data collection using the Room Observation Measurements form and the Building Materials Moisture Testing Log that is programmed into the Samsung Galaxy tablet (see equivalent forms at end of this protocol). These efforts include measurement of room dimensions, temperature and humidity from all the primary rooms designated on the Room Inventory form (protocol I4), and building moisture testing in 3 rooms. These efforts are conducted on a room-by-room basis. Making room observations and building measurements while in the same room is designed to save time. It is more efficient than going back to the 3 rooms targeted for moisture measurements after collecting room observation measurements in all the rooms.
Data Recording on:		Technician Form Set (bound) pulled from Kit (B)
Equipment Needed from Kit (W)
1 Samsung Galaxy Tablet 1 backpack to hold tablet and other supplies 1 duffel bag to carry other supplies 1 clipboard 1 blue ink pen 1 compass 1 flashlight with extra batteries				1 tape measure (25’) 1 Humidity/Temperature Meter (air measurements) 1 moisture meter (building materials measurements) 1 Backup Resident Questionnaire (needed only if tablet fails) 1 Break-off Report (loose; if needed in case of a break-off)
Supplies Needed from Kit (B) - Subkit T7
3 rows of 4 self-adhesive, pre-printed ID labels
Glove Use Directives:			Use new (see protocol I0)

Procedure

1. Collect data in each of the four primary rooms and basement (if one exists) one room at a time using the Room Observation Measurements form and Building Materials Moisture Testing Log programmed into the tablet (see equivalent forms at end of this protocol).

1.1 Perform room observation measurements following the directives shown in the Room Observation forms.

1.1.1 Record Room ID numbers from completed Room Inventory form. The room ID fields are obtained from the completed room Inventory form (from protocol I4).

1.1.2 Record building level. Use same rules as for completing Room Inventory form. Use this as a check against the original level assignment on that form.

1.1.3 Record carpet types.

1.1.4 Record air temperature and humidity measurements using the temperature/humidity meter. See Operating Instructions for Temperature/Humidity Meter.

1.1.5 Record room dimensions using your tape measure.

1.1.5.1 Wall height. Measure in feet and inches to closest 1 inch.

1.1.5.2 Wall length. Measure in feet to closest 1 foot. If the room is not rectangular, provide the north (x direction) and east (y direction) measurements that when multiplied together give the best estimate of the floor area in the room.

1.1.5.3 Number of windows, doors and unpainted surfaces. For each component (windows, doors, and unpainted surfaces), record total number observed on each wall as indicated on the form.

Doors that are mostly glass are considered windows on this form.
The primary example of an unpainted area is an open doorway (a cased opening that has no door).

1.1.5.4 Height of windows, doors and unpainted surfaces. For each component (windows, doors, and unpainted surfaces), record the height of the component in feet to closest 0.5 feet (6 inches).

If the component height varies in the room, record an estimated average height.

1.1.5.5 Combined width of windows, doors and unpainted surfaces. For each component (windows, doors, and unpainted surfaces), record the total combined width of that component present in the room. Measure in feet to closest 0.5 feet (6 inches).

Window widths are to be measured from the left edge of the window trim (where it meets the wall) across the window to the right edge of the window trim where it meets the wall.
Door widths are likewise measured from trim edge to trim edge.

1.2 Perform building moisture measurements when in CLA, BR or the Basement following the directives shown in the Building Materials-Moisture Testing Log form, using the moisture meter. Use the following parameters to make these measurements:

1.2.1 Record Room ID numbers from completed Room Inventory form. The room ID fields are obtained from the completed room Inventory form.

1.2.2 Examine all the room walls for water damage and record the estimated area of this damage in square feet of surface area.

1.2.3 Pick a wall to test with accessible interior and exterior surface. If possible, pick a wall that is accessible on both the interior (inside the selected room) and the exterior (outside the selected room but still inside the DU). Note: No moisture measurements are to be made on the exterior of the DU. If no wall is accessible on the exterior inside the DU, then pick any accessible interior wall.

1.2.4 Record building moisture measurements on the interior wall using the moisture meter as indicated on the Building Materials-Moisture Testing Log form at 3 inches, 3 feet and 6 feet off the floor. See Operating Instructions for Building Moisture Meter.

1.2.5 Record building moisture measurements on the exterior wall using the moisture meter as indicated on the Building Materials-Moisture Testing Log form at 3 inches, 3 feet and 6 feet off the floor. If it cannot be tested indicate so on the form Building Materials-Moisture Testing Log.

1.2.6 Record building moisture measurements on up to 2 areas that have visible water damage stains using the moisture meter near the center of the damaged areas as indicated on the Building Materials-Moisture Testing Log. Look around the room for any signs of visible water damage. These areas may be on a wall other than the one tested above. If there are more than 2 areas, select the two that look the worst of those that are accessible.

2. Move on to collect the Vacuum Dust Sampling - Allergens & Mold (protocol I7).

Operating Instructions for Temperature/Humidity Meter (Testo 615)

1. Go to the center of the room and turn on the meter by pressing the white I/O button. After about 6 seconds, the active display screen should show the following information:

A small black arrow in the top left corner pointing up at "%" marked on the meter case. This is the indicator that verifies that the top large number is in % relative humidity.
- If this arrow at the bottom of the screen pointing down to "td" marked on the meter case, then press the %/td button to toggle the arrow back to the top pointing up at "%".
A large number towards the top center (with no units). This is the number that is recorded in the Room Humidity field on Room Inventory Form.
A large number towards the bottom followed by the units (ºF). This is the number that is recorded in the Room Temperature field on Room Inventory Form.
- If a ºC is displayed, then the meter is displaying degrees centigrade and must be changed to Fahrenheit. See Instructions on changing ºC to ºF.

2. Hold the meter away from you (so that your body does not affect the readings) and press the HOLD MAX/MIN button. "Hold" will be displayed on the screen and this will freeze the screen so you can record the data on the Room Observation Form (on the tablet).

3. Press the HOLD MAX/MIN button three more times to get back to the active display screen before taking any other readings. The active display screen shows only the two numbers (humidity and temperature) with no "Hold", "Max", or "Min" indicators.

4. Turn off the meter by pressing the white I/O button.

Instructions on changing ºC to ºF (Testo 615)

1. Turn off the meter by pressing the I/O button.

2. Access the options screen by pressing and holding down the HOLD MIN/MAX button while pressing the I/O button to turn on the meter. Do not release the HOLD button until the screen displays a flashing "Auto" and a large "ON".

3. Press the HOLD MIN/MAX button again to change the display to the temperature units (ºC or ºF)

4. Toggle between the temperature units by pressing the %/td button. When the desired ºF is reached, press the HOLD MIN/MAX button again, then turn off the meter by pressing the I/O button. Next time you turn on the meter, it will be set to display temperature in the desired ºF.

Operating Instructions for Building Moisture Meter (Tramex meter)

1. Turn on the meter by sliding the on-off button located on the top of the meter. The display meter will show the temperature, the date, and the time. If the date and time are not correct, there is NO NEED to change them to the correct date and time since these settings do not affect the building moisture reading. 2. Press the On button on the keypad to activate the meter.

3. Press the "Wall" key to put the meter into the wall-reading mode of operation. The top right corner indicates the amount of moisture in the wall. It has the following format:

Rel = XXX, where XXX is a number from 000-100.

This XXX number is the only number (Reading) that you will be recording on the Building Materials -Moisture Testing Log.

4. Examine the wall that you are going to test and, for setting the meter, categorize it as one of three substrate wall-types: brick, drywall, or plaster. Then set the meter to the selected wall-type before pressing the meter against the wall and taking a Reading as follows:

To change the wall-type being sampled, press the Wall button. This will take you to a screen that is blank except for the current wall-type (such as Plaster) in the bottom left corner. To scroll the different wall types, use the up and down keys. To select the displayed wall type, press the Enter key. The normal display screen will now show the selected wall-type in the bottom left corner.

NOTES:

For actual wood walls, use the drywall setting

For actual plaster walls, use the plaster setting

For actual drywall or wallboard, use the drywall setting

For actual concrete, concrete block or cinderblock, use the brick setting

5. Press the back of the meter to the selected location on the wall and record the REL= number as the reading on the Building Materials -Moisture Testing Log. Also record the actual substrate type (wood, plaster, drywall-wallboard, concrete-cinderblock-other concrete block) on the Log (do not use the wall-type selected to set the meter!)

NOTE: If the wall type does not change, additional readings at other locations can be collected by simply moving the meter to those locations and pressing the back of the meter to the wall at those locations.

6. When all readings have been collected, turn off the meter by sliding the on-off button located on the top of the meter.

Room Observation Form - KIT							Room ID #_______________
> BUILDING LEVEL (0 = basement): ___________
> ROOM CARPET CODE (circle all that apply): Antislip features? Yes 1 No 2 Mat (2’x3’ or less) 1 Area Rug 2 Wall-to-Wall Carpet 3 Concrete/brick 4 Wood Flooring 5 Vinyl tile/linoleum 6 Grouted tile 7 Other 8 Specify for Other:______________________________________________________
> ROOM WINDOW TREATMENT (circle all that apply): Blinds 1 Curtains 2 Drapes 3 Shades 4 None 5 Other 6....Specify for Other:___________________________________________________________ Blind/curtain cords present? Yes 1 No 2 IF cords present, looped? Yes 1 No 2
> ROOM TEMPERATURE: ________^oF ROOM HUMIDITY: _________%
> ROOM DIMENSIONS:			Avg. Wall Height:	\|__\|\|__\| ft \|__\|\|__\| in				Number		Height (FT)	Combined width (FT)
North wall	Length:	__________ FT		o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
East wall	Length:	__________ FT		o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
South wall				o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
West wall				o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______

> OBSERVATIONS:					Yes	No
Food debris observed?					1	2
Greasy stove?					1	2			No stove present 3
Mildew observed?					1	2
Other moisture evidence?					1	2
Cockroach stains?					1	2
Live/dead cockroaches?					1	2
Room/window Air Conditioner?					1	2
Dehumidifier?					1	2
Humidifier/vaporizer?					1	2
Child safety locks on cabinet drawers/doors?					1	2
Child safety locks on electrical outlets?					1	2			Plugged-in Items - List Codes:
Extension cords plugged into outlets?					1	2
Power Strips plugged into outlets?					1	2
Multi outlet adapters plugged into outlet?					1	2
Plugged-in Items Codes: 1=Lamps/clocks/fans 2=Cooking/Microwaves 3=Computer/Entertainment 4=Space heater/AC 5=Other _______________________________________________________

Room Observation Form - CLA							Room ID #_______________
> BUILDING LEVEL (0 = basement): ___________
> ROOM CARPET CODE (circle all that apply): Antislip features? Yes 1 No 2 Mat (2’x3’ or less) 1 Area Rug 2 Wall-to-Wall Carpet 3 Concrete/brick 4 Wood Flooring 5 Vinyl tile/linoleum 6 Grouted tile 7 Other 8 Specify for Other:______________________________________________________
> ROOM WINDOW TREATMENT (circle all that apply): Blinds 1 Curtains 2 Drapes 3 Shades 4 None 5 Other 6....Specify for Other:___________________________________________________________ Blind/curtain cords present? Yes 1 No 2 IF cords present, looped? Yes 1 No 2
> ROOM TEMPERATURE: ________^oF ROOM HUMIDITY: _________%
> ROOM DIMENSIONS:			Avg. Wall Height:	\|__\|\|__\| ft \|__\|\|__\| in				Number		Height (FT)	Combined width (FT)
North wall	Length:	__________ FT		o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
East wall	Length:	__________ FT		o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
South wall				o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
West wall				o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______

> OBSERVATIONS:					Yes	No
Food debris observed?					1	2
Greasy stove?					1	2			No stove present 3
Mildew observed?					1	2
Other moisture evidence?					1	2
Cockroach stains?					1	2
Live/dead cockroaches?					1	2
Room/window Air Conditioner?					1	2
Dehumidifier?					1	2
Humidifier/vaporizer?					1	2
Child safety locks on cabinet drawers/doors?					1	2
Child safety locks on electrical outlets?					1	2			Plugged-in Items - List Codes:
Extension cords plugged into outlets?					1	2
Power Strips plugged into outlets?					1	2
Multi outlet adapters plugged into outlet?					1	2
Plugged-in Items Codes: 1=Lamps/clocks/fans 2=Cooking/Microwaves 3=Computer/Entertainment 4=Space heater/AC 5=Other _______________________________________________________

After completing this form, complete the Building Moisture Measurements for this room

Room Observation Form - BR							Room ID #_______________
> BUILDING LEVEL (0 = basement): ___________
> ROOM CARPET CODE (circle all that apply): Antislip features? Yes 1 No 2 Mat (2’x3’ or less) 1 Area Rug 2 Wall-to-Wall Carpet 3 Concrete/brick 4 Wood Flooring 5 Vinyl tile/linoleum 6 Grouted tile 7 Other 8 Specify for Other:______________________________________________________
> ROOM WINDOW TREATMENT (circle all that apply): Blinds 1 Curtains 2 Drapes 3 Shades 4 None 5 Other 6....Specify for Other:___________________________________________________________ Blind/curtain cords present? Yes 1 No 2 IF cords present, looped? Yes 1 No 2
> ROOM TEMPERATURE: ________^oF ROOM HUMIDITY: _________%
> ROOM DIMENSIONS:			Avg. Wall Height:	\|__\|\|__\| ft \|__\|\|__\| in				Number		Height (FT)	Combined width (FT)
North wall	Length:	__________ FT		o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
East wall	Length:	__________ FT		o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
South wall				o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
West wall				o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______

> OBSERVATIONS:					Yes	No
Food debris observed?					1	2
Greasy stove?					1	2			No stove present 3
Mildew observed?					1	2
Other moisture evidence?					1	2
Cockroach stains?					1	2
Live/dead cockroaches?					1	2
Room/window Air Conditioner?					1	2
Dehumidifier?					1	2
Humidifier/vaporizer?					1	2
Child safety locks on cabinet drawers/doors?					1	2
Child safety locks on electrical outlets?					1	2			Plugged-in Items - List Codes:
Extension cords plugged into outlets?					1	2
Power Strips plugged into outlets?					1	2
Multi outlet adapters plugged into outlet?					1	2
Plugged-in Items Codes: 1=Lamps/clocks/fans 2=Cooking/Microwaves 3=Computer/Entertainment 4=Space heater/AC 5=Other _______________________________________________________

After completing this form, complete the Building Moisture Measurements for this room

Room Observation Form - Other Room							Room ID #_______________
> BUILDING LEVEL (0 = basement): ___________
> ROOM CARPET CODE (circle all that apply): Antislip features? Yes 1 No 2 Mat (2’x3’ or less) 1 Area Rug 2 Wall-to-Wall Carpet 3 Concrete/brick 4 Wood Flooring 5 Vinyl tile/linoleum 6 Grouted tile 7 Other 8 Specify for Other:______________________________________________________
> ROOM WINDOW TREATMENT (circle all that apply): Blinds 1 Curtains 2 Drapes 3 Shades 4 None 5 Other 6....Specify for Other:___________________________________________________________ Blind/curtain cords present? Yes 1 No 2 IF cords present, looped? Yes 1 No 2
> ROOM TEMPERATURE: ________^oF ROOM HUMIDITY: _________%
> ROOM DIMENSIONS:			Avg. Wall Height:	\|__\|\|__\| ft \|__\|\|__\| in				Number		Height (FT)	Combined width (FT)
North wall	Length:	__________ FT		o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
East wall	Length:	__________ FT		o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
South wall				o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
West wall				o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______

> OBSERVATIONS:					Yes	No
Food debris observed?					1	2
Greasy stove?					1	2			No stove present 3
Mildew observed?					1	2
Other moisture evidence?					1	2
Cockroach stains?					1	2
Live/dead cockroaches?					1	2
Room/window Air Conditioner?					1	2
Dehumidifier?					1	2
Humidifier/vaporizer?					1	2
Child safety locks on cabinet drawers/doors?					1	2
Child safety locks on electrical outlets?					1	2			Plugged-in Items - List Codes:
Extension cords plugged into outlets?					1	2
Power Strips plugged into outlets?					1	2
Multi outlet adapters plugged into outlet?					1	2
Plugged-in Items Codes: 1=Lamps/clocks/fans 2=Cooking/Microwaves 3=Computer/Entertainment 4=Space heater/AC 5=Other _______________________________________________________

Room Observation Form - Basement							Room ID #_______________
> BUILDING LEVEL (0 = basement): ___________
> ROOM CARPET CODE (circle all that apply): Antislip features? Yes 1 No 2 Mat (2’x3’ or less) 1 Area Rug 2 Wall-to-Wall Carpet 3 Concrete/brick 4 Wood Flooring 5 Vinyl tile/linoleum 6 Grouted tile 7 Other 8 Specify for Other:______________________________________________________
> ROOM WINDOW TREATMENT (circle all that apply): Blinds 1 Curtains 2 Drapes 3 Shades 4 None 5 Other 6....Specify for Other:___________________________________________________________ Blind/curtain cords present? Yes 1 No 2 IF cords present, looped? Yes 1 No 2
> ROOM TEMPERATURE: ________^oF ROOM HUMIDITY: _________%
> ROOM DIMENSIONS:			Avg. Wall Height:	\|__\|\|__\| ft \|__\|\|__\| in				Number		Height (FT)	Combined width (FT)
North wall	Length:	__________ FT		o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
East wall	Length:	__________ FT		o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
South wall				o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______
West wall				o Windows o Doors o Other unpainted surfaces				____ ____ ____		_____ _____ _____	_______ _______ _______

> OBSERVATIONS:					Yes	No
Food debris observed?					1	2
Greasy stove?					1	2			No stove present 3
Mildew observed?					1	2
Other moisture evidence?					1	2
Cockroach stains?					1	2
Live/dead cockroaches?					1	2
Room/window Air Conditioner?					1	2
Dehumidifier?					1	2
Humidifier/vaporizer?					1	2
Child safety locks on cabinet drawers/doors?					1	2
Child safety locks on electrical outlets?					1	2			Plugged-in Items - List Codes:
Extension cords plugged into outlets?					1	2
Power Strips plugged into outlets?					1	2
Multi outlet adapters plugged into outlet?					1	2
Plugged-in Items Codes: 1=Lamps/clocks/fans 2=Cooking/Microwaves 3=Computer/Entertainment 4=Space heater/AC 5=Other _______________________________________________________

After completing this form, complete the Building Moisture Measurements for this room

Building Materials - Moisture Testing Log
					Initials ___________

Room		Area water damage (SF)	Area tested		Substrate Code	Reading	If not tested, reason
Common Living Area ID # ________ If not tested, reason: _____			Interior wall			3 in—
						3 ft—
						6 ft—
			Exterior wall			3 in—
						3 ft—
						6 ft—
			Visibly water damaged area 1			Center—
			Visibly water damaged area 2			Center—
		Does this Room have a musty smell (circle one) 1= YES 2=NO Does this room have any visible mold growth (circle one) 1=YES 2=NO
Bedroom ID # ________ If not tested, reason: _____			Interior wall			3 in—
						3 ft—
						6 ft—
			Exterior wall			3 in—
						3 ft—
						6 ft—
			Visibly water damaged area 1			Center—
			Visibly water damaged area 2			Center—
		Does this Room have a musty smell (circle one) 1= YES 2=NO Does this room have any visible mold growth (circle one) 1=YES 2=NO
Basement ID# _______ If not tested, reason: _____			Below grade wall			3 in—
						3 ft—
						6 ft—
			Visibly water damaged area 1			Center—
			Visibly water damaged area 2			Center—
		Does this Room have a musty smell (circle one) 1= YES 2=NO Does this room have any visible mold growth (circle one) 1=YES 2=NO
	Substrate Codes			Reason Codes (for No Test)
	D - drywall or wallboard			I - Inaccessible
	W - wood			NA - Not allowed
	P - plaster			NP - None Present (such as no water damaged areas present)
	C - concrete, concrete block or cinderblock			NX - Does not Exist (such as no Basement in DU)
	O - Other			O - Other (SPECIFY IN BOX)

I8- FUNGI VACUUM DUST SAMPLING
Staff Involved:	Assigned Interviewer
Overview: After the Room Inventory and Building Moisture Measurements have been completed (protocol I7), the Interviewer will perform vacuum dust sampling for mold using the Vacuum Sample Allergens Log form provided in the Resident Questionnaire Form set (see form at the end of this protocol). These efforts include using the DustStream sampler connected to a vacuum cleaner to collect one composite dust sample from the floors of 2 primary rooms, the Common Living Area (CLA) and the Bedroom (BR) (as designated in the selection column of the Room Inventory form).
Data Recording on:		Fungi Vacuum Sample Log
Equipment Needed from Kit (X)
1 blue pen 1 clipboard 1 flashlight with extra batteries 1 pr knee pads 1 tape measure (25’) 1 duffle bag o carry vacuum equipment 1 vacuum cleaner with bag & hose attachment 1 25’ extension cord with 2 prong adapter 1 Stopwatch					2 DustStream Sampler attachments (goes on vacuum) inside a re-closable bag. cleaning wipes (from Interviewer Field equipment) gloves blue masking tape trash bag
Supplies Needed from Kit (B) - Subkit T8
1 row of 4 self-adhesive, pre-printed ID labels inside re-closable bag. 2 DustStream dust sample collection filters				2 50mL centrifuge tubes (to hold final sample). 2 One-quart re-closable bags; one for the sample and one for the sampler after cleaning
Glove Use Directives:			Use new (see protocol I0)

Procedure

1. Retrieve Equipment and needed supplies as indicated in the list above.

2. Enter CLA and BR room IDs on the Vacuum Sample Allergens Log form as designated on the Room Inventory form. This room ID is obtained from the Room Inventory form (protocol I4).

3. Go to the CLA, locate the sofa, tape the corners of the 3’ x 6’ sampling area, and record the sampling area. In the absence of a sofa locate what appears to be most commonly used chair in the room. Using a tape measure and a roll of blue masking tape, mark the corners of a 3-foot by 6-foot rectangular sampling area on the floor immediately against the selected sofa (or other primary use chair). Place the long side of the rectangle against the sofa and record the dimensions on the Vacuum Sample Log. If the sample location cannot accommodate a sample area of these dimensions, adjust the dimensions accordingly (but try to sample a total of 18 square feet) and record these dimensions on the Vacuum Sample Log.

4. Plug in and test the vacuum to be sure that it will run. Use the extension cord as needed to reach the sampling location with the vacuum.

5. Assign ID number to sample collection containers, Log form, and Chain-of-Custody.

5.1 Place sample ID label on each of two 50mL centrifuge tubes. Using two of the supplied labels, ensure both sample containers have the sample ID number on them.

5.2 Place sample ID label on Vacuum Sample Log form. Place a third replicate ID label (same ID number) on a chain of custody form and complete the appropriate entries on this form.

5.3 Place sample ID label on Chain of Custody form. Place a fourth replicate ID label (same ID number) on a chain of custody form and complete the appropriate entries on this form.

6. Don a new pair of lab gloves.

7. Clean Gloves and attach DustStream sampler. Wipe off the gloves with a cleaning wipe and fit a clean DustStream sampler to the sampling vacuum cleaner and dispose of the cleaning wipe in a trash bag. Wrap a piece of blue tape around the interface joint between the DustStream sampler and the vacuum cleaner hose end so that it will seal any gaps and ensure that the sampler will not accidentally fall off while in use.

8. Insert a new filter tube into the DustStream sampler and collect sample. Hold the DustStream sampler with open end up and insert a new filter tube. Collect the vacuum sample using the following parameters:

8.1 Turn on the vacuum, place sampler at one corner of the marked area and start the stopwatch to time the vacuuming process. Starting at one corner of the marked sampling area, place the DustStream sampler in contact with the floor surface taking care not to disturb the masking tape used to mark the corners.

8.2 Avoid vacuuming up any large debris that is not considered dust or dirt.

8.3 While vacuuming, slightly tilt the sampler to one side to create a slight gap between the floor surface and the sampler. NOTE: Vacuum efficiency is improved by increasing the airflow into the sampler. A sampler in total contact with the floor surface will not collect sample as it completely blocks all airflow.

8.4 Watch the stopwatch while slowly sweeping over the sampling area back and forth with slight overlapping on each pass until the entire area is vacuumed. Adjust the rate of movement so that a total of 5minutes is used to vacuum the entire 18 square foot area.

8.5 If the corner marking masking tape is accidentally vacuumed, hold the sampler facing up towards the ceiling, stop the vacuum and pick the tape out of the sampler with your gloved hand and discard the tape in a trash bag. Turn the vacuum back on and return to vacuuming the sampling area. Be sure to account for the lost sample time when you do this so you get a total of five minutes of vacuuming time.

8.6 At the end of sample collection in the CLA, hold the sampler facing up, then turn off the vacuum and remove the filter tube so that the collected dust remains in the tube. Place the tube in the labeled 50mL centrifuge tube and screw the lid tight. Carefully set the DustStream sampler on the end of the vacuum hose so that it lies within the area just sampled while handling the filter tube.

8.7 Place the capped centrifuge tube into a 1 qt re-closable bag and place this sample in the supplies/equipment bag for temporary storage.

8.8 Complete the remaining data fields on the Fungi Vacuum Sample Log form for this room.

9. Move equipment and supplies to the BR. Do not remove the DustStream sampler from the vacuum cleaner nor the gloves from your hands. They will be used on the second room (BR) to be sampled.

10. Locate a randomly selected bed, tape the corners of the 3’ x 6’ sampling area, and record the sampling area. If 2 or more beds are in the room, randomly select one using the Random Selection Procedure after step 17 of this protocol. Using a tape measure and a roll of blue masking tape, mark the corners of a 3-foot by 6-foot rectangular sampling area on the floor immediately against the side of the bed where a resident is most likely to get in and out of bed. Place the long side of the rectangle against the bed and, if possible, have the rectangular sample area extend under the bed by 3 or 4 inches so that part of the sample goes under the bed. Record the dimensions on the Vacuum Sample Log. If the sample location cannot accommodate a sample area of these dimensions, adjust the dimensions accordingly (but try to sample a total of 18 square feet) and record these dimensions on the Vacuum Sample Allergens Log.

11. Plug in and test the vacuum to be sure that it will run. Use the extension cord as needed to reach the sampling location with the vacuum.

12. Don a new pair of lab gloves.

13. Clean gloves. Wipe off the gloves with a cleaning wipe and dispose of the cleaning wipe in a trash bag. NOTE: There is no need to change or clean the DustStream sampler since the sample collected here in the BR will be composited in the laboratory with the one collected from the CLA.

14. Insert a new filter tube into the DustStream sampler and collect the sample. Hold the DustStream sampler open end up and insert a new filter tube. Collect the vacuum sample using the same parameters as listed under step (8) placing this filter tube into the second labeled 50mL centrifuge tube and placing it into the same previously labeled 1-qt re-closable bag as the sample collected in the CLA.

15. Review recorded data and complete all data entries on the Vacuum Sample Log and the combined Chain-of-Custody Vacuum Dust and Dust Wipe Swiffer™ Samples form that stays with Kit (F) (see protocol I9).

16. Clean the DustStream sampler thoroughly (inside and out) for use on the next DU using several cleaning wipes. Let air dry for a couple of minutes before placing the sampler in and sealing shut a new clean 1-qt re-closable. Double-bag the sampler and re-store this with other Interviewer equipment.

17. Move on to the Dust Wipe Swiffer™ Sample collections (protocol I9).

Random Selection Procedure for Items (like beds)

If only one item exists, select the one item.
If more than one item exists, use the following procedure:

1. Count the number of items (beds)

2. Go to the Random Number Table

3. Select the first unused row of the table.

4. Look under the column that matches the count number to get the selection and remember the selected number.

5. Put a line through that row of the table to indicate that it has been used.

6. Starting at the bed closest to the main entrance of the room, count clockwise (left to right) the beds until the selected number is reached and select that bed to sample.

FUNGI VACUUM SAMPLE LOG (vacuum 5 min per 18 sq. ft.)
CLA Room ID ______________			Initials _______________
BR Room ID ______________

Sample #	Sample Collected?	Location		Sample surface code (circle one)	Floor area vacuumed
sample ID label here	Yes 1 No 2 If No, reason code: ___________	Floor in CLA		Smooth/cleanable 1 Not smooth 2 Carpeted 3	3’ x 6’ 1 Not 3’ x 6’ 2 Enter: \|___\|\|___\|in X \|___\|\|___\|in
	Yes 1 No 2 If No, reason code: ___________	Floor in BR		Smooth/cleanable 1 Not smooth 2 Carpeted 3	3’ x 6’ 1 Not 3’ x 6’ 2 Enter: \|___\|\|___\|in X \|___\|\|___\|in

Reason Codes (for No sample)
I - Inaccessible, NA - Not allowed, NR - No more room to collect sample, O - Other (SPECIFY IN BOX)

Random Number Table for Random Selections

Random Number Selections from a Group of 2 to 14 Items
Row	Number of Items to Pick From:
Row	2	3	4	5	6	7	8	9	10	11	12	13	14
1	2	2	3	1	3	4	5	3	7	11	5	3	5
2	2	3	3	4	2	5	8	5	10	1	3	7	2
3	2	1	3	1	4	2	8	3	2	5	7	3	2
4	2	3	3	1	3	1	6	8	6	9	3	13	2
5	1	1	3	5	4	2	6	2	5	3	4	2	2
6	1	3	2	3	4	7	6	2	6	3	12	4	14
7	2	3	2	2	5	6	6	1	1	8	9	8	8
8	2	2	1	4	2	4	5	5	4	6	6	10	13
9	2	2	3	1	5	3	6	6	7	2	8	7	1
10	1	3	1	1	3	2	2	7	5	6	10	4	13
11	2	1	3	1	5	7	3	6	10	6	3	2	13
12	1	2	3	2	5	4	2	4	8	3	10	11	9
13	1	2	2	2	4	3	2	6	3	8	4	4	6
14	2	1	3	3	3	2	3	7	5	10	5	4	7
15	2	2	1	4	4	7	3	7	2	9	7	5	11
16	2	3	1	3	3	6	6	9	8	11	5	2	11
17	2	3	3	2	4	3	4	2	9	3	3	12	12
18	1	2	2	2	4	4	2	4	7	2	5	9	12
19	1	1	1	3	5	3	3	4	2	4	8	7	8
20	1	3	3	2	2	2	2	3	5	7	11	12	12
21	2	1	4	4	5	1	3	2	2	3	4	7	4
22	2	1	3	4	3	5	3	5	5	10	1	11	2
23	2	1	3	3	1	5	3	3	5	5	4	7	3
24	1	3	2	3	5	4	7	3	8	4	8	5	6
25	1	3	2	2	6	2	5	5	3	2	1	10	2
26	2	3	3	4	5	5	5	8	6	3	6	3	12
27	2	3	3	2	2	6	2	1	6	2	5	8	12
28	1	3	3	4	6	3	7	1	3	3	2	8	11
29	2	2	4	4	3	7	3	2	8	10	6	10	8
30	1	1	2	5	5	2	3	2	3	4	4	8	11
31	2	3	1	4	4	4	5	7	6	3	6	2	3
32	1	3	3	4	5	5	4	3	9	6	3	9	12
33	1	2	3	3	2	4	6	8	4	3	4	11	13
34	2	1	1	3	3	3	7	4	8	2	4	11	1
35	1	1	3	2	6	6	6	3	8	4	6	1	7
36	1	1	3	5	3	4	5	6	10	2	9	1	11
37	1	2	2	3	3	7	7	4	3	2	3	6	12
38	1	2	3	5	4	7	6	1	1	8	6	8	13
39	1	1	1	3	3	6	5	3	7	8	12	6	1
40	2	2	1	1	2	4	7	9	5	9	5	11	12

I9- DUST WIPE SWIFFER® SAMPLING
Staff Involved:	Assigned Interviewer
Overview: After collection of the vacuum dust sample (protocol I8), the Interviewer will collect a dust wipe composite sample from 2 rooms (CLR and BR) using dry Swiffer™ dusters. The dusters are removed from a re-sealable bag and are used to wipe the tops of structures that are not often cleaned. The Swiffer™ dusters are then returned to the re-sealable bag and stored temporarily with other collected samples until they can be placed in a freezer.
Data Recording on:		Resident questionnaire form set pulled from Kit (B)
Equipment Needed from Kit (X)
1 blue pen 1 clipboard					nitrile gloves trash bag
Items needed from Kit (F)
Shipper plus field to lab chain of custody (COC) - leave shipper in automobile, but put COC with supplies. Return COC back to shipper with samples at end of testing at the DU
Supplies Needed from Kit (B) - Subkit T8
1 row of 4 self-adhesive, pre-printed ID labels inside re-closable bag. 1 dry Swiffer™ duster inside a re-closeable bag.				1 One-quart re-closable bag
Glove Use Directives:			Use new (see protocol I0)

Procedure

1. Get ready to collect dust. Open the top of the bag containing the duster and then put on a new pair of gloves.

2. Collect dust in the CLA. Using the duster, wipe the tops of structures not often cleaned, for example, tops of doorways and doors, tops of book shelves, sconces, etc., - anywhere dust settles.

3. Collect dust in the BR. Using the same duster, wipe the tops of structures in the BR not often cleaned, in the same way.

4. Store and label the sample. Place the dirtied duster back in the original re-sealable bag and then toss your gloves into the trash. Place one of the sample ID labels on the bag containing the sample and place the entire bag inside another bag. Be sure to squeeze as much air out of the bags as possible before sealing so they do not consume too much room in the freezer when they are ultimately stored back at the Interviewer's base of operations.

5. Complete the logs and COC. Place a second sample ID label on the Dust Wipe Swiffer™ Log and another on the COC. Be sure that the sample and COC get placed back into the shipper (Kit (F) at the end of testing at the DU.

DUST WIPE SWIFFER™ SAMPLE LOG
CLA Room ID ______________			Initials _______________
BR Room ID ______________

Sample #	Sample Collected in the indicated room?	Location		Comments
sample ID label here	Yes 1 No 2 If No, reason code: ___________	CLA
	Yes 1 No 2 If No, reason code: ___________	BR

Reason Codes (for No sample)
I - Inaccessible, NA - Not allowed, NR - No more room to collect sample, O - Other (SPECIFY IN COMMENTS BOX)

Chain-of-Custody for Vacuum Dust and Dust Wipe Swiffer™ Samples
Completed by:						on
	(name)						(date)
Sample ID		vacuum dust	Swiffer™		Comments
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Relinquished by: Date / Time:				Relinquished by: Date / Time:
Received by: Date / Time: Condition Acceptable?  Yes  No				Received by: Date / Time: Condition Acceptable?  Yes  No

I10- - FLUSHED DRINKING WATER SAMPLE
Staff Involved:	Assigned Interviewer
Overview: After collecting the Swiffer® dust sample, the Interviewer collects one or two flushed draw water samples from the kitchen faucet. One sample is collected at all DUs. Relevant sampling data are collected on a form. In addition, the Interviewer will collect a hot water temperature reading on the hot water coming from the Kitchen faucet. (Note that the flushed drinking water sample is collected using only cold water.) If the DU is the first to be visited in the PSU, then: a second flushed water sample will be collected in that DU, and each of the two spiked QC water samples will be re-labeled using ID labels from the I10 subkit from the first DU. The Interviewer will also ensure that the first-draw water sample retrieved from the resident is properly labeled, a replicate of this label is placed on the Water Sample Log bound in the resident questionnaire form set for the DU, and a replicate label is placed on the Chain-of-Custody Form [from Kit (E)].
Data Recording on:		Resident Questionnaire Form Set - Water sample log (for both 1st and flushed draw samples
Equipment Needed from Kit (X)
1 roll of electrical tape. 1 thermometer					gloves
Supplies Needed from Kit (E2) [Drinking water shipper] If this is the 1st DU tested in the PSU
2 pre-filled one-Liter bottles marked with QC stickers. (These are spiked QC samples) 1 empty one-Liter bottle having a "duplicate" sticker on it (used for field duplicate QC sample in 1st DU in PSU only)					Chain-of-Custody
Supplies Needed from Kit (B) - Subkit I10
1 strip of ID labels having suffix numbers 04, 05, 06, and 07.				1 one-Liter bottle (empty)
Glove Use Directives:			Use new (see protocol I0)

Procedure

1. Go to the faucet or tap used by the resident for the first-draw water sample.

2. Ready the bottles. Set the water bottles to be used (one or two as described in the Overview above) on a clean dry surface within reach of the faucet. Unscrew the caps and place them upside down on the surface next to the bottles. Avoid touching the insides of the water bottle or cap.

3. Flush the tap. Open the COLD water faucet fully and start the stopwatch.

4. Fill the first bottle. Insert the bottle under the stream of water after 3 minutes (180 seconds) of running water out of the faucet and fill the bottle to the top. Pour out just enough so the liquid is level with the narrowing of the bottle where the neck begins (so the lab will have room to add acid to it before analysis).

5. Fill the second bottle (if field duplicate required). Fill the second bottle (if a field duplicate is to be collected) immediately after filling the first bottle without stopping the water coming from the faucet. Fill to the same level as the first sample. If you did collect this sample, do not pull off the "duplicate" label on the second sample so you will know for sure which was collected first and which was collected second (the duplicate is always second).

6. Cap and seal the bottles. For each bottle, screw the caps on tightly and wipe off the outside of the bottle so it is dry before sealing the cap. Seal the cap using electrical tape. Place the end of the tape (on the roll) over the edge where the cap meets the top of the bottle and hold it there with your thumb. Pull and stretch the tape as you wrap it around and over the cap edge. Make 2 full wraps around the cap pulling hard at the end to stretch-break the tape. Push any trailing tape on the cap tightly against the cap to finish the seal.

7. Label flushed water sample bottles and forms. Place one of the ID labels with the "04" suffix on the first flushed water sample. Place a replicate ID label on the Water Sample Log and check the box on that form to mark it as a flushed sample. If you collected a field duplicate sample, then:

Pull off the original QC sample "duplicate" label from the field duplicate QC sample and replace it with one of the ID labels with the "05" suffix on it. Place a replicate ID label on the Water Sample Log and check the box on that form to mark it as a flushed duplicate water sample.
Pull off the original QC sample "QC" labels from both spiked QC samples and replace them with one of the ID labels having an "06" suffix and one having an "07" suffix on it. Place a replicate ID label for each on the Water Sample Log and check the boxes on that form to mark these 2 samples as lab QC water samples.

8. Label first-draw sample forms. Place one of the ID labels used to mark the first-draw sample collected from the resident (the ones with the "01" suffix) on the Water Sample Log and check the box on that form to mark it as a first-draw water sample. Hold on to the remaining water sample labels. They will be used again later to mark the Chain-of-Custody for Water Samples.

NOTE: Justification for using a 3 minute flush time. There are two methods commonly used for collecting the flushed cold water sample. One is to wait until a significant temperature change occurs in the water coming from the tap and the other is to wait a specific length of time. A hybrid method could also be used such as waiting for a temperature change up to a specified time where the sample gets collected when and if the temperature has changed before the time expires with collection at the end of the time if no temperature change was observed. The assumption here is that the temperature change is an indicator that the water coming out of the tap is coming from the source and not the pipes inside the home. That assumption is not always valid and depends a great deal on the configuration of the home, the type of water source and the locations of piping feeding water to the tap. In addition, not only is it hard to define what is a significant temperature change on which to base the collection decision, the use of a water temperature change protocol is much more complicated to carry out in the field than using just a specific time to flush the tap. Also, the potential burden on the resident must be considered. Allowing too many gallons to be flushed could annoy the resident and long time periods increase the overall time the team has to stay in the unit. There is also the issue that in a very large multi-family building, the total pipe length to the source may be considerable. Under most circumstances, the proposed time of 3 minutes will result is roughly 5 gallons of flushed water before any sample is collected.

DRINKING WATER SAMPLE LOG
DU ID
Completed by:							on
	(name)							(date)
Sample ID		Check Sample Type
		Flushed Sample	Duplicate Flushed sample	Lab QC sample	First-draw sample	Comments
Field sample ID label here

Chain-of-Custody for Drinking Water Samples
Completed by:					on
	(name)					(date)
Sample ID		Water Sample	Comments
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Relinquished by: Date / Time:				Relinquished by: Date / Time:
Received by: Date / Time: Condition Acceptable?  Yes  No				Received by: Date / Time: Condition Acceptable?  Yes  No

I11- - EXTERIOR WALKTHROUGH OBSERVATIONS
Staff Involved:	Assigned Interviewer
Overview: After the flushed water sampling as been completed (protocol I10), the Interviewer contacts the Technician to complete the collection of the formaldehyde sample. Once that equipment is removed, the Interviewer performs walkthrough observations of the exterior of the DU using the Exterior Conditions Log form (see form at the end of this protocol). This includes collection of outside temperature and humidity measurements, and observations on building conditions.
Data Recording on:		Resident Questionnaire Form Set - Exterior Conditions Log
Equipment Needed from Kit (X)
1 blue pen 1 clipboard 1 compass 1 flashlight with extra batteries (use for all protocols all DUs)				1 tape measure (25’) 1 Humidity/temperature meter (air measurements) 1 Break-off Report (if needed in case of a break-off)
Supplies Needed from Kit (B) - Subkit T1
none
Glove Use Directives:			Use new (see protocol I0)

Procedure

1. Complete collection of the formaldehyde sample. Call/contact the technician to come and complete the final shutdown of the sampling train and collect the formaldehyde sample. The Technician will follow their procedures provided in protocol T1 to complete this effort.

2. Conduct exterior walkthrough using the Exterior Conditions Log. Use the following parameters to conduct this work:

1.1 For single-family residence, make building condition observations on the outside of the DU including the immediately surrounding real property that goes with the house.

1.2 For multifamily residence, make building condition observations on the outside of the building where the DU is located including the immediate surrounding real property close to the unit.

1.3 For Outdoor Air Conditions measurements use the humidity/temperature meter. See Operating Instructions for Temperature/Humidity Meter in protocol I7.

1.4 For Random Exterior Wall measurements, measure the wall recorded on the Room Inventory form

2. Check with Technician and move on to End-Of-Day Collected Sample and Data Review activities to ensure that all targeted data and sample collection has been completed.

EXTERIOR CONDITIONS LOG

Number of Units in Building

If the respondent does not know how many units are in the building (Q6 in Questionnaire), verify by some other means (such as by looking at the mailboxes) and answer the following questions (circle one):

4 or fewer units 1 5units or more 2 Don’t Know 8

Outdoor Air Conditions
Outdoor: Temperature _______^oF	Relative Humidity ________%

Random Exterior Wall (from Room Inventory form); circle selection: N E S W
Estimated wall length in feet= _______	Estimated wall height in feet= ________

Building Condition (exterior)	YES	No	NA
1 Roof missing parts of surfaces (tiles, boards, shakes)	1	2	8
2 Roof has holes or large cracks	1	2	8
3 Gutters or downspouts broken	1	2	8
4 Chimney masonry cracked, bricks loose or missing, out of plumb	1	2	8
5 Exterior walls have large cracks or holes	1	2	8
6 Two or more windows broken, missing, or boarded up	1	2	8
7 Foundation has major cracks, missing material, or structure leans	1	2	8

Outdoor Water

Present in the Yard?

If Yes….

Pool

YES 1

NO 2

Fence present?

YES 1

NO 2

Type of fence?

Full perimeter 1

3 sides of house 2

Other 3

Fence height:

________ FT

Lock on fence from outside house?

YES 1

NO 2

Hot tub

YES 1

NO 2

Cover?

YES 1

NO 2

Cover locked/secure?

YES 1

NO 2

Pond/natural waters

YES 1

NO 2

T1- FORMALDEHYDE IN AIR SAMPLING
Staff Involved:	Assigned Field Technician and Interviewer
Overview: Immediately after introductions are made between the Interviewer, respondent, and Technician, the Technician assembles and calibrates the sampling equipment (pump, tubing and sorbent tube) assembly and initiates air sample collection by attaching the calibrated assembly to the Interviewer’s clothing. Air sampling for formaldehyde continues until the Interviewer has completed all interior activities. Once completed, the Interviewer has the Field Technician (while the Interviewer is still inside the DU) measure the end of sampling flow-rate of the air sampling assembly, disassemble the assembly, and store the collected sample. Relevant sampling data are collected on a form.
Data Recording on:		Technician Form Set (bound) pulled from Kit (B)
Equipment Needed from Kit (X)
1 tool bucket with blue Pocket Bucket Tote 1 blue ink pen 1 clipboard 1 black sharpie marker 1 box of cleaning clothes (wipes) 1 box nitrile gloves 1 trash bag 1 box of cleaning clothes (wipes) 1 box nitrile gloves 1 trash bag roll of blue or green masking tape 1 set jewelers screwdrivers					Personal air-sampling pump assembly (may or may not include controller as shown in Figure T1-1) Sorbent tube breaker Tubing for pump (2 sections: 1 short, 1 long) Rotameter Low Flow Tube cover with clip Quick start guide - Rotameters Quick start guide low rate Set-up Charger for pump clothing clip with loop (allows tubing to side through it)
Supplies Needed from Kit (D) [Formaldehyde shipper]
4 sorbent tubes [ORBO 555, DPNH-treated silica gel] each in separate plastic re-closable bag					Chain-of-Custody for SGS labs
Supplies Needed from Kit (B) - Subkit T1
3 rows of 4 self-adhesive, pre-printed ID labels				one re-closable plastic bag for unused media labeled "Not for Analysis"
Glove Use Directives:			Use new (see protocol I0)

Complete cover pages of the Technician Form Set.

Use information obtained from the Interviewer and labeling from the Kit (B) selected for use for the DU to complete the cover page.

General Information on Sampling

(1) Target air sampling flow rate. For the AHHS II, the optimum flow-rate of air through the sorbent tube used to capture formaldehyde from the air is 1.5 liters per minute (LPM). This rate is at or near the maximum capability of the personal air sampling pump.

(2) Sampling train configuration for flow-rate calibration checks. The sampling train used to collect check calibration of the pumps is shown in Figure T1-1: a long tube coming out of the pump is connected to a (low flow) tube holder and is fed through a clothing clip; the tube holder is connected to an opened ended sorbent tube (arrow on tube points toward the pump*); the other open end of the sorbent tube is connected to a short tube going to the rotameter.

*If no arrow is shown on tube, examine the dark colored media in the tube. There will be a small section of media closer to one end that is capped by narrow ribbons of packing material. It is this section that must point toward the pump. This is section is used to capture any breakthrough of formaldehyde that slips past the media before this smaller section.

Figure T1-1. Sampling train configuration for calibration.

(3) Charging of pump. All pumps will be fully charged and maximum flow rates checked/adjusted prior to shipment to the field in the technician's equipment [Kit (X)] within a bag labeled "Equipment for T1". The sampling train system (pump, tubes, holders, sorbent tube for calibration at QT, and rotameter) will be completely assembled as shown in Figure T1-1 using an "office calibration only sorbent tube". The Technician must ensure that they keep these pumps fully charged while not in use so that they will be ready when needed. This includes charging them between DUs as opportunities arise to do so.

(4) Sampling train configuration for sample collection. The sampling train used to collect a formaldehyde sample is the same as that used for calibration except that the rotameter and the section of tubing connecting it to the sorbent tube are removed and replaced by a cover cap over the sorbent tube to protect the Interviewer (who will be wearing the sampling train) from the sharp edges of the open ended sorbent tube. The cover cap has a clip on it so it can be easily fastened to the Interviewer’s clothing.

(5) Breaking open the end of the sorbent tubes. Use gloves when handling media. Sorbent tubes containing the media used to absorb the formaldehyde are sealed in glass and the ends must be broken open to a diameter of at least 1/2 the total diameter of the outside of the sorbent tube. This is done by placing each end of the tube into the sorbent tube breaker and twisting (rotating) them back and forth a couple of times to score the outside of the tube until the tube snaps along that score line. Shake excess glass shards out of the tube breaker into the trash.

(6) The three categories of sorbent tubes. All sorbent tubes come with 2 red caps to cover the ends when not inserted into the sampling train. They all contain the same materials and media. Labeling of the tubes is done by wrapping a self-stick label around one of the cap ends as shown in Figure T1-2: For the AHHS II, the tubes are loosely categorized into three categories:

(a) Office calibration only. This sorbent tube is inserted into the pre-assembled sampling train and is shipped from QT to the field. It has 2 ID labels, one wrapped around one of the two red caps (located inside the bag containing the sampling train) and one around the body of the tube itself to ensure that it does not get used for collecting an air sample (this label location is not used for regular samples targeted for analysis). The ID label contains the words "Office calibration only". This sorbent tube is NEVER used in the field except to hold the sampling train together in a calibration configuration. However, it does get used at the QT office to verify that the pump is working properly and at the desired flow rate.

(b) Field calibration only. At least one sorbent tube per PSU is required for field calibration of the sampling train. It gets labeled using a self stick label containing the words "Field calibration only". This label is placed as shown in Figure T1-2.

Figure T1-2. Sorbent tube with end caps and attached sample ID label.

(7) Collection of field blank. One field blank is to be collected at the first DU tested in a PSU (1 per PSU). Collect the field blank immediately after calibration by performing all the steps used for the regular sample except to do not pull any air through the sorbent tube when it is in the sampling train. Simply break open the ends, insert it into the sampling train and then remove it WITHOUT TURNING ON THE PUMP, cap the ends, label it as per the sample collection procedure and place it in its own plastic bag. It can be temporarily stored in the tote bucket until the end of testing at a DU where it is transferred along with the regular sample and any left-over spares to the Kit (D) for cold storage. After this is done, prepare a new sorbent tube to collect the regular sample (1 per DU).

(8) Interviewer apparel and personal hygiene directives. The Interviewer is directed to not wear any garments that have been dry-cleaned recently or any garments that are new that have never have been wet-washed. They must wear clothes that have only been cleaned by wet-washing in a standard or high efficiency washer and dryer. In addition, the Interviewer is directed to not wear any perfume other than what may already be presence in deodorant they routinely wear under their arms. These precautions are needed to ensure that the clothing being worn by the Interviewer does not contribute any formaldehyde to the collected samples (a low but not zero probability event).

Initiate Sample Collection Procedure

1. Perform pre-sampling flow-rate calibration check of the pump.

(a) Place the sampling train assembly on a clean level surface such as a table or counter.

(b) Carefully remove "Office calibration only" tube from the sampling train and cap it using the caps provided for this tube inside the plastic bag that held the sampling train.

(c) Obtain a new sorbent tube and remove the red end caps placing them back into the plastic bag that held the tube. Use the tube breaker to open both ends of the tube and set it temporarily back into the plastic bag it came from. Place a "Field calibration only" label on one of the caps.

(d) Insert the tube into the sampling train making sure that the correct tube end points toward the pump.

(e) Turn on the pump and wait about 3 minutes for it to warm up. Lower your eye to view the rotameter perpendicular to the rotameter face (90 degrees). Identify the flow rate as indicated by where the center of the ball is floating within the rotameter. The ball should be within the range of 1.3 and 1.7 LPM; if not, contact QT for further instructions. Record the flow rate on the Formaldehyde Sampling Log Record under Initial Field Calibration Flow-rate and then turn off the pump.

(f) Remove the "Field calibration only" sorbent tube, re-cap the ends, store it in the designated plastic bag, and place it in a protected spot in your bucket tote. If the tube does not get cracked or broken, it can be used repeatedly for performing flow-rate calibration checks at other DUs that are tested on that same day, but not at DUs on subsequent days. A least one new tube must be used for initial field calibrations each day of testing.

2. Assemble sampling train for sample collection.

(a) Remove the rotameter and tubing from the sampling train and place these items back into the T1 equipment subkit bag.

(b) Obtain a new sorbent tube and remove the red end caps placing them back into the plastic bag that held the tube. Use the tube breaker to open both ends of the tube and set it temporarily back into the plastic bag it came from. Place a sample ID label [(from Kit (B) subkit T1] on one of the caps.

(d) Install the tube protector over the sorbent tube.

3. Place sampling train on the Interviewer and start sample collection.

(a) Using the wide clip on the pump, hang the pump on either a belt or on a pocket on the opposite side of the Interviewer's dominant hand far enough toward the back to be completely out of the way and so the Interviewer can still sit down in a chair for administering the resident questionnaire.

(b) Run the tubing loosely from the pump and clip the protective cover containing the open ended sorbent tub to a location on the upper part of their shirt or blouse (such as a lapel, a pocket, a collar). Be sure that both the tube and protective cover clip are placed where it is unlikely to interfere with the ability of the Interviewer to conduct the various activities assigned to them during the interior efforts at the DU.

(c) Examine the tubing and be sure it is securely attached using the supplied clothing slip and/or a couple of pieces of blue masking tape to be sure it does not hang where it may get caught on a chair or other objects as the Interviewer moves around.

4. Turn on the pump. Record the counter number on the pump, and the time it was turned on, on the Formaldehyde Sampling Log.

Complete Sample Collection Procedure

1. Retrieve and store the regular sample when the Interviewer has completed all of their internal activities. If at all possible, avoid starting any final exterior activities (causing you to turn off the pump) until the pump has been on for at least 3 hours.

(a) Turn off the pump. Record the counter number on the pump, and the time it was turned off, on the Formaldehyde Sampling Log.

(b) Using a new pair of gloves, carefully remove the clip from the Interviewer and pull the sorbent tube out of the sampling train. Retrieve the red caps that go on the sorbent tube and verify that they have the correct sample ID label before pushing the caps over the ends of the tube (the one matching the initial calibration flow-rate and the start/stop counter and time entries on the log form) before pushing the caps over the ends of the tube. Store the tube in its designated plastic bag and place it in a protected spot in your bucket tote.

2. Carefully remove the sampling train from the Interviewer and conduct a post sampling flow-rate check.

(a) Place the sampling train assembly on a clean level surface such as a table or counter.

(b) Remove the "Field calibration only" sorbent tube from your protected spot in your bucket tote, uncap the ends storing the caps back in their designated plastic bag, and insert the sorbent tube back into the sampling train using the configuration for flow-rate calibration checks.

(e) Turn on the pump. Lower your eye to view the rotameter perpendicular to the rotameter face (90 degrees). Identify the flow rate as indicated by where the center of the ball is floating within the rotameter. Record this flow rate on the Formaldehyde Sampling Log Record under Initial Field Calibration Flow-rate and then turn off the pump.

3. Store all sorbent tube media as appropriate. At the end of sampling in a DU, all sorbent tubes targeted for potential use in the DU (typically 4) are to be placed in plastic bags and stored in the Kit (D) Shipper containing blue ice packs so they will be kept cold until they can be moved to the freezer at the end of the day. With the possible exception of the sorbent tube used for "field calibration only", place all media that are not regular or field blank samples in a plastic bag labeled "Not for analysis". At the end of a workday, also place the sorbent tube used for "field calibration only" in this bag.

Cover Sheet for Technician Form Set

Dwelling Unit ID:

Kit (B) Number:

place Kit (B) label here

PSUID - AHHS SEGID - SAMP TYPE

DU Address

Interviewer Name

Check if this is 1st DU in the PSU to get tested

►

◄

If checked, use Kit (B) box with a -WQ suffix and collect a pesticide QC sample and a dust wipe Swiffer™ sample

Check if this is 2nd DU in the PSU to get tested

►

◄

If checked, use Kit (B) box with a -W suffix and a dust wipe Swiffer™ sample

**Note all fields to be completed by Technician

FORMALDEHYDE IN AIR COLLECTION LOG
Pump Information:		Pump Number: ___________________________
Pre-calibration Flow-rate Check						Post-calibration Flow-rate Check
Date	Clock time completed			Measured Flow rate LPM		Date	Clock time completed	Measured Flow rate LPM

Sample Information:
ID			Clock time when pump started		Clock time when pump stopped		Comments
place Sample ID Label here

FORMALDEHYDE IN AIR COLLECTION LOG (QC)
Pump Information:		Pump Number: ___________________________
Pre-calibration Flow-rate Check						Post-calibration Flow-rate Check
Date	Clock time completed			Measured Flow rate LPM		Date	Clock time completed	Measured Flow rate LPM

Sample Information:
ID			Clock time when pump started		Clock time when pump stopped		Comments
place Sample ID Label here

Chain-of-Custody for Formaldehyde Samples
Completed by:					on
	(name)					(date)
Sample ID		Sorbent tube	Comments
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Relinquished by: Date / Time:				Relinquished by: Date / Time:
Received by: Date / Time: Condition Acceptable?  Yes  No				Received by: Date / Time: Condition Acceptable?  Yes  No

T2- LEAD-BASED PAINT TESTING (using XRF)
Staff Involved:	Assigned Field Technician
Overview: The Technician conducts LBP testing using combination of automated data collection programmed into the XRF instrument and a checklist (one for each room and the exterior). LBP testing will include selected surfaces on the interior and on the exterior. The checklist contains a list all of the building components to be tested if present. The interior testing is to be done before the exterior and includes testing in the KIT, CLR, BR and OTHER rooms. Actual testing of any surfaces cannot be started until the Interviewer completes the Room Inventory efforts (protocol I4). In addition, the Technician must be present with the Interviewer for the Introduction (protocol I3) so that the resident becomes familiar with the Technician and comfortable with his/her presence in the DU. After this introduction is completed, the Informed Consent is signed, and collection of the air sample for formaldehyde has been started, the Technician will warm up the XRF and perform internal calibration and QC checks. By the time these checks are completed, the Interviewer should have completed the Room Inventory, which is needed to direct the Technician to the rooms selected for environmental sampling. The Interviewer and Technician will make a quick visit with the resident to each of these interior rooms to communicate agreement on the rooms that are selected for testing. During this quick visit, the drinking water service line will be tested for Pb if it can be located and assessed. Once this is done, the testing of selected surfaces in the four selected rooms and the primary entryway will be performed. Testing on the exterior locations will be performed after completing collection of all of the interior samples. Exterior testing includes measurements on a porch area (if it exists), and on other selected exterior surfaces on one randomly selected side of the DU (designated as east, west, north or south as determined during the room inventory).
Data Recording on:		Technician Form Set (bound) pulled from Kit (B) plus completed room inventory sheet
Equipment Needed from Kit (Y) and Kit (Z)
1 Heuresis model Pb200i with calibration check standards [Kit (Z)] 1 blue ink pen 1 clipboard 1 flashlight with extra batteries				1 tape measure (25’) 1 pair knee pads 1 compass
Glove Use Directives:			not required

General XRF Use Information

Custody. The XRF, Kit (Z), is shipped directly from the XRF manufacturer to the Technician (and back at the end of the PSU) and is not the responsibility of the Interviewer.
Electronic Storage. The Heuresis PB 200i has enough storage capacity to hold all of the readings in all DUs in the survey. Therefore, the Technician is directed to never erase any of the stored data from the XRF.
Charging. The Technician is responsible for ensuring that the batteries in the XRF and the spares are fully charged prior to testing in each unit.
Mode of Operation. ***to be updated by QuanTech after XRF programming has been completed***
Warm-up. Prior to use for any testing, the XRF must be turned on and allowed to warm up for at least 5 minutes. The Technician should place the XRF on top of its carrying case and keep it far removed from any other electronic device in the home such as a television set when turning it on (necessity unclear but this is a prudent precaution).
Calibration Checks. All readings must be bracketed (prior to and after testing building components) by measurements on the manufacturer's calibration check standards. If the XRF must be turned off after warm-up, tests must be made on the calibration check standards prior to shutting down. In case of a battery failure that requires a switch in the battery pack, this may not be possible. If this happens contact the assigned QT custodian or the QA manager (Dr. Gary Dewalt) to discuss options.
Rooms Selected for Testing. Obtain a copy of the Room Inventory form from the Interviewer and participate in a quick walk through of the DU with the Interviewer before starting the testing on the interior. Locate and collect a reading on the drinking water service line coming into the DU at this time.
Testing Path Precautions. The Technician shall take care to ensure that no persons (occupant or neighbor) are inadvertently exposed to radiation from the XRF. The Heuresis PB 200i contains a nominal 5 milli-Curies of Co-57. The degree of penetration of the radiation from this XRF is very much dependent on the thickness and type of material you're measuring: if it's a steel door there is essentially no exposure on the other side of the door, but a hollow wood door or wall made of drywall is a different story. Also, in taking a single sub-10-second measurement with an XRF instrument with a 1 to 5 mCi 57Co source, the dose levels caused by an incidental exposure are not dangerous. However, despite these facts, the Technician is directed to skip any measurement on components where a person could be less than 1 meter in a direct line from the front of the XRF. This means that walls that are common to other DUs where persons may be located should not be tested by the technician. In such cases, be sure to note on the applicable form that this is the reason the component was not tested.

TESTING AT THE DU

NOTE: These instructions will be dated to reflect final programming of the XRF before training for the survey is conducted.

1. Collect readings on each of the interior components using the six LBP Testing Checklists (Miscellaneous, Kitchen, Common Lining Area, Bedroom, Other Room, and Exterior) using the parameters provided below:

4.1 ***To be completed after final XRF programming***

4.1.1 1 DU ID#.

4.1.2 2 Room ID#.

4.1.3 3 Comp(loc).

4.1.4 4 Def Other.

4.1.5 5 Substrate.

4.1.6 6 Comp Cond.

4.1.7 7 % Det.

END OF DAY LBP TESTING ACTIVITIES

These activities are a part of the offsite end-of-day activities. The daily activities relevant to these protocols include the following:

1. Download data. ***To be completed after final XRF programming***

2. Recharge Batteries. ***To be completed after final XRF programming***

Random Selection Process for Windows

1. Count the number of window systems in the room.

2. Go to the Random Number Table

2.1 Select the first unused row of the table.

2.2 Look under the column that matches the count number to get the selection and remember the selected number.

2.3 Put a line through that row of the table to indicate that it has been used.

3. Starting at the main entrance door in the room, count clockwise (left to right) the windows until the selected number is reached and test this window system.

For example, if the room has 4 windows and the first row of the table is used, then the 3rd window (going left to right from the main entrance) is to be tested.

GENERAL OPERATION OF THE HEURESIS MODEL Pb200I

***To be completed after final XRF programming***

A. Turning ON the XRF.

B. Starting up the AHHS II program

C. Summary of Data Entry using the AHHS II program.

D. Downloading Data to the tablet

IMPORTANT NOTE: THIS DOWNLOAD PROCEDURE MUST BE COMPLETED AT THE CONCLUSION OF WORK IN EACH DWELLING UNIT

Table T1-1. Data Collection Programming on the Heuresis model Pb200i

***to be updated by QuanTech after XRF programming has been completed***

Pick List Choices (Code Clarification, if needed)

1st Entry: DU ID NOT pick list but uses virtual keyboard; format is ###-###-ZZ

2nd Entry: Room ID

KIT Kitchen

CLA Common Living Area

KIT Bedroom

OTHER Other selected room

EXT Exterior (includes entryway)

3rd Entry: Component (quadrant location = 1,2,3 or 4)

QC Std 0 QC standard <0.01 mg/cm²

QC Std 1.04 QC standard 1.04 mg/cm²

QC Std 3.58 QC standard 3.58 mg/cm²

Interior items:

N Wall(4) north wall

E wall(1) east wall

S wall(3) south wall

W Wall(1) west wall

Win sill(1) random window sill

Win sash(3) sash on same window above

Win aprn(2) apron on same window above

Win jamb(4) jamb on same window above

Basebrd(2) baseboard on east wall

Beam(4) beam or column

Cabinet(3) built-in cabinet

Ceiling(4) ceiling

Chairrai(1) chair rail

Cls shlf(3) any closet, shelf or support

Cmold(2) crown molding

Door(3) random door

Dr jamb(4) jamb on door above

Fireplac(2) fireplace or chimney

Floor(2) floor

Other 1(2) other painted/deteriorated comp

Other 2(2) other painted/deteriorated comp

Radiator(3) radiator or built-in heater

Str rail(1) stair rail

Str risr(2) any riser

Str tred(4) any tread

Pipe Drinking water service line

Exterior items:

X N Sid(4) North wall siding

X E Sid(1) East wall siding

X S Sid(3) South wall siding

X W Sid(1) West wall siding

X Mdoor(1) main entryway door

X Mjamb(3) jamb on same door above

X Pceil(4) porch celing

X Pfloor(2) porch or stairwell floor

X Prail(3) rail in porch/stairwell above

X Thres(3) threshold on same door above

X Waprn(3) same window above

X Wsash(2) same window above

X Wsill(2) randomly picked operable window

X Cbord(1) cornerboard

X Fndwall(1) foundation wall

X Skirt(2) skirt or dripboard

X Chmny(3) chimney

X Lattice(3) lattice

X Other1(2) other painted/deteriorated comp

X Other2(2) other painted/deteriorated comp

4th Entry (optional) Define Other NOT pick list but uses virtual keyboard

5th Entry: Substrate Type

Brick

Concrete

Ceramic

Drywall drywall or sheetrock

Metal

Plaster plaster or stucco

Stone

Vinyl

Wood

Wallpaper

Other

6th Entry: Component Condition

Satisfactory substrate okay

Repair substrate needs repair

Replace substrate needs replacing

7th: % Deteriorated

1-10%

11-25%

26-50%

51-75%

76-90%

91-99%

100%

LBP TESTING CODES AND CHECKLIST INSTRUCTIONS

Use the checklists to keep track of items tested or reviewed for testing

All components listed on the checklists are to be tested if found and painted, varnished, or otherwise coated. Bracket all interior and exterior readings by QC standards as listed on the forms.

SPECIAL DIMENSION MEASUREMENTS INSTRUCTIONS FOR WINDOWS

The purpose of recording dimensions of the random window (in inches) is to be able to calculate the total painted surface areas of the window system (the non-glass portions). Mullions, if they exist, are ignored.

N = Window Count. This is the total number of windows in room.
W=Width. Measure horizontal width, side to side, starting at left edge of trim (where it meets the wall) all the way across the window to the right edge of the trim (where it meets the wall).
H=Height. Measure vertical height top to bottom start starting at the top of the trim (where it meets the wall) all the way across the window where either the left of right side trim stops (this is often at the sill).
X1= Trim Width Left. Measure the width of the trim on the left side starting at the left edge of the glass and wrapping the tape measure across the sash, jambs and other left side trim to the wall edge.
X2=Trim Width Right. If the left is the same as the right, you can use the same number determined for X1. If not, use same procedure as for X1 on the right side.
X3=Trim Width Top. Measure the width of the trim on the top part of the window starting at the top of the trim (where it meets the wall) and wrapping the tape measure across the top trim to where it meets edge of the glass. If you can't reach it, estimate the width.
X4=Trim Width Bottom. Measure the width of the trim on the bottom part of the window starting at the bottom glass edge and wrapping the tape measure across the sash, sill and apron (if it exists) to the wall edge under the sill or apron.

TEST LOCATIONS (LOC) ARE DEFINED IN QUADRANTS AS FOLLOWS:

	Components with large areas =>	1 = upper left quadrant	2 = upper right quadrant
		4 = lower leftquadrant	3 = lower right quadrant

Components with narrow areas =>

1 (N)

left or top quadrant

2 (E)

middle left or 2^nd quadrant down

3 (S)

middle right or 3^rd quadrant down

4 (W)

right or bottom quadrant

LBP Testing Checklist for Miscellaneous Tests

Check off items on the checklist as they are tested or not tested using the following Test Codes:

1 = Tested this Item

6= Not Tested - Could not locate drinking water service line.

7= Not Tested - Found drinking water service line, but inaccessible with XRF.

Record Testing of drinking water service line in the row below:

Item Tested Clarification Test Code Clock Time when tested

Pipe ________ ___________________

Record g any extra readings taken on the calibration check standards (such as needed due to a battery failure) in the rows below:

Item Tested Clarification Test Code Clock Time when tested

Std 0 -frnt, -bck front&back std <0.01 mg/cm² ________ ___________________

Std 1 -frnt, -bck front&back std 1.04 mg/cm² ________ ___________________

Std 3 -frnt, -bck front&back std 3.58 mg/cm² ________ ___________________

Std 0 -frnt, -bck front&back std <0.01 mg/cm² ________ ___________________

Std 1 -frnt, -bck front&back std 1.04 mg/cm² ________ ___________________

Std 3 -frnt, -bck front&back std 3.58 mg/cm² ________ ___________________

Std 0 -frnt, -bck front&back std <0.01 mg/cm² ________ ___________________

Std 1 -frnt, -bck front&back std 1.04 mg/cm² ________ ___________________

Std 3 -frnt, -bck front&back std 3.58 mg/cm² ________ ___________________

LBP Testing Checklist for KIT

Check off items on the checklist as they are tested or not tested using the following Test Codes:

1 = Tested this Item

2 = Not Tested - Item not present

3 = Not Tested - Items present, but not painted, varnished or otherwise coated

4 = Not Tested - Items present and painted, but inaccessible

5 = Not Tested - Items present and painted, but not safe to test

At end of testing in a room, fill in the open quantity blanks for selected items shown below:

Component Code KIT

(test quad) Clarification Test Code Quantity Units

Std 0 -frnt, -bck front&back std <0.01 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 1 -frnt, -bck front&back std 1.04 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 3 -frnt, -bck front&back std 3.58 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

N Wall(4) north wall ________ ▓▓▓▓▓ ▓▓▓▓▓

E wall(1) east wall ________ ▓▓▓▓▓ ▓▓▓▓▓

S wall(3) south wall ________ ▓▓▓▓▓ ▓▓▓▓▓

W Wall(1) west wall ________ ▓▓▓▓▓ ▓▓▓▓▓

Win sill(1) random window sill ________ ▓▓▓▓▓ ▓▓▓▓▓

Win sash(3) sash on window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Win aprn(2) apron on window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Win jamb(4) jamb on window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Dimensions: N=____ W=____ X1=____ X2=____ X3=____ X4=____

Door(3) random door ________ ▓▓▓▓▓ ▓▓▓▓▓

Dr jamb(4) jamb on door above ________ ▓▓▓▓▓ ▓▓▓▓▓

Floor(2) floor ________ ▓▓▓▓▓ ▓▓▓▓▓

Basebrd(2) baseboard on east wall ________ ▓▓▓▓▓ ▓▓▓▓▓

Ceiling(4) ceiling ________ ▓▓▓▓▓ ▓▓▓▓▓

Cmold(2) crown molding ________ ▓▓▓▓▓ ▓▓▓▓▓

Chairrai(1) chair rail ________ ▓▓▓▓▓ ▓▓▓▓▓

Fireplac(2) fireplace or chimney ________ ▓▓▓▓▓ ▓▓▓▓▓

Beam(4) beam or column ________ _______ each

Cls shlf(3) any closet, shelf or support ________ _______ linear feet

Cabinet(3) built-in cabinet ________ _______ linear feet

Str rail(1) stair rail ________ _______ linear feet

Str tred(4) any tread ________ _______ each

Str risr(2) any riser ________ _______ each

Radiator(3) radiator or built-in heater ________ _______ each

Other 1(2) other deteriorated comp ________ ▓▓▓▓▓ ▓▓▓▓▓

Other 2(2) other deteriorated comp ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 0 -frnt, -bck front&back std <0.01 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 1 -frnt, -bck front&back std 1.04 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 3 -frnt, -bck front&back std 3.58 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

LBP Testing Checklist for CLA

Check off items on the checklist as they are tested or not tested using the following Test Codes:

1 = Tested this Item

2 = Not Tested - Item not present

3 = Not Tested - Items present, but not painted, varnished or otherwise coated

4 = Not Tested - Items present and painted, but inaccessible.

5 = Not Tested - Items present and painted, but not safe to test

At end of testing in a room, fill in the open quantity blanks for selected items shown below:

Component Code CLA

(test quad) Clarification Test Code Quantity Units

Std 0 -frnt, -bck front&back std <0.01 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 1 -frnt, -bck front&back std 1.04 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 3 -frnt, -bck front&back std 3.58 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

N Wall(4) north wall ________ ▓▓▓▓▓ ▓▓▓▓▓

E wall(1) east wall ________ ▓▓▓▓▓ ▓▓▓▓▓

S wall(3) south wall ________ ▓▓▓▓▓ ▓▓▓▓▓

W Wall(1) west wall ________ ▓▓▓▓▓ ▓▓▓▓▓

Win sill(1) random window sill ________ ▓▓▓▓▓ ▓▓▓▓▓

Win sash(3) sash on window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Win aprn(2) apron on window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Win jamb(4) jamb on window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Dimensions: N=____ W=____ X1=____ X2=____ X3=____ X4=____

Door(3) random door ________ ▓▓▓▓▓ ▓▓▓▓▓

Dr jamb(4) jamb on door above ________ ▓▓▓▓▓ ▓▓▓▓▓

Floor(2) floor ________ ▓▓▓▓▓ ▓▓▓▓▓

Basebrd(2) baseboard on east wall ________ ▓▓▓▓▓ ▓▓▓▓▓

Ceiling(4) ceiling ________ ▓▓▓▓▓ ▓▓▓▓▓

Cmold(2) crown molding ________ ▓▓▓▓▓ ▓▓▓▓▓

Chairrai(1) chair rail ________ ▓▓▓▓▓ ▓▓▓▓▓

Fireplac(2) fireplace or chimney ________ ▓▓▓▓▓ ▓▓▓▓▓

Beam(4) beam or column ________ _______ each

Cls shlf(3) any closet, shelf or support ________ _______ linear feet

Cabinet(3) built-in cabinet ________ _______ linear feet

Str rail(1) stair rail ________ _______ linear feet

Str tred(4) any tread ________ _______ each

Str risr(2) any riser ________ _______ each

Radiator(3) radiator or built-in heater ________ _______ each

Other 1(2) other deteriorated comp ________ ▓▓▓▓▓ ▓▓▓▓▓

Other 2(2) other deteriorated comp ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 0 -frnt, -bck front&back std <0.01 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 1 -frnt, -bck front&back std 1.04 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 3 -frnt, -bck front&back std 3.58 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

LBP Testing Checklist for BR

Check off items on the checklist as they are tested or not tested using the following Test Codes:

1 = Tested this Item

2 = Not Tested - Item not present

3 = Not Tested - Items present, but not painted, varnished or otherwise coated

4 = Not Tested - Items present and painted, but inaccessible.

5 = Not Tested - Items present and painted, but not safe to test

At end of testing in a room, fill in the open quantity blanks for selected items shown below:

Component Code BR

(test quad) Clarification Test Code Quantity Units

Std 0 -frnt, -bck front&back std <0.01 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 1 -frnt, -bck front&back std 1.04 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 3 -frnt, -bck front&back std 3.58 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

N Wall(4) north wall ________ ▓▓▓▓▓ ▓▓▓▓▓

E wall(1) east wall ________ ▓▓▓▓▓ ▓▓▓▓▓

S wall(3) south wall ________ ▓▓▓▓▓ ▓▓▓▓▓

W Wall(1) west wall ________ ▓▓▓▓▓ ▓▓▓▓▓

Win sill(1) random window sill ________ ▓▓▓▓▓ ▓▓▓▓▓

Win sash(3) sash on window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Win aprn(2) apron on window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Win jamb(4) jamb on window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Dimensions: N=____ W=____ X1=____ X2=____ X3=____ X4=____

Door(3) random door ________ ▓▓▓▓▓ ▓▓▓▓▓

Dr jamb(4) jamb on door above ________ ▓▓▓▓▓ ▓▓▓▓▓

Floor(2) floor ________ ▓▓▓▓▓ ▓▓▓▓▓

Basebrd(2) baseboard on east wall ________ ▓▓▓▓▓ ▓▓▓▓▓

Ceiling(4) ceiling ________ ▓▓▓▓▓ ▓▓▓▓▓

Cmold(2) crown molding ________ ▓▓▓▓▓ ▓▓▓▓▓

Chairrai(1) chair rail ________ ▓▓▓▓▓ ▓▓▓▓▓

Fireplac(2) fireplace or chimney ________ ▓▓▓▓▓ ▓▓▓▓▓

Beam(4) beam or column ________ _______ each

Cls shlf(3) any closet, shelf or support ________ _______ linear feet

Cabinet(3) built-in cabinet ________ _______ linear feet

Str rail(1) stair rail ________ _______ linear feet

Str tred(4) any tread ________ _______ each

Str risr(2) any riser ________ _______ each

Radiator(3) radiator or built-in heater ________ _______ each

Other 1(2) other deteriorated comp ________ ▓▓▓▓▓ ▓▓▓▓▓

Other 2(2) other deteriorated comp ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 0 -frnt, -bck front&back std <0.01 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 1 -frnt, -bck front&back std 1.04 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 3 -frnt, -bck front&back std 3.58 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

LBP Testing Checklist for Other Room

Check off items on the checklist as they are tested or not tested using the following Test Codes:

1 = Tested this Item

2 = Not Tested - Item not present

3 = Not Tested - Items present, but not painted, varnished or otherwise coated

4 = Not Tested - Items present and painted, but inaccessible.

5 = Not Tested - Items present and painted, but not safe to test

At end of testing in a room, fill in the open quantity blanks for selected items shown below:

Component Code OTHER ROOM

(test quad) Clarification Test Code Quantity Units

QC Std 0 QC standard <0.01 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

QC Std 1.04 QC standard 1.04 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

QC Std 3.58 QC standard 3.58 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

N Wall(4) north wall ________ ▓▓▓▓▓ ▓▓▓▓▓

E wall(1) east wall ________ ▓▓▓▓▓ ▓▓▓▓▓

S wall(3) south wall ________ ▓▓▓▓▓ ▓▓▓▓▓

W Wall(1) west wall ________ ▓▓▓▓▓ ▓▓▓▓▓

Win sill(1) random window sill ________ ▓▓▓▓▓ ▓▓▓▓▓

Win sash(3) sash on window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Win aprn(2) apron on window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Win jamb(4) jamb on window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Dimensions: N=____ W=____ X1=____ X2=____ X3=____ X4=____

Door(3) random door ________ ▓▓▓▓▓ ▓▓▓▓▓

Dr jamb(4) jamb on door above ________ ▓▓▓▓▓ ▓▓▓▓▓

Floor(2) floor ________ ▓▓▓▓▓ ▓▓▓▓▓

Basebrd(2) baseboard on east wall ________ ▓▓▓▓▓ ▓▓▓▓▓

Ceiling(4) ceiling ________ ▓▓▓▓▓ ▓▓▓▓▓

Cmold(2) crown molding ________ ▓▓▓▓▓ ▓▓▓▓▓

Chairrai(1) chair rail ________ ▓▓▓▓▓ ▓▓▓▓▓

Fireplac(2) fireplace or chimney ________ ▓▓▓▓▓ ▓▓▓▓▓

Beam(4) beam or column ________ _______ each

Cls shlf(3) any closet, shelf or support ________ _______ linear feet

Cabinet(3) built-in cabinet ________ _______ linear feet

Str rail(1) stair rail ________ _______ linear feet

Str tred(4) any tread ________ _______ each

Str risr(2) any riser ________ _______ each

Radiator(3) radiator or built-in heater ________ _______ each

Other 1(2) other deteriorated comp ________ ▓▓▓▓▓ ▓▓▓▓▓

Other 2(2) other deteriorated comp ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 0 -frnt, -bck front&back std <0.01 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 1 -frnt, -bck front&back std 1.04 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 3 -frnt, -bck front&back std 3.58 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

LBP Testing Checklist for Exterior

[NOTE: it is assumed that the XRF will be turned off after completing testing of the interior rooms.] Check off items on the checklist as they are tested or not tested using the following Test Codes:

1 = Tested this Item

2 = Not Tested - Item not present

3 = Not Tested - Items present, but not painted, varnished or otherwise coated

4 = Not Tested - Items present and painted, but inaccessible.

5 = Not Tested - Items present and painted, but not safe to test

At end of testing in a room, fill in the open quantity blanks for selected items shown below:

Component Code Exterior

(test quad) Clarification Test Code Quantity Units

QC Std 0 QC standard <0.01 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

QC Std 1.04 QC standard 1.04 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

QC Std 3.58 QC standard 3.58 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

X N Sid(4) North wall siding ________ ▓▓▓▓▓ ▓▓▓▓▓

X E Sid(1) East wall siding ________ ▓▓▓▓▓ ▓▓▓▓▓

X S Sid(3) South wall siding ________ ▓▓▓▓▓ ▓▓▓▓▓

X W Sid(1) West wall siding ________ ▓▓▓▓▓ ▓▓▓▓▓

X Mdoor(1) main entryway door ________ ▓▓▓▓▓ ▓▓▓▓▓

X Mjamb(3) jamb on door above ________ ▓▓▓▓▓ ▓▓▓▓▓

X Thres(3) threshold on door above ________ ▓▓▓▓▓ ▓▓▓▓▓

X Pfloor(2) porch or stairwell floor ________ _______ square feet

X PCeil(4) porch celing ________ ▓▓▓▓▓ ▓▓▓▓▓

X Prail(3) rail in porch/stairwell above ________ _______ linear feet

Items Below Are To Be Tested on A Randomly Selected Exterior Wall (N, E, S or W) identified on the Room Inventory form

Component Code Exterior

(test quad) Clarification Test Code Quantity Units

X Wsill(2) random operable window ________ ▓▓▓▓▓ ▓▓▓▓▓

X Wsash(2) same window above ________ ▓▓▓▓▓ ▓▓▓▓▓

X Waprn(3) same window above ________ ▓▓▓▓▓ ▓▓▓▓▓

Dimensions: N=____ W=____ X1=____ X2=____ X3=____ X4=____

X Cbord(1) cornerboard ________ _______ feet

X Fndwall(1) foundation wall ________ ▓▓▓▓▓ ▓▓▓▓▓

X Skirt(2) skirt or dripboard ________ ▓▓▓▓▓ ▓▓▓▓▓

X Chmny(3) chimney ________ _______ square feet

X Lattice(3) lattice ________ _______ square feet

X Other1(2) other deteriorated comp ________ ▓▓▓▓▓ ▓▓▓▓▓

X Other2(2) other deteriorated comp ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 0 -frnt, -bck front&back std <0.01 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 1 -frnt, -bck front&back std 1.04 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Std 3 -frnt, -bck front&back std 3.58 mg/cm² ________ ▓▓▓▓▓ ▓▓▓▓▓

Random Number Table for Random Selections

Random Number Selections from a Group of 2 to 14 Items
Row	Number of Items to Pick From:
Row	2	3	4	5	6	7	8	9	10	11	12	13	14
1	2	2	3	1	3	4	5	3	7	11	5	3	5
2	2	3	3	4	2	5	8	5	10	1	3	7	2
3	2	1	3	1	4	2	8	3	2	5	7	3	2
4	2	3	3	1	3	1	6	8	6	9	3	13	2
5	1	1	3	5	4	2	6	2	5	3	4	2	2
6	1	3	2	3	4	7	6	2	6	3	12	4	14
7	2	3	2	2	5	6	6	1	1	8	9	8	8
8	2	2	1	4	2	4	5	5	4	6	6	10	13
9	2	2	3	1	5	3	6	6	7	2	8	7	1
10	1	3	1	1	3	2	2	7	5	6	10	4	13
11	2	1	3	1	5	7	3	6	10	6	3	2	13
12	1	2	3	2	5	4	2	4	8	3	10	11	9
13	1	2	2	2	4	3	2	6	3	8	4	4	6
14	2	1	3	3	3	2	3	7	5	10	5	4	7
15	2	2	1	4	4	7	3	7	2	9	7	5	11
16	2	3	1	3	3	6	6	9	8	11	5	2	11
17	2	3	3	2	4	3	4	2	9	3	3	12	12
18	1	2	2	2	4	4	2	4	7	2	5	9	12
19	1	1	1	3	5	3	3	4	2	4	8	7	8
20	1	3	3	2	2	2	2	3	5	7	11	12	12
21	2	1	4	4	5	1	3	2	2	3	4	7	4
22	2	1	3	4	3	5	3	5	5	10	1	11	2
23	2	1	3	3	1	5	3	3	5	5	4	7	3
24	1	3	2	3	5	4	7	3	8	4	8	5	6
25	1	3	2	2	6	2	5	5	3	2	1	10	2
26	2	3	3	4	5	5	5	8	6	3	6	3	12
27	2	3	3	2	2	6	2	1	6	2	5	8	12
28	1	3	3	4	6	3	7	1	3	3	2	8	11
29	2	2	4	4	3	7	3	2	8	10	6	10	8
30	1	1	2	5	5	2	3	2	3	4	4	8	11
31	2	3	1	4	4	4	5	7	6	3	6	2	3
32	1	3	3	4	5	5	4	3	9	6	3	9	12
33	1	2	3	3	2	4	6	8	4	3	4	11	13
34	2	1	1	3	3	3	7	4	8	2	4	11	1
35	1	1	3	2	6	6	6	3	8	4	6	1	7
36	1	1	3	5	3	4	5	6	10	2	9	1	11
37	1	2	2	3	3	7	7	4	3	2	3	6	12
38	1	2	3	5	4	7	6	1	1	8	6	8	13
39	1	1	1	3	3	6	5	3	7	8	12	6	1
40	2	2	1	1	2	4	7	9	5	9	5	11	12

T3- LEAD WIPE SAMPLING FOR Pb
Staff Involved:	Assigned Field Technician
Overview: After the interior LBP testing has been completed (protocol T2), the Technician will perform lead wipe sample collection in the KIT, CLR, BR and OTHER rooms. These efforts include collection of two wipe samples in each of the rooms, one from a random windowsill and one from the center of the largest open area on the floor. Also included are collection of one field blank and one sample from the floor in the center of the doorway to the major entrance to the DU. One square foot templates will be used for floor samples. The entire interior sill area will be wiped for windowsill samples. The surface type wiped for floor and window samples, carpet pile depth (for carpeted surfaces), window treatments, surface area wiped, and proximity of floor samples to doors, windows, and traffic patterns will be recorded using a form.
Data Recording on:		Technician Form Set (bound), pulled from Kit (B), plus completed room inventory sheet
Equipment Needed from Kit (X)
1 tool bucket with blue Pocket Bucket Tote 1 blue ink pen 1 clipboard 1 black sharpie marker 1 pocket knife 1 flashlight with extra batteries 1 roll electrical tape 1 roll blue tape					1 tape measure (25’) 1 box of cleaning clothes (wipes) 1 box nitrile gloves 1 pr knee pads 1 trash bag 1 template (aluminum or stainless), square with 12 in. x 12 in. internal dimensions
Supplies Needed from Kit (B) - Subkit T3
12 ASTM compliant Dust Wipe Media (individual packets; includes 2 spares) 10 rigid-walled dust wipe containers for storing the samples				10 rows of 4 self-adhesive, pre-printed ID labels (ID suffixes 12 through 20) 12 two-gal re-closable bags (for holding sample containers together)
Glove Use Directives:			Use new or cleaned gloves between samples (see protocol I0)

General Sampling Procedure

1. Check Supplies. Ensure there are sufficient supplies in your tool bucket tote to collect all ten lead wipe samples.

2. Go to each room and collect samples. Go to the each of the 4 primary rooms to sample (KIT, CLA, BR, and Other room) as designated on the Room Inventory form and collect a windowsill and floor sample using the following parameters:

2.1 Record the Room ID number on the form as shown on the Room Inventory form.

2.2 Use the Procedure to Collect Each Wipe Sample protocol shown in this document for each sample collected.

2.3 Collect the floor sample first using the 1 sq. ft. template. Locate this sample in the center of the largest open area on the floor.

2.4 Collect the windowsill sample second without using any template. For window systems, use the Random Selection Process provided in this protocol to select among the different window systems present in the room. The entire interior sill area will be wiped for windowsill samples.

2.5 If this is the Kitchen, collect a field blank after the windowsill sample.

3. Temporarily store samples. Place the all the collected samples in a doubled 2-gal re-closable bag to hold them together and temporarily store them in your tool bucket.

4. Review and complete data entries. Review the samples collected and the data recorded on the Lead Wipe Sample Logs and the Chain-of-Custody form. Ensure that all data fields are completed. Make any needed corrections.

5. Move on to pesticide wipe sample collection, protocol T4.

Random Selection Process for Windows

1. Count the number of window systems in the room.

2. Go to the Random Number Table (see form in protocol T1, also on page * in Technician form set).

2.1 Select the first unused row of the table.

2.2 Look under the column that matches the count number to get the selection and remember the selected number.

2.3 Put a line through that row of the table to indicate that it has been used.

3. Starting at the main entrance door in the room, count clockwise (left to right) the windows until the selected number is reached and test this window system.

For example, if the room has 5 windows and the 5^th row of the table is used, then the 5^th window (going left to right from the main entrance) is to be tested.

Procedure to Collect Each Wipe Sample

1. Label the container(s) and forms. Place a unique Sample ID label on the side of the sample container using the first unused row of 4 Sample ID labels provided in the sub-kit. Place a second replicate ID label (same ID number as above) on the indicated place on the Lead Wipe Sample Log starting at the first open entry of this form (NOTE: Be sure that the field sample ID label goes on the correct row). Place a third replicate ID label (same ID number) on a chain of custody form and complete the appropriate entries on both forms to the extent possible using a blue ink pen. For backup labeling, write the sample ID number on the sample container (opposite side of sample label) using a black sharpie marker. Be sure this hand-written ID number matches the ID number shown on the label.

2. Put on gloves. Don a new pair of lab gloves if not wearing gloves or if existing gloves are damaged or potentially contaminated.

3. Clean gloves, sample container, wipe package, and template. Wipe off the gloves with a cleaning wipe, then the outside of the tube and wipe package to be used for sample collection, then the sampling template (square shaped) if it is to be used and dispose of the cleaning wipe in a trash bag.

4. Repeat step (3).

5. Place the sampling template (floor samples only) on the sampling location. Tape down an outside corner if needed to hold the template still while sampling.

6. Open the wipe package and remove the wipe taking care to avoid touching anything with the wipe except the surface to be sampled. Temporarily discard the package in a pocket of your tool belt.

7. Wipe the sampling location to collect surface dust using the Standard Wiping Procedure

7.1 If the sample to be collected is a field blank (Kitchen only), collect it by performing the Standard Wiping Procedure, except do not touch the wipe to any surfaces (the wipe simply gets folded 3 times as you would if actually wiping the surface).

7.2 If the sample is a regular floor sample, collect a 1 square foot sample using the template.

7.3 If the sample is a windowsill sample, collect the entire interior sill area.

8. Clean equipment for interim storage. Wipe off the template (if used) with a cleaning wipe. Discard the cleaning wipe and store the template for use in the next room.

9. Pickup debris. Put any trash generated in a trash bag.

Standard Wiping Procedure (Note: This procedure is equivalent to the ASTM procedure)

A1. Select wiping pattern. Select either an "S" or Z" wiping pattern and collect the sample. Ensure that the whole sampling location is thoroughly wiped. The "S" pattern is performed as shown in Figure 1. At each turn, the wipe is rotated so that the same edge of the wipe is always leading (moving forward). The "Z" pattern is performed as shown in Figure 2, and the wipe is not rotated at each turn. The wiping patterns shown in Figures 1 and 2 can be performed as shown (right-handedly) or in mirror image (left-handedly), beginning the wiping motion at the upper right rather than the upper left.

A2. Position the wipe pad on the hand. Spread and/or fold the wipe on the hand in such a way that the wipe touches only the sampling location. Do not touch the sampling location with any part of the gloved hand. Place an open flat hand with the fingers together on the wipe pad. On some surfaces, it may be necessary to hold the wipe pad between thumb and forefinger, or between forefinger and middle finger to manipulate it.

A3. Wipe location side-to-side. Wipe the entire sampling location either using an overlapping side-to-side "S" pattern (Figure 1a) or a back and forth "Z" pattern (Figure 2a). Apply firm pressure to the wipe pad. For an "S" pattern, position the hand so that the same edge of the wipe pad is always pushed forward. This will require twisting of both the wrist and arm upon reaching the edges of the sampling location as the surface is wiped. The "Z" pattern does not require this twisting.

A4. Fold wipe in half, sample side in. Fold the wipe pad in half with the dirty side inward. Exercise care during folding to avoid loss of collected dust.

A5. Wipe location top-to-bottom. Using the folded wipe pad, repeat the wiping procedure within the sampling location except use a forward and back overlapping "S" (Figure b) or "Z" (Figure 2b) pattern.

A6. Fold wipe in half, sample side in. Fold the wipe pad in half again with the collected residue side inward. Exercise care during folding to avoid loss of collected dust.

A7. Wipe location edges and corners. Wipe edges and corners within the sampling location as illustrated in Figure 1c or Figure 2c for the "S" or "Z" wiping pattern, respectively.

A8. Fold wipe in half, sample side in. Fold the wipe pad in half again with the collected dust side inward. Exercise care during folding to avoid loss of collected dust.

A9. Store collected sample. Insert the folded wipe pad into the sample container.

FIGURE T3-1: Schematic of a side-to-side overlapping "S" wiping pattern. Only the center of the wipe path is shown, not the entire wiping width. Figure 1a shows the first "S" wipe pattern; Figure 1b shows the second "S" wipe pattern; and Figure 1c shows the final pattern that concentrates on the edges and corners.

FIGURE T3-2: Schematic of a side-to-side overlapping "Z" wiping pattern. Only the center of the wipe path is shown, not the entire wiping width. Figure 2a shows the first "Z" wipe pattern; Figure 2b shows the second "Z" wipe pattern; and Figure 2c shows the final pattern that concentrates on the edges and corners.

LEAD WIPE SAMPLE LOG - KIT
Room # ______________			Initials _______________

Sample #	Sample Collected?	Location	Sample surface code (circle one)	Carpet pile depth (nearest 1/8 in)	Proximity (circle all that apply)	Floor area wiped
sample ID label here	Yes 1 No 2 If No, reason code: _________ _________ _________	Floor	Smooth/cleanable 1 Not smooth 2 Carpeted 3	\|___\| / 8 in	<3 ft to door 1 <3 ft to window 2 In traffic pattern 3	12" x 12" 1 Not 12"x12" 2 Enter: \|___\|\|___\|in X \|___\|\|___\|in
				Sampled window treatment (circle all that apply)	Sill surface area wiped
sample ID label here	Yes 1 No 2 If No, reason code: _________ _________ _________	Window Sill	Smooth/cleanable 1 Not smooth 2	Blinds 1 Curtains 2 Drapes 3 Shades 4 None 5	\|___\| \|___\|----\|___\|/8 in X \|___\| \|___\|----\|___\|/8 in
sample ID label here	Yes 1 No 2 If No, reason code: _________ _________ _________	Field Blank

Reason Codes (for No sample)
I -Inaccessible, NA -Not allowed, NM -No more room to collect sample, NP -None present, NR -Not required, O -Other (SPECIFY IN BOX)

LEAD WIPE SAMPLE LOG - CLA
Room # ______________			Initials _______________

Sample #	Sample Collected?	Location	Sample surface code (circle one)	Carpet pile depth (nearest 1/8 in)	Proximity (circle all that apply)	Floor area wiped
sample ID label here	Yes 1 No 2 If No, reason code: _________ _________ _________	Floor	Smooth/cleanable 1 Not smooth 2 Carpeted 3	\|___\| / 8 in	<3 ft to door 1 <3 ft to window 2 In traffic pattern 3	12" x 12" 1 Not 12"x12" 2 Enter: \|___\|\|___\|in X \|___\|\|___\|in
				Sampled window treatment (circle all that apply)	Sill surface area wiped
sample ID label here	Yes 1 No 2 If No, reason code: _________ _________ _________	Window Sill	Smooth/cleanable 1 Not smooth 2	Blinds 1 Curtains 2 Drapes 3 Shades 4 None 5	\|___\| \|___\|----\|___\|/8 in X \|___\| \|___\|----\|___\|/8 in

Reason Codes (for No sample)
I -Inaccessible, NA -Not allowed, NM -No more room to collect sample, NP -None present, NR -Not required, O -Other (SPECIFY IN BOX)

LEAD WIPE SAMPLE LOG - BR
Room # ______________			Initials _______________

Sample #	Sample Collected?	Location	Sample surface code (circle one)	Carpet pile depth (nearest 1/8 in)	Proximity (circle all that apply)	Floor area wiped
sample ID label here	Yes 1 No 2 If No, reason code: _________ _________ _________	Floor	Smooth/cleanable 1 Not smooth 2 Carpeted 3	\|___\| / 8 in	<3 ft to door 1 <3 ft to window 2 In traffic pattern 3	12" x 12" 1 Not 12"x12" 2 Enter: \|___\|\|___\|in X \|___\|\|___\|in
				Sampled window treatment (circle all that apply)	Sill surface area wiped
sample ID label here	Yes 1 No 2 If No, reason code: _________ _________ _________	Window Sill	Smooth/cleanable 1 Not smooth 2	Blinds 1 Curtains 2 Drapes 3 Shades 4 None 5	\|___\| \|___\|in----\|___\|/8 in X \|___\| \|___\|in ----\|___\|/8 in

Reason Codes (for No sample)
I -Inaccessible, NA -Not allowed, NM -No more room to collect sample, NP -None present, NR -Not required, O -Other (SPECIFY IN BOX)

LEAD WIPE SAMPLE LOG - Other Room
Room # ______________			Initials _______________

Sample #	Sample Collected?	Location	Sample surface code (circle one)	Carpet pile depth (nearest 1/8 in)	Proximity (circle all that apply)	Floor area wiped
sample ID label here	Yes 1 No 2 If No, reason code: _________ _________ _________	Floor	Smooth/cleanable 1 Not smooth 2 Carpeted 3	\|___\| / 8 in	<3 ft to door 1 <3 ft to window 2 In traffic pattern 3	12" x 12" 1 Not 12"x12" 2 Enter: \|___\|\|___\|in X \|___\|\|___\|in
				Sampled window treatment (circle all that apply)	Sill surface area wiped
sample ID label here	Yes 1 No 2 If No, reason code: _________ _________ _________	Window Sill	Smooth/cleanable 1 Not smooth 2	Blinds 1 Curtains 2 Drapes 3 Shades 4 None 5	\|___\| \|___\|----\|___\|/8 in X \|___\| \|___\|----\|___\|/8 in

Reason Codes (for No sample)
I -Inaccessible, NA -Not allowed, NM -No more room to collect sample, NP -None present, NR -Not required, O -Other (SPECIFY IN BOX)

LEAD WIPE SAMPLE LOG - Entryway
Room # ______________			Initials _______________

Sample #	Sample Collected?	Location	Sample surface code (circle one)	Carpet pile depth (nearest 1/8 in)	Proximity (circle all that apply)	Floor area wiped
sample ID label here	Yes 1 No 2 If No, reason code: _________ _________ _________	Floor	Smooth/cleanable 1 Not smooth 2 Carpeted 3	\|___\| / 8 in	<3 ft to door 1 <3 ft to window 2 In traffic pattern 3	12" x 12" 1 Not 12"x12" 2 Enter: \|___\|\|___\|in X \|___\|\|___\|in

Reason Codes (for No sample)
I -Inaccessible, NA -Not allowed, NM -No more room to collect sample, NP -None present, NR -Not required, O -Other (SPECIFY IN BOX)

Chain-of-Custody for Lead in Wipes
DU ID:
Completed by:					on
	(name)					(date)
Sample ID		TYPE Lead Dust Wipe	Comments
Field sample ID label here		X
Field sample ID label here		X
Field sample ID label here		X
Field sample ID label here		X
Field sample ID label here		X
Field sample ID label here		X
Field sample ID label here		X
Field sample ID label here		X
Field sample ID label here		X
Field sample ID label here		X
Relinquished by: Date / Time:				Relinquished by: Date / Time:
Received by: Date / Time: Condition Acceptable?  Yes  No				Received by: Date / Time: Condition Acceptable?  Yes  No

T4- PESTICIDE WIPE SAMPLING
Staff Involved:	Assigned Field Technician
Overview: After completing the collection of the dust wipe samples for lead (protocol T3), the Technician will collect, using subkit T4, two pesticide wipe sample(s) in the Kitchen. A field blank will also be collected using subkit T4b in the first DU sampled in a PSU (1 per PSU). One square foot templates will be used for these floor samples. Relevant sampling data are collected on a form.
Data Recording on:		Technician Form Set (bound), pulled from Kit (B), plus completed room inventory sheet
Equipment/Items Needed (from Kit (X) unless otherwise noted)
1 tool bucket with blue Pocket Bucket Tote 1 blue ink pen 1 clipboard 1 black sharpie marker 1 tape measure (25’) 1 pr knee pads 1 box nitrile gloves 1 template (aluminum or stainless), square with 12 in. x 12 in. internal dimensions				1 roll Teflon tape (1") 1 trash bag 1 glass petri dish (4in diameter or larger) inside 1-qt re-sealable bag Pesticide Shipper [Kit (C)] with one frozen blue ice pack in it from portable freezer [Kit (Y)] left in vehicle and a COC form that stays with Kit. Used to temporarily store collected samples.
Supplies Needed from Kit (B) - Subkit T4					Supplies Needed from Kit (B) - Subkit T4b; used only for first DU in a PSU
2 rows of 4 self-adhesive, pre-printed ID labels 2 piece of aluminum foil (minimum size of 12 x 16 inches) 7 vials of isopropanol (6-mL; includes 1 spare) 2 jars containing 3 wipe pads each (do not open until used) 8 (5 plus 3 spare) Alcohol Wipes in individual packets 4 one-qt re-closable bags (2 for each regular sample)					1 rows of 4 self-adhesive, pre-printed ID labels 3 vials of isopropanol (6-mL) 1 "QC" labeled jar containing 3 wipe pads (do not open until used) 2 one-qt re-closable bags (2 for each regular sample)
Glove Use Directives:			Use new gloves only (see protocol I0)

Procedure to Collect Samples

1. Gather supplies to collect pesticide samples and go to the kitchen. Take the needed equipment and supplies into the kitchen where the sample is to be collected as indicated on the completed room inventory form.

2. Select sample locations. Select two 12” x 12” floor locations in the Kitchen that are least likely to be routinely walked-on such as under a table, in a corner or behind a door, and that are as far apart as possible. The selected locations must be large enough to accommodate the square-shaped (for use away from a wall edge) template.

3. Label the sample jars and forms. For each of the two "regular" sample jars in subkit T4, place a unique Sample ID label (suffix = 22 on one and suffix = 23 on the other) on the side of the jar using the first unused two rows of replicate Sample ID labels provided in the sub-kit. Place a replicate sample ID label (same ID numbers as above) on the Pesticide Sample Log for the non-QC sample data entries. Place a third replicate ID label from each (same ID numbers as above) on the Chain of Custody form [stored in the pesticide shipper Kit (C)] and complete the appropriate entries on both forms using a blue ink pen.

If a pesticide QC sample is to be collected in this unit, then use the supplies in subkit T4b and repeat the sample ID labeling process (one label with suffix 24 on the Jar, one replicate label on Pesticide Sample Log, and one label on Chain of Custody form).

4. Make a clean surface to work on. Place a section of aluminum foil flat on the floor near the locations to be sampled as a clean surface to place supplies on while sampling. Wearing a new pair of nitrile gloves, open an alcohol wipe package and wipe the surface of the aluminum foil where sample jars and supplies are to be placed. Discard the cleaning wipe.

5. Clean the template and place it on the first location. Open a second alcohol wipe package, unfold the wipe and wipe off the template to be used. Place the template on the first sampling location and discard the cleaning wipe.

6. Clean the petri dish. Open a third alcohol wipe package, unfold the wipe and wipe off the inside of the petri dish and then the outside of the petri dish. Set each half of the petri dish down on the aluminum foil, inside facing up to make a tray to hold the sample wipe pads. Discard the cleaning wipe.

7. Collect QC sample (subkit T4b supplies). If a QC sample is to be collected, then open the lid of the sample jar with the QC sticker, setting the lid on the cleaned aluminum foil surface with the top down. Do not touch the wipe pads. Open one vial of isopropanol and pour the entire contents (6-mL in each vial) into the jar containing the 3 wipe pads. Repeat this with a second vial, and then a third vial so that a total of 18-mL of isopropanol has been added. Discard the vials and vial caps. Re-seal the jar containing the wipe pads and isopropanol and slowly invert the jar at least 3 times with light shaking to distribute the isopropanol. Set the jar back on the clean aluminum foil surface.

8. Collect the first regular sample. Open the lid of one of the labeled regular sample jars (one without a QC sticker) containing the 3 wipe pads, setting the lid on the cleaned aluminum foil surface with the top down.

8.1 Place wipes in petri dish. Carefully remove the wipe pads from jar and tease the wipe pads apart placing one in one half of the petri dish and the other two in the other half of the petri dish.

8.2 Soak one wipe with isopropanol. Open one vial of isopropanol and pour the entire contents (6-mL) over the surface of one of the wipe pads in the petri dish. Discard the vial and vial caps.

8.3 Wipe the selected location and store sample in jar. Pick up the wetted wipe pad and wipe the floor surface inside the template using the “Standard Wiping Procedure”. Place the folded wipe pad into the empty, (original) labeled sample jar and repeat steps 8.1 through 8.3 for the remaining two wipes. Seal the jar.

8.4 Clean the template and place it on the second location. Open a fourth alcohol wipe package, unfold the wipe and wipe off the template to be used. Place the template on the second sampling location and discard the cleaning wipe.

9. Collect the second regular sample. Open the lid of the other labeled regular sample jar (one without a QC sticker) containing the 3 wipe pads, setting the lid on the cleaned aluminum foil surface with the top down and then repeat steps 8.1 through 8.3 for this second sample.

10. Re-seal each jar containing each wipe pad using Teflon tape and store. Check the lids of each jar to be sure they are tightly shut. Seal the gap between the lid and the jar by wrapping a ribbon of Teflon tape about 3 times around that portion of the jar slightly stretching the tape as you wrap. Place each sealed glass jar containing the sample in a 1-qt re-closable bag taking care to squeeze as much air out of it as you can before it is sealed. Double bag each sample jar using a second 1-qt re-closable bag, again taking care to squeeze as much air out of it as you can. Place the collected samples in the Insulated Pesticide Shipping Box [Kit (Y)] with the frozen blue ice packs.

11. Measure the approximate distance between the centers of the 2 regular samples in inches and record this number on the Pesticide Sample Log.

12. Clean equipment for storage. Open a fifth alcohol wipe package, unfold the wipe, wipe off the template(s) and petri dish and store them with field equipment. Discard the cleaning wipe.

13. Pick up trash. While wearing the gloves, clean-up remaining debris using the trash bag (toss all empty vials, cleaning wipes and packaging, aluminum foil, etc) and then finally tossing the gloves in the trash bag.

14. Complete and verify data entries. Check the Pesticide Sample Log and the Chain-of Custody form for data entries and ensure all needed entries have been made. Be sure to place the completed Chain-of Custody form back inside the Insulated Pesticide Shipping Box [Kit (Y)] with the pesticide samples (this will accompany the samples when shipped to the EPA designated lab).

NOTE: The completed Pesticide Sample Log (bound) remains with the other bound forms in the Technician Form Set and is sent back to QuanTech headquarters with the other samples and field data. EPA will be sent a copy of the applicable forms from QT headquarters.

15. Move on to lead soil sample collection, protocol T5.

Standard Wiping Procedure (Note: This is the same basic procedure as for use in collecting lead dust wipes, equivalent to the ASTM procedure. Although the 4” x 4” wipe pad is smaller than a lead wipe, it can still be folded twice as per the standard wiping protocol shown below)

A1. Select wiping pattern. Select either an “S” or Z” wiping pattern and collect the sample. Ensure that the whole sampling location is thoroughly wiped. The “S” pattern is performed as shown in Figure 1. At each turn, the wipe is rotated so that the same edge of the wipe is always leading (moving forward). The “Z” pattern is performed as shown in Figure 2, and the wipe is not rotated at each turn. The wiping patterns shown in Figures 1 and 2 can be performed as shown (right-handedly) or in mirror image (left-handedly), beginning the wiping motion at the upper right rather than the upper left.

A2. Position the wipe pad on the hand. Spread and/or fold the wipe pad on the hand in such a way that the wipe pad touches only the sampling location. Do not touch the sampling location with any part of the gloved hand. Place an open flat hand with the fingers together on the wipe pad. On some surfaces, it may be necessary to hold the wipe pad between thumb and forefinger, or between forefinger and middle finger to manipulate the wipe pad.

A3. Wipe location side-to-side. Wipe the entire sampling location either using an overlapping side-to-side “S” pattern (Figure 1a) or a back and forth “Z” pattern (Figure 2a). Apply firm pressure over the wipe pad. For an “S” pattern, position the hand so that the same edge of the wipe pad is always pushed forward. This will require twisting of both the wrist and arm upon reaching the edges of the sampling location as the surface is wiped. The “Z” pattern does not require this twisting.

A4. Fold wipe in half, sample side in. Fold the wipe pad in half with the collected residue side inward. Exercise care during folding to avoid loss of collected dust.

A5. Wipe location top-to-bottom. Using the folded wipe pad, repeat the wiping procedure within the sampling location except use a forward and back overlapping “S” (Figure b) or “Z” (Figure 2b) pattern.

A6. Fold wipe in half, sample side in. Fold the wipe pad in half again with the collected residue side inward. Exercise care during folding to avoid loss of collected dust.

A7. Wipe location edges and corners. Wipe edges and corners within the sampling location as illustrated in Figure 1c or Figure 2c for the “S” or “Z” wiping pattern, respectively.

A8. Fold wipe in half, sample side in. Fold the wipe pad in half again with the collected dust side inward. Exercise care during folding to avoid loss of collected dust.

A9. Store collected sample. Insert the folded wipe pad into the sample container.

FIGURE 1: Schematic of a side-to-side overlapping “S” wiping pattern. Only the center of the wipe path is shown, not the entire wiping width. Figure 1a shows the first “S” wipe pattern; Figure 1b shows the second “S” wipe pattern; and Figure 1c shows the final pattern that concentrates on the edges and corners.

FIGURE 2: Schematic of a side-to-side overlapping “Z” wiping pattern. Only the center of the wipe path is shown, not the entire wiping width. Figure 2a shows the first “Z” wipe pattern; Figure 2b shows the second “Z” wipe pattern; and Figure 2c shows the final pattern that concentrates on the edges and corners.

PESTICIDE WIPE SAMPLE LOG
Kitchen	Room ID # ___________		Initials ______________

Sample #	Sample collected ?	Location	Sample surface code (circle one)	Surface area wiped
Field sample ID label here	Yes 1 No 2 If No, reason code: ______________ ______________ ______________ ______________ ______________	Floor	Smooth Cleanable 1 Rough Not cleanable 2 Carpeted 3	12” x 12” 1 NOT 12” x 12” 2 Enter: \|___\|\|___\|in X \|___\|\|___\|in
Field sample ID label here	Yes 1 No 2 If No, reason code: ______________ ______________ ______________ ______________ ______________	Floor	Smooth Cleanable 1 Rough Not cleanable 2 Carpeted 3	12” x 12” 1 NOT 12” x 12” 2 Enter: \|___\|\|___\|in X \|___\|\|___\|in

Approximate distance between the centers of two samples listed above (inches): _____________________

QC ID label here (from subkit T4)b	Yes 1 No 2 If No, reason code: ______________ ______________ ______________ ______________ ______________ ______________	QC Sample

Reason Codes (for no sample):

I - Inaccessible

NA - Not allowed

NP - No collection jar present

NR - Not required

O - Other (SPECIFY IN BOX)

Chain-of-Custody for Pesticide Samples [page 1 of 2]
HU#
Completed by:						on
	(name)						(date)
Sample ID		Check Sample Type			Comments
		QC sample	Field Sample
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Relinquished by: Date / Time:				Relinquished by: Date / Time:
Received by: Date / Time: Condition Acceptable?  Yes  No				Received by: Date / Time: Condition Acceptable?  Yes  No

Chain-of-Custody for Pesticide Samples [page 2 of 2]
HU#
Completed by:						on
	(name)						(date)
Sample ID		Check Sample Type			Comments
		QC sample	Field Sample
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Field sample ID label here
Relinquished by: Date / Time:				Relinquished by: Date / Time:
Received by: Date / Time: Condition Acceptable?  Yes  No				Received by: Date / Time: Condition Acceptable?  Yes  No

T5- LEAD SOIL SAMPLING
Staff Involved:	Assigned Field Technician
Overview: After completing the collection of pesticide wipe samples, soil samples will be collected from the locations listed below. At each location, samples will be collected from bare soil, i.e., not covered with grass, concrete, asphalt, or other permanent covering, if possible. If no soil is bare, soil samples will be collected from covered surfaces, if possible. Thus, soil samples may be collected from soil covered by grass or mulch, but not concrete or asphalt. A maximum of six soil samples will be collected as shown below. Relevant sampling data are collected on the forms in this protocol. One (1) main entry composite sample. Two (2) foundation/dripline composite samples. One (1) mid-yard area composite sample. One (1) or two (2) composite play area samples. In addition to the soil samples, an estimate will be made of the total bare soil on the property associated with the DU and recorded as <9 sq. ft. or >=9 sq. ft.
Data Recording on:		Technician Form Set (bound) pulled from Kit (B)
Equipment Needed from Kit (X)
1 tool bucket with blue Pocket Bucket Tote 1 blue ink pen 1 clipboard 1 black sharpie marker 1 pocket knife 1 flashlight with extra batteries				1 tape measure (25’) 1 box of cleaning clothes (wipes) 1 box nitrile gloves 1 pr knee pads 1 trowel 1 scoopula 1 trash bag
Supplies Needed from Kit (B) - Subkit T5
Six 6oz. Jars for storing samples Six rows of 4 self-adhesive, pre-printed ID labels Six 1-qt re-closable bags (one for sample)				Six 1-qt re-closable bags (for each sample) One 2-gal re-closable bags (for holding samples containers together)
Glove Use Directives:			Use new or clean gloves between samples (see protocol I0)

General Procedure

1. Collect one main entry composite sample as listed below. This sample represents soil which may be blown or easily tracked into the home. This sample is a composite of 3 scoop samples spread out as much as possible in a roughly 1- foot diameter circle placed as close as possible to the front entryway.

1.1 Select sampling area immediately adjacent to main entryway. Locate the main entryway of the DU and select a sampling location in the immediate area near this entryway for soil that may be blown or easily tracked into the home. For multi-family housing, select the entryway that is most often used by the residents going into the building where the unit is located.

1.2 Collect the composite sample as shown in the Procedure to Collect Composite Soil Sample.

2. Collect the first (1 sample) of two foundation/dripline composite samples as listed below. This sample is from the exterior wall area matching the main entry to the DU. This sample is a composite of 3 scoop samples spread out along the foundation/dripline areas within 3 feet of the building foundation.

2.1 Select sampling area along wall that includes the main entryway. Locate the main entryway of the DU and select a sampling location from the exterior wall area matching the main entry to the DU.

2.2 Collect the composite sample along the dripline as shown in the Procedure to Collect Composite Soil Sample.

3. Collect the second (1 sample) of two foundation/dripline composite samples as listed below. This sample is from an exterior wall area (different from the sample above) that is selected as the most likely wall to be a part of or immediately adjacent to a children’s play area. This sample is a composite of 3 scoop samples spread out along the foundation/dripline areas within 3 feet of the building foundation.

3.1 Select sampling area along wall most likely to be facing children's play area (not the main entryway). Locate the main entryway of the DU and select a sampling location from a NON-ENTRYWAY exterior wall area that is selected as the most likely wall to be a part of or immediately adjacent to a children’s play area.

3.2 Collect the composite sample in dripline as shown in the Procedure to Collect Composite Soil Sample.

4. Collect one (1 sample) mid-yard composite sample as listed below. This soil represents lead in the residential yard away from the housing unit. This sample is a composite of 3 scoop samples spread out as much as possible in a roughly 1-foot diameter circle located on the most prominent bare soil area on any side of the DU found approximately midway between the drip line and the nearest property boundary or between the drip line and another building on the housing unit property.

4.1 Select sampling area in mid-yard at most prominent bare area. Locate the most prominent bare soil area on any side of the DU found approximately midway between the drip line and the nearest property boundary or between the drip line and another building on the housing unit property. If no mid-yard soil is bare, soil samples will be collected from a covered mid-yard area, if possible by carefully removing the covering of mulch or grass after a scoop sample is collected.

4.2 Collect the composite sample as shown in the Procedure to Collect Composite Soil Sample.

5. Collect one or two (1-2 samples) composite play area samples as listed below. This sample is a composite of 3 scoop samples that are collected from fixed ‘units’ of play equipment

5.1 Identify number of fixed units of play equipment. A play area is defined as an area that has fixed play equipment including swing sets, climbing gyms, sandboxes, permanent/immovable pools, and sport/game areas (basketball, net games, horseshoes, ball field, etc.). Pieces of attached, contiguous equipment, such as an attached slide, swings, and teeter-totter, will be treated as one fixed ‘unit’ of play equipment.

5.2 Select one or two sampling areas at fixed units of play equipment.

5.2.1 If only one (1) fixed ‘unit’ of play equipment exists, one composite sample will be collected at this unit.

5.2.2 If two (2) fixed ‘units’ of play equipment exist, two composite samples will be collected, one each at each unit.

5.2.3 If three (3) or more fixed ‘units’ of play equipment exist, two composite samples will be collected, one each at 2 randomly selected units. Two (2) fixed units will be randomly selected (See Random Selection Procedure) from among all fixed ‘units’ that appear to be the most commonly used by children using the Random Selection Procedure for Items.

5.3 Collect the composite sample(s) as shown in the Procedure to Collect Composite Soil Sample.

6. Temporarily store samples. Place the all the collected samples in a 2-gal re-closable bag to hold them together and temporarily store them in your tool bucket.

7. Review and complete data entries. Review the samples collected and the data recorded on the Lead Soil Sample Log and the Chain-of-Custody form. Ensure that all data fields are completed. Make any needed corrections.

Procedure to Collect Composite Soil Sample

1. Label the container(s) and forms. Place a Sample ID label on a sample container (jar) using the first unused row of 4 Sample ID labels provided with Technician Set. Place a second replicate ID label (same ID number as above) on the indicated place on the Lead Soil Sample Log. Place a third replicate ID label (same ID number) on a chain of custody form and complete the appropriate entries on this form. For backup labeling, write the sample ID number on the sample container (opposite side of sample label) using a black sharpie marker. Be sure this hand-written ID number matches the ID number shown on the label.

2. Put on gloves. Don a new pair of nitrile gloves as needed.

3. Clean gloves, scoopula, trowel, and tape measure. Wipe off the gloves with a cleaning wipe, then the sampling trowel, scoopula, and the tape measure to be used for sample collection and dispose of the cleaning wipe in a trash bag.

4. Repeat step (3).

5. Dig test hole to 1/2 inch depth. Using the trowel or scoopula and a tape measure, dig a small test hole adjacent to the sampling location to a depth of ½ inch. Use this hole as a visual aid during soil collection to help limit collection to a depth of ½ inch. Clean the sampling trowel using a wipe and dispose of the cleaning wipe in a trash bag.

6. Collect first of three (3) sub-samples. Collect soil placing it in the labeled jar (soil collection container) by scooping soil with the trowel or scoopula down to the depth indicated by the test hole. Continue to collect soil down to that depth until about a 1/3 of the jar is filled. Remove any large debris from the sample such as sticks and plant material by picking it out with your gloved hand.

7. Collect soil from two more locations to complete the composite sample as listed below:

7.1 If this is not a dripline sample, collect roughly the same volume of soil from two more locations within a 1-foot diameter circle around the first sample location. Put these sub-samples in the same soil collection container as the first sub-sample from (6) above. Be sure that the soil container is full or close to full. Seal the jar tight using the supplied lid and seal the jar inside a 1 quart re-closeable bag.

7.2 For dripline samples, collect roughly the same volume of soil from two more locations along the dripline so that the three portions of the composite are roughly equally spaced along that side of the DU and the maximum distance between any two sub-samples is roughly one foot. Put this sub-sample into the same soil collection container as the first sample from (6) above. Be sure that the soil container is full or close to full. Seal the jar tight using the supplied lid and seal the jar inside a 1 quart re-closeable bag.

8. Complete data entries on forms. Record the data collection information on the applicable row of the Lead Soil Sample Log and Chain-of-Custody form matching the label on the sample container. Complete the entries as indicated on these forms.

Random Selection Process for Items (playsets)

1. Count the number of items (playsets).

2. Go to the Random Number Table (see form in protocol T1)

2.1 Select the first unused row of the table.

2.2 Look under the column that matches the count number to get the selection and remember the selected number.

2.3 Put a line through that row of the table to indicate that it has been used.

3. Starting at the left most item (playset), count items clockwise (left to right) until the selected number is reached and collect samples from this item (playset).

For example, if there are 3 play set areas and the 6^th row of the table is the first open row not previously used, then the 3^rd play set (going from left to right) is to be tested.

Random Number Table for Random Selections

Random Number Selections from a Group of 2 to 14 Items
Row	Number of Items to Pick From:
Row	2	3	4	5	6	7	8	9	10	11	12	13	14
1	2	2	3	1	3	4	5	3	7	11	5	3	5
2	2	3	3	4	2	5	8	5	10	1	3	7	2
3	2	1	3	1	4	2	8	3	2	5	7	3	2
4	2	3	3	1	3	1	6	8	6	9	3	13	2
5	1	1	3	5	4	2	6	2	5	3	4	2	2
6	1	3	2	3	4	7	6	2	6	3	12	4	14
7	2	3	2	2	5	6	6	1	1	8	9	8	8
8	2	2	1	4	2	4	5	5	4	6	6	10	13
9	2	2	3	1	5	3	6	6	7	2	8	7	1
10	1	3	1	1	3	2	2	7	5	6	10	4	13
11	2	1	3	1	5	7	3	6	10	6	3	2	13
12	1	2	3	2	5	4	2	4	8	3	10	11	9
13	1	2	2	2	4	3	2	6	3	8	4	4	6
14	2	1	3	3	3	2	3	7	5	10	5	4	7
15	2	2	1	4	4	7	3	7	2	9	7	5	11
16	2	3	1	3	3	6	6	9	8	11	5	2	11
17	2	3	3	2	4	3	4	2	9	3	3	12	12
18	1	2	2	2	4	4	2	4	7	2	5	9	12
19	1	1	1	3	5	3	3	4	2	4	8	7	8
20	1	3	3	2	2	2	2	3	5	7	11	12	12
21	2	1	4	4	5	1	3	2	2	3	4	7	4
22	2	1	3	4	3	5	3	5	5	10	1	11	2
23	2	1	3	3	1	5	3	3	5	5	4	7	3
24	1	3	2	3	5	4	7	3	8	4	8	5	6
25	1	3	2	2	6	2	5	5	3	2	1	10	2
26	2	3	3	4	5	5	5	8	6	3	6	3	12
27	2	3	3	2	2	6	2	1	6	2	5	8	12
28	1	3	3	4	6	3	7	1	3	3	2	8	11
29	2	2	4	4	3	7	3	2	8	10	6	10	8
30	1	1	2	5	5	2	3	2	3	4	4	8	11
31	2	3	1	4	4	4	5	7	6	3	6	2	3
32	1	3	3	4	5	5	4	3	9	6	3	9	12
33	1	2	3	3	2	4	6	8	4	3	4	11	13
34	2	1	1	3	3	3	7	4	8	2	4	11	1
35	1	1	3	2	6	6	6	3	8	4	6	1	7
36	1	1	3	5	3	4	5	6	10	2	9	1	11
37	1	2	2	3	3	7	7	4	3	2	3	6	12
38	1	2	3	5	4	7	6	1	1	8	6	8	13
39	1	1	1	3	3	6	5	3	7	8	12	6	1
40	2	2	1	1	2	4	7	9	5	9	5	11	12

LEAD SOIL SAMPLE LOG
DU ID:_____________________							Initials________
>GENERAL AREAS
Sample number	Sample Collected?		Sample Type	Other Data		Wall (circle one)	Type of cover code (circle one)
sample ID label here	Yes 1 No 2 If No, reason code: _______		Major entry			N E S W	Bare 1 Grass 2 Mulch 3 Moss 4 Ivy/plant 5 Sand/Gravel 6
sample ID label here	Yes 1 No 2 If No, reason code: _______		Foundation/ drip line			N E S W	Bare 1 Grass 2 Mulch 3 Moss 4 Ivy/plant 5 Sand/Gravel 6
sample ID label here	Yes 1 No 2 If No, reason code: _______		Foundation/ drip line			N E S W	Bare 1 Grass 2 Mulch 3 Moss 4 Ivy/plant 5 Sand/Gravel 6
sample ID label here	Yes 1 No 2 If No, reason code: _______		Mid yard	Distance to wall: \|___\| \|___\| ft		Play Area? Y 1 N 2	Bare 1 Grass 2 Mulch 3 Moss 4 Ivy/plant 5 Sand/Gravel 6
>PLAY AREAS
Sample number	Sample Collected?		Sample Type	Is the Play Eqpt treated wood?			Type of cover code
sample ID label here	Yes 1 No 2 If No, reason code: _________		Play equipment	Yes 1 No 2			Bare 1 Grass 2 Mulch 3 Moss 4 Ivy/plant 5 Sand/Gravel 6
sample ID label here	Yes 1 No 2 If No, reason code: _________		Play equipment	Yes 1 No 2			Bare 1 Grass 2 Mulch 3 Moss 4 Ivy/plant 5 Sand/Gravel 6

>TOTAL AREA OF BARE SOIL		Less than 9 ft²: Yes 1 No 2			9 ft² or more: Yes 1 No 2
		Percent of yard area with bare soil: \|___\|\|___\| %

Reason Codes (for No sample)

I -Inaccessible, NA -Not allowed, NS -No soil present, NSP - no second play area to sample from

O -Other (SPECIFY IN BOX)

AHHS II Field Chain-of-Custody for Lead in Soil
DU ID
Completed by:					on
	(name)					(date)
Sample ID		TYPE Soil	Comments
Field sample ID label here		X
Field sample ID label here		X
Field sample ID label here		X
Field sample ID label here		X
Field sample ID label here		X
Field sample ID label here		X
Relinquished by: Date / Time:				Relinquished by: Date / Time:
Received by: Date / Time: Condition Acceptable?  Yes  No				Received by: Date / Time: Condition Acceptable?  Yes  No

1 It should be noted, however, that experienced Interviewers are often successful in gaining entry into such restricted access communities.

Field protocols for AHHS II Revision No. 0 15Dec16 page i

File Type	application/vnd.openxmlformats-officedocument.wordprocessingml.document
File Title	QAP Appendix B
Subject	AHHS
Author	Dewalt
File Modified	0000-00-00
File Created	2021-01-14
